TRG500
S
E
R
I
E
S
Specifications
INPUT SPECIFICATIONS:
Voltage ......................................................................................90 ~ 264Vac
Frequency .....................................................................................47 to 63Hz
Input Current .................................................................................0.5A max.
Inrush Current.................................................................40A max. @240Vac
Isolation ............................................................ lnput to output =4,242VDC
Leakage Current.......................................................................0.25mA max
TRG500 Series Derating Curve
100%
80%
60%
20LFM(Natural Convection)
40%
20%
0%
0
10
20
30
40
50
60
Ambient Temperature(˚C)
6W SWITCHING
ADAPTER
OUTPUT SPECIFICATIONS:
Holdup Time ..................................................................10mS typ. @115Vac
Over Voltage Protection….......................................................................Yes
ENVIRONMENTAL CHARACTERISTICS:
Operating Temperature .................................................................
0 ~ 40˚C
Storage Temperature ...................................................................-20
~ 85˚C
Cooling..........................................................................Natural Convection
Features
NOTE:
1. Voltage setpoint at 60% full load.
2. Add a 0.1µF ceramic capacitor and a 10µF E.L. capacitor to output for Ripple &
• Universal Input Range 90-264VAC
• Meets EN55022 Class B and
CISPR/FCC Class B, Conducted
Ordering information
TRG5XX
-
X
-
XX
X
XX
• Continuous Short Circuit Protection
• Over Voltage Protection
• CEC Level IV Compliant
(Output Cable Lengt 1800mm)
MECHANICAL CHARACTERISTICS:
Dimensions ............72.00 x 52.00 x 35.00mm(2.835 x 2.047 x 1.378 Inches)
Weight ..............................................................................135g (0.30Pounds)
Noise measurement @20MHz BW.
3. Line regulation measured from 100Vac to 240Vac, full load.
4. Load regulation measured from 60% to full load and from 60% to 20% load
(60% +/- 40% load)
Mechanical Specification
All Dimensions In Inches(mm)
Tolerance
Inches: x.xxx= ±0.02
Millimeters: x.xx= ±0.5
Model No.
AC Plug Type
A : USA 2 Pin
E : Europe 2 Pin
U : British 3 Pin
S : Australia 2 Pin
DC Plug Type
* Please see
Page235 for
more detailed
descriptions
OVP
E : With OVP
DC Cable Length and Type
01 : 720mm
02 : 1200mm
03 : 1800mm
11 : 720mm with Ferrite Core
12 : 1200mm with Ferrite Core
13 : 1800mm with Ferrite Core
* 20AWG / UL2468
FIG.A
2.047 (52.00)
FIG.E
0.539 (13.70) ± 0.027 (0.70)
MODEL
TRG501
12V
500mA
0A
1%
± 3%
± 1%
± 2%
120~144KHz Typ.
68% Typ.
TRG502
10V
600mA
0A
1%
± 3%
± 1%
± 2%
120~144KHz Typ.
68% Typ.
70.866 (1800.00) ± 1.969 (50.00)
0.500 (12.70) ± 0.011(0.30)
0.669 (17.00) ± 0.031 (0.80)
1.378 (35.00)
3.529 (89.65)
2.047 (52.00)
0.748 (19.00) ± 0.011(0.30)
2.835 (72.00)
2.713 (68.91)
OUTPUT
VOLTAGE
MAX.
LOAD
MIN.
LOAD
RIPPLE &
NOISE
VOLTAGE
LINE
LOAD
SETPOINT REGULATION REGULATION
SWITCHING
FREQUENCY
%EFF
2.835 (72.00)
70.866 (1800.00) ± 1.969 (50.00)
TRG503
9V
650mA
0A
1%
± 3%
± 1%
± 2%
120~144KHz Typ.
68% Typ.
1.378 (35.00)
0.688 (17.50) ± 0.019 (0.50)
TRG506
8V
650mA
0A
1%
± 3%
± 1%
± 3%
120~144KHz typ.
67% Typ.
FIG.S
2.047 (52.00)
FIG.U
2.047 (52.00)
TRG507
7.5V
650mA
0A
1%
± 3%
± 1%
± 3%
120~144KHz typ.
67% Typ.
2.835 (72.00)
3.307 (84.00)
2.835 (72.00)
TRG508
7.0V
650mA
0A
1%
± 3%
± 1%
± 3%
120~144KHz typ.
67% Typ.
70.866 (1800.00) ± 1.969 (50.00)
3.396 (86.26)
70.866 (1800.00) ± 1.969 (50.00)
TRG510
6.5V
650mA
0A
1%
± 3%
± 1%
± 3%
120~144KHz typ.
67% Typ.
0.342 (8.68) ± 0.019 (0.50)
MAX0.372 (9.45)
1.378 (35.00)
0.669 (17.00) ± 0.011 (0.30)
1.378 (35.00)
0.692 (17.60) ± 0.023 (0.60)
TRG511-1
6.0V
1000mA
0A
1%
± 3%
± 1%
± 4%
120~144KHz typ.
67% Typ.
TRG513-1
5.0V
1200mA
0A
1%
± 3%
± 1%
± 4%
120~144KHz typ.
66% Typ.
Typical at 25˚C, nominal line and 75% load, unless otherwise Specified
T R G 5 0 0
Short Circuit Protection ................................Continuous (Auto Recovery)
