TN6R04

Description
Switching Regulator IC for RCC Method Power Supplies Applications
CategoryPower/power management    The power supply circuit
File Size44KB,4 Pages
ManufacturerSANYO
Websitehttp://www.semic.sanyo.co.jp/english/index-e.html
Download Datasheet Parametric View All

TN6R04 Overview

Switching Regulator IC for RCC Method Power Supplies Applications

TN6R04 Parametric

Parameter NameAttribute value
MakerSANYO
Parts packaging codeTO-220F
package instruction,
Contacts3
Reach Compliance Codeunknow
ECCN codeEAR99
Other featuresALSO REQUIRES A NEGATIVE SUPPLY OF -10 TO -25V
Analog Integrated Circuits - Other TypesSWITCHING REGULATOR
Maximum input voltage25 V
Minimum input voltage10 V
JESD-30 codeR-XZFM-T5
Number of functions1
Number of terminals5
Maximum operating temperature125 °C
Minimum operating temperature-25 °C
Maximum output current16.5 A
Package body materialUNSPECIFIED
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Certification statusNot Qualified
surface mountNO
Switch configurationSINGLE
Maximum switching frequency200 kHz
Temperature levelOTHER
Terminal formTHROUGH-HOLE
Terminal locationZIG-ZAG
Ordering number : ENN7908
TN6R04
ExPD (Excellent Power Device)
TN6R04
Features
Switching Regulator IC for RCC
Method Power Supplies Applications
Original contorol IC for Delay RCC-type.
High voltage Power MOSFET with current sense.
Overload protection.
Only few external components required.
Small Full-Isolation package : TO-220FI5H.
Specifications
Absolute Maximum Ratings
at Ta=25°C
Parameter
Drain-to-Source Voltage
Drain Current (DC)
Drain Current (Pulse)
IC Input Voltage
Allowable Power Dissipation
Operating Temperature
Junction Temperature
Storage Temperature
Symbol
VDS
ID
IDP
VIN
PD
Topr
Tj
Tstg
PW≤10µs, duty cycle≤1%
Conditions
Ratings
650
5.5
16.5
30
2.0
Tc=25°C
35
--25 to +125
150
--55 to +150
Unit
V
A
A
V
W
W
°C
°C
°C
Electrical Characteristics
at Ta=25°C
Parameter
[MOSFET]
Drain-to-Source Breakdown Voltage
Zero-Gate Voltage Drain Current
Cutoff Voltage
Static Drain-to-Source On-State Resistance
Input Capacitance
Output Capacitance
[IC]
Restriction of Drive Voltage
Detection Voltage of Feedback and
Overload Amplifier
VIN(OV)
VFB
IIN=1mA, VFB=0
VDELAY, VIN=10V, IIN=50mA
30
2.0
V
V
V(BR)DSS
IDSS
VGS(off)
RDS(on)
Ciss
Coss
ID=1mA, VDELAY=0
VDS=650V, VDELAY=0
VDS=10V, ID=1mA
ID=2.8A, VDELAY=15V
VDS=20V, f=1MHz
VDS=20V, f=1MHz
650
1.0
3.0
1.2
1450
250
4.0
1.6
V
mA
V
pF
pF
Symbol
Conditions
Ratings
min
typ
max
Unit
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft's
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
71504 TS IM TB-00000234 No.7908-1/4
