TG2210FT
TOSHIBA GaAs Linear Integrated Circuit GaAs Monolithic
TG2210FT
RF SPDT Switch
Switch the receive filter for mobile communication.
Switch the diversity antenna.
Switch the local signal.
Features
·
·
·
·
Low insertion Loss: L
OSS
= 0.4dB (typ.)
High isolation: ISL = 30dB (typ.)
Low voltage operation: V
C
= 0 V/2.5 V
Small package: TU6 package (2.0 × 1.25 × 0.6 mm)
Weight: 0.008 g (typ.)
Pin Connection, Marking
(top view)
V
C1
6
RFcom
5
V
C2
4
UL
1
RF2
2
GND
3
RF1
Maximum Ratings
(Ta
=
25°C)
Characteristics
Control voltage
Input power
Operating temperature range
Storage temperature range
Symbol
V
C1
V
C2
P
i
T
opr
T
stg
Rating
5
5
1
-40~85
-55~125
Unit
V
V
W
°C
°C
Caution
This device is sensitive to electrostatic discharge. When using this device, please ensure that all tools and
equipment are earthed.
1
2002-07-30
TG2210FT
Test Circuit 1
(RF Test Circuit)
RFcom
C1
V
C1
C
2
C
2
V
C2
Top
view
C
1
C
3
GND
C
1
RF2
RF1
C
1
: 100 pF
C
2
: 100 pF
C
3
: 7 pF
Please fix the value of each capacity for using frequency and circuit.
Recommend Capacity
1 GHz
Ｃ
1
Ｃ
2
Ｃ
3
100 pF
100 pF
7 pF
1.6 GHz
100 pF
100 pF
3 pF
2.4 GHz
100 pF
100 pF
1.5 pF
Notice
The circuits and measurements contained in this document are given only in the context of as examples of
applications for these products.
Moreover, these example application circuits are not intended for mass production, since the high-frequency
characteristics (the AC characteristics) of these devices will be affected by the external components which the
customer uses, by the design of the circuit and by various other conditions.
It is the responsibility of the customer to design external circuits which correctly implement the intended
application, and to check the characteristics of the design.
TOSHIBA assume no responsibility for the integrity of customer circuit designs or applications.
3
2002-07-30
