K4S511633C-YL/N/P
8M x 16Bit x 4 Banks Mobile SDRAM
FEATURES
• 3.0V power supply
• LVCMOS compatible with multiplexed address
• Four banks operation
• MRS cycle with address key programs
-. CAS latency (1 & 2 & 3)
-. Burst length (1, 2, 4, 8 & Full page)
-. Burst type (Sequential & Interleave)
• All inputs are sampled at the positive going edge of the system
clock.
• Burst read single-bit write operation
• DQM for masking
• Auto & self refresh
• 64ms refresh period (8K cycle)
• 1 /CS Support.
• Commercial Temperature Operation (-25°C ~ 70
°C).
Extended Temperature Operation (-25°C ~ 85°C).
Industrial Temperature Operation (-40°C ~ 85°C).
• 54balls DDP CSP
K4S511633C-YL/N80
K4S511633C-YL/N1H
K4S511633C-YL/N1L
CMOS SDRAM
GENERAL DESCRIPTION
The K4S511633C is 536,870,912 bits synchronous high data
rate Dynamic RAM organized as 4 x 8,388,608 words by 16bits,
fabricated with SAMSUNG's high performance CMOS technology.
Synchronous design allows precise cycle control with the use of
system clock I/O transactions are possible on every clock cycle.
Range of operating frequencies, programmable burst length and
programmable latencies allow the same device to be useful for a
variety of high bandwidth, high performance memory system
applications.
ORDERING INFORMATION
Part No.
Max Freq.
125MHz(CL=3)
100MHz(CL=2)
100MHz(CL=2)
100MHz(CL=3)
*1
LVCMOS
54 CSP
Interface
Package
- YN : Low Power, Operating Temp : -25°C ~ 85
°C.
- YL : Low Power, Operating Temp : -25°C ~ 70
°C.
- YP : Low Power, Operating Temp : -40
°C
~ 85
°C.
Note :
1. In case of 33MHz Frequency, CL1 can be supported.
FUNCTIONAL BLOCK DIAGRAM
I/O Control
LWE
Data Input Register
LDQM
Bank Select
8M x 16
Sense AMP
8M x 16
8M x 16
8M x 16
Refresh Counter
Output Buffer
Row Decoder
Row Buffer
DQi
Address Register
CLK
ADD
Column Decoder
Col. Buffer
Latency & Burst Length
LRAS
LCBR
LCKE
LRAS
LCBR
LWE
LCAS
Programming Register
LWCBR
LDQM
Timing Register
* Samsung Electronics reserves the right to
change products or specification without
notice.
CLK
CKE
CS
RAS
CAS
WE
DQM
Rev. 1.2 Dec. 2002
K4S511633C-YL/N/P
ABSOLUTE MAXIMUM RATINGS
Parameter
Voltage on any pin relative to Vss
Voltage on V
D D
supply relative to Vss
Storage temperature
Power dissipation
Short circuit current
Symbol
V
I N
, V
O U T
V
DD
, V
DDQ
T
STG
P
D
I
OS
Value
-1.0 ~ 4.6
-1.0 ~ 4.6
-55 ~ +150
1
50
CMOS SDRAM
Unit
V
V
°C
W
mA
Notes :
Permanent device damage may occur if ABSOLUTE MAXIMUM RATINGS are exceeded.
Functional operation should be restricted to recommended operating condition.
Exposure to higher than recommended voltage for extended periods of time could affect device reliability.
DC OPERATING CONDITIONS
Recommended operating conditions (Voltage referenced to V
SS
= 0V, T
A
=Commercial, Extended and Industrial)
Parameter
Supply voltage
Input logic high voltage
Input logic low voltage
Output logic high voltage
Output logic low voltage
Input leakage current
Symbol
V
D D
V
DDQ
V
I H
V
IL
V
O H
V
OL
I
LI
Min
2.7
2.7
2.2
-0.3
2.4
-
-10
Typ
3.0
3.0
3.0
0
-
-
-
Max
3.6
3.6
V
DDQ
+0.3
0.5
-
0.4
10
Unit
V
V
V
V
V
V
uA
1
2
I
O H
= -2mA
I
OL
= 2mA
3
Note
Notes :
1. V
IH
(max) = 5.3V AC. The overshoot voltage duration is
≤
3ns.
2. V
IL
(min) = -2.0V AC. The undershoot voltage duration is
≤
3ns.
3. Any input 0V
≤
V
IN
≤
V
DDQ
.
Input leakage currents include HI-Z output leakage for all bi-directional buffers with tri-state outputs.
4. Dout is disabled, 0V
≤
V
OUT
≤
V
DDQ.
CAPACITANCE
Clock
(V
DD
= 3.0V, T
A
= 23°C, f = 1MHz, V
REF
=0.9V
±
50 mV)
Pin
Symbol
C
CLK
C
IN
C
IN
C
ADD
C
OUT
Min
3.0
3.0
1.5
3.0
3.0
Max
9.0
9.0
4.5
9.0
6.5
Unit
pF
pF
pF
pF
pF
Note
RAS, CAS, WE, CS, CKE
DQM
Address
D Q
0
~ DQ
15
Rev. 1.2 Dec. 2002
K4S511633C-YL/N/P
DC CHARACTERISTICS
CMOS SDRAM
Recommended operating conditions (Voltage referenced to V
SS
= 0V, T
A
=Commercial, Extended and Industrial)
Parameter
Symbol
Burst length = 1
t
RC
≥
t
R C
(min)
I
O
= 0 mA
CKE
≤
V
IL
(max), t
CC
= 10ns
Test Condition
-80
Operating Current
(One Bank Active)
Precharge Standby Current
in power-down mode
I
CC1
160
Version
-1H
155
-1L
145
mA
1
Unit
Note
I
CC2
P
2
2
35
I
C C 2
PS CKE & CLK
≤
V
IL
(max), t
CC
=
∞
I
CC2
N
CKE
≥
V
IH
(min), CS
≥
V
IH
(min), t
CC
= 10ns
Input signals are changed one time during 20ns
CKE
≥
V
IH
(min), CLK
≤
V
IL
(max), t
CC
=
∞
Input signals are stable
CKE
≤
V
IL
(max), t
CC
= 10ns
mA
Precharge Standby Current
in non power-down mode
I
CC2
NS
Active Standby Current
in power-down mode
I
CC3
P
mA
25
15
15
50
mA
I
C C 3
PS CKE & CLK
≤
V
IL
(max), t
CC
=
∞
I
CC3
N
CKE
≥
V
IH
(min), CS
≥
V
IH
(min), t
CC
= 10ns
Input signals are changed one time during 20ns
CKE
≥
V
IH
(min), CLK
≤
V
IL
(max), t
CC
=
∞
Input signals are stable
I
O
= 0 mA
Page burst
4Banks Activated
t
CCD
= 2CLKs
t
RC
≥
t
R C
(min)
-YL
mA
Active Standby Current
in non power-down mode
(One Bank Active)
I
CC3
NS
45
mA
Operating Current
(Burst Mode)
Refresh Current
I
CC4
230
210
210
mA
1
I
CC5
350
335
305
mA
2
3
Self Refresh Current
I
CC6
CKE
≤
0.2V
-YN
-YP
1800
uA
4
5
Notes :
1. Measured with outputs open.
2. Refresh period is 64ms.
3.
4.
5.
6.
K4S511633C-YL**
K4S511633C-YN**
K4S511633C-YP**
Unless otherwise noted, input swing IeveI is CMOS(V
IH
/V
IL
=V
DDQ
/V
SSQ)
Rev. 1.2 Dec. 2002
