802.11a/b/g Wireless and Ethernet LAN Adapter
SX-550
Embedded
Wireless and
Networking Module
Embedded
Intelligent OEM
Wired Networking for OEM devices
The Most Powerful and Secure Way to Implement Wireless Capabilities
The advantages of wireless networking are obvious. But as an OEM
device manufacturer, how can you easily and securely implement
wireless capabilities in your devices?
The solution is the Silex SX-550 Module, the first embedded networking
solution that supports all of the major wireless networking standards --
802.11a, 802.11b, and 802.11g -- as well as 100Base-T and 10Base-T
wired Ethernet. The SX-550 provides the most extensive network
security capabilities in the industry, so it can be used in virtually any
application or environment that requires wireless communications.
The SX-550 increases your bottom line by reducing your time to
market, making your products more competitive, and lessening the
need for in-house wireless expertise. It enables you to easily add wired
or wireless network connectivity to your devices with such features as:
•
High speed serial port plus dedicated console.
The SX-550 serial port
runs at speeds up to 921.6Kbps with full modem control. The SX-550
also includes a second serial port for use as a dedicated console.
•
Ethernet and wireless versions.
The SX-550 is available in models with
wired Ethernet only, or with both Ethernet and 802.11a/b/g wireless
capabilities. The two models are program compatible, so you do not
need to develop separate software in order to support both.
•
8 general purpose input/output (GPIO) signals.
The GPIOs can be
used for custom applications like driving LEDs and sensing switches, or
for modem signals in conjunction with the serial ports.
•
Serial port emulation soft ware.
The SX-550 includes software that
emulates a standard Windows
TM
COM port (for example, COM3). This
allows you to use your existing Windows-based applications without any
changes.
•
Ethernet bridge mode.
The SX-550 can be configured as a transparent
bridge between Ethernet and 802.11a/b/g. This allows an Ethernet-
enabled device to communicate wirelessly with no modifications required
to your existing software.
•
Power management.
The SX-550 consumes very little power during
inactive periods, making it ideal for battery powered applications.
•
Antenna diversity.
The SX-550 has two U.FL antenna connectors for
improved quality of transmission and reception.
•
Easy to use.
The SX-550 features a compact form factor with
through-holes for flexible mounting options. A 40-pin connector
header for the serial and GPIO signals simplifies the hardware
interface to your device.
An available developer's kit provides the required hardware, software
tools and documentation for OEM customers to easily integrate the
SX-550 module in their equipment. The developer's kit includes
value-added programmable features, such as APIs for custom SNMP
and Email notification on the network. For example, you can use the
available GPIOs to eliminate the need for an additional processor and
therefore to reduce cost.
Highly Secure
Security is critical for enterprise and medical networks. In fact,
some network managers will not allow devices on their networks
that are not compatible with their security standards. Consequently,
the SX-550 is designed to work with all the major security standards.
It supports 802.1x Extensible Authentication Protocol (EAP) with
TLS, TTLS, LEAP, FAST, and PEAP to provide the most robust
network authentication. For wireless security, the SX-550 works
with the latest Wi-Fi Protected Access 2 (WPA2) Enterprise and
Personal (PSK) security, as well as WPA and WEP. The SX-550
also includes other enterprise-level security features such as access
control lists, protocol and application enable/disable, read and write
configuration passwords, and SNMP community name configuration.
Easy to Manage
The SX-550 is easy to configure and offers several options for
management. In addition to a built-in web browser interface, silex
provides ExtendView, a Windows utility for bulk configuration and
management. A console accessible via TELNET or the UART is
available for more sophisticated diagnostics and configuration. The
SX-550 is also compatible with the Simple Network Management
Protocol (SNMP) for compatibility with most popular network
management systems. In adddition, the SX-550 can be managed by
the attached device using AT commands and console commands
sent via the serial port. The SX-550 firmware is stored in flash
memory for easy updating in the field.
silex SX-550 Module Diagram
2.346"
0.570"
0.270"
2.346"
1.660"
0.875"
0.215"
1.750"
1.500"
1.580"
0.140"
1.750"
0.85"
2.176"
CPU BOARD - BOTTOM VIEW
0.085"
0.100"
0.118"
0.770"
0.087" DIA
6 PLACES
WIRELESS LAN - TOP VIEW
OEM Interface
The OEM interface allows OEMs to add functionality via a
daughtercard. Power is also input via this header. This is a 40-
pin 0.05” pitch surface-mount header
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
Signal
TPRX+
TPRX-
SWITCH
AVDD
UART0_RXD
UART0_TXD
GND
UART0_RTS
UART1_RTS
GND
UART1_TXD
GND
SPI_CS
+3.3VDC
GPIO_1
GPIO_2
+3.3VDC
GPIO_3
GND
GPIO_5
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
Signal
TPTX+
TPTX-
LED_1
+3.3VDC
GPIO_9
GPIO_10
+3.3VDC
UART0_CTS
UART1_CTS
GND
UART1_RXD
RESET_N
SPI_CLK
GND
SPI_SDO
SPI_SDI
GND
GPIO_4
GND
GPIO_6
Specifications
Serial Ports
Two serial UART ports are be
accessible via the OEM header.
Port 1 supports Transmit Data,
Receive Cata, Clear to Send, and
Request to send. 3 of the GPIOs
can be configured for use as the
Data Terminal Ready, Dataset
Ready, and Data Carrier Detect
modem signals.
Port 2 is dedicated for as a
console port for management
and configuration purposes.
General Purpose I/O Signals
8 of the general purpose signals
of the CN210 Processor are
accessible via the OEM header.
They can be used for driving
LED's, receiving switch input or as
general purpose signals that allow
the user to monitor or control via
the silex software interface.
External pull-ups are required for
customization.
Power Input
Power is input to the main module
via the OEM header. +3.3VDC +/-
10% is supplied through this
header.
Power Consumption
Wireless LAN power consumption
1000mA for maximum transmit.
Environmental Temperature
•
Operating Temperature: 0°
to 50° C
•
Storage Temperature: -20°
to +70° C
•
Maximum temperature
change per hour: 20° C
Relative Humidity
•
Operating: 10% to 90% non-
condensing
•
Storage: 10% to 90% non-
condensing
Altitude
•
Operating: 3.1 km
•
Storage: 9 km
Standards Compliance
•
RS232, serial interfaces
•
802.11 a/b/g for the wireless
version
•
802.3i (10Base-T) and
802.3u (100Base-TX)
Ethernet
•
RFC 2217
Ordering Information
For your specific configuration and its corresponding part number,
call silex at 1-866-765-8761 (U.S. toll-free) or +1 801-748-1199
(other countries).
Technical information and specifications are subject to change without notice. ©2008 Silex Technology, Inc.
