CONSMA006.062

Description
RF connectorsma fml edge multi mnt for 0.062 pcb
CategoryThe connector
File Size152KB,1 Pages
ManufacturerConnector City
Environmental Compliance
Download Datasheet View All

CONSMA006.062 Overview

RF connectorsma fml edge multi mnt for 0.062 pcb

1
2
3
4
D
Description
Body
Socket
Insulation
Washer
Nut
Material
Brass
BE CU
Teflon
Brass
Brass
Finish
Nickel
Gold
Teflon
Nickel
Nickel
TOP VIEW
0.040 (1.02)
MOUNTING METHODS
0.050 (1.27)
Use of nut
optional
D
0.040 (1.02)
SIDE VIEW
∅0.325
(8.30)
∅0.225
(5.80)
1/4-36UNS-2A
THREADS
BACK VIEW
0.05 terminal
(1.27)
0.039 0.179
(1.00) (4.54)
0.04 (1.02)
0.04 (1.02)
0.067±0.002
(1.70±0.05)
Clamps into
molded case
C
C
Clamps into
molded case
FLAT 0.228
(5.80)
0.175
(4.50)
0.375
(9.60)
0.786
(20.40)
0.375
(9.60)
0.152
(3.90)
0.157
(4.00)
0.240
(6.10)
Flange hides
hole
B
NUT
H8
0.311
(7.90)
WASHER
Plastic/Metal
Case
B
RECOMMENDED FOOTPRINT
0.16
0.06
A
RECOMMENDED
MOUNTING HOLE
∅0.254
(6.50)
Ø0.402
(10.20)
1/4-36UNS-2B
THREADS
Serves as
rear flange
0.10
0.234
(6.00)
0.10
Title
0.065
(1.65)
SMA FEMALE EDGE MULTI-MOUNT
FOR 0.062" THICK BOARD
Revision:
1.0
Date:
5/29/2007
INCHES (mm)
0.020
(0.50)
A
Part No.
CONSMA006.062
Dimensions:
CONNECTOR CITY
159 ORT LANE
MERLIN, OR 97532
PH (541)-471-6256
FAX (541)-471-6251
Sheet 1 of 1
