KW1-2301 SERIES
LED Numeric Display
Single Digit (2.30")
DESCRIPTION:
The KW1-2301 series is large single digit display in 2.30 inch (56.90mm) height
with right DP designed for accurate readable displays need to be viewed over
a distance.
This series is suitable for use in instruments, digital readout displays.
All devices are available as either common anode or common cathode.
PACKAGE DIMENSIONS
31.90
8.0
o
5.50
A
F
69.70
58.40(2.3")
G
B
ABSOLUTE MAXIMUM RATINGS: (Ta=25 C)
Parameter
Max
Reverse Voltage per segment
5V
Reverse Current per segment (Vr = 5V)
100µA
Derating Linear from 25
o
C per segment
0.4mA/
o
C
Operating Temperature Range
-40
o
C To 85
o
C
Storage Temperature Range
-40
o
C To 100
o
C
Soldering Temperature 1.6mm(1/16") from body for 5 sec. at 260
o
C
NOTES : 1. All dimensions are in millimeters (inches).
2. Tolerance is +0.25mm(0.010) unless otherwise specified.
3. Specifications are subject to change without notice.
4. NP: No Pin.
5. NC: No Connect.
o
E
D
C
DP
+
PIN 1
47.70
12.0
2.54*4=10.16
φ0.50
59.80
INTERNAL CIRCUIT DIAGRAM
1, 8
1, 8
TESTING CONDITION FOR EACH PARAMETER :
Parameter
Forward Voltage
Peak Emission Wave Length
Spectral Line Half-Width
Reverse Current
Average Luminous Intensity
Symbol
Vf
λρ
∆λ
Ir
Iv
Unit
V
nm
nm
µA
µ
cd
Test Condition
If=20mA
If=20mA
If=20mA
Vr=5V
If=10mA
A B C D E F
7 6
4
3 2 9
G DP
10 5
A B C D E F
7 6
4
3 2 9
G DP
10 5
PART NO. SELECTION AND APPLICATION INFORMATION (RATINGS AT 25 C AMBIENT)
Chip
Part No.
Raw
Material
GaAsP/GaP
GaAlAs
GaP
GaP
GaAsP/GaP
GaAsP/GaP
GaAlAs
GaP
GaP
GaAsP/GaP
Emitted
Color
Hi-Eff. Red
Super Red
Green
Super Green
Yellow
Hi-Eff Red
Super Red
Green
Super Green
Yellow
Common
Cathode
Common
Anode
C.C
or
C.A
Wave
Length
λρ
(nm)
635
660
565
570
585
635
660
565
570
585
Absolute Maximum Ratings
∆λ
Pd
If
Electro-optical Data(at 10mA)
o
If
If
Vf (V)
Iv (µcd)
(Peak) Per Segment (Rec) Per Segment
(nm) (mW) (mA) (mA) Min. Typ. Max. mA Min. Typ.
45
20
30
30
30
45
20
30
30
30
100
100
100
100
100
100
100
100
100
100
50
50
50
50
50
50
50
50
50
50
100
100
100
100
100
100
100
100
100
100
6.8
6.4
6.8
6.8
6.8
6.8
6.4
6.8
6.8
6.8
8.0
7.5
8.4
8.4
8.4
8.0
7.5
8.4
8.4
8.4
10 10-20 2000 6000
8.0 10-20 12000 42000
10 10-20 1800 5400
10 10-20 2000 5700
10 10-20 1800 5400
10 10-20 2000 6000
8.0 10-20 12000 42000
10 10-20 1800 5400
10 10-20 2000 5700
10 10-20 1800 5400
KW1-2301A3
KW1-2301AS
KW1-2301A2
KW1-2301AG
KW1-2301A6
KW1-2301C3
KW1-2301CS
KW1-2301C2
KW1-2301CG
KW1-2301C6
REMARKS : 1. The average luminous intensity is obtained by summing the luminous intensity of each segment and dividing by the total number of segments.
2. Luminous intensity is measured with a light sensor and filter combination that approximates the CIE (International Commission on Illumination) eye-response curve.
3. Clean only by pure water, isopropanol, ethanol, Freon TF (or equivalent).
