China Electronics Technology Group Corporation
No.26 Research Institute
70MHz SAW Filter
7MHz Bandwidth
Part Number: LBN70A52
www. sipatsaw.com
SIPAT Co., Ltd.
Features
For IF SAW filter
High attenuation
Single-ended operation
No matching required for operation at 50Ω
Dual In-line Package
RoHS compliant (2002/95/EC), Pb-free
Specifications
Parameter
Center Frequency
Insertion Loss
1 dB Bandwidth
3 dB Bandwidth
40 dB Bandwidth
Passband Variation
Absolute Delay
Group Delay(f0±3MHz)
Ultimate Rejection
Material Temperature coefficient
Substrate Material
Ambient Temperature
Operating Temperature Range
Storage Temperature Range
DC Voltage
Input Power
ESD Class
Package Size
Notes:
1.
2.
3.
4.
All specifications are based on the test circuit shown;
In production, all specifications are measured by Agilent Network analyzer and full 2 port calibration at room
temperature;
Electrical margin has been built into the design to account for the variations due to temperature drift and
manufacturing tolerances;
This is the optimum impedance in order to achieve the performance show.
Unit
MHz
dB
MHz
MHz
MHz
dB
usec
nsec
dB
KHz/°C
-
°C
°C
°C
V
dBm
-
Minimum
69.96
-
7.14
-
-
-
-
-
40
Typical
70
22.6
7.15
7.32
7.95
0.8
3.81
130
50
-6.58
YZ LN
25
Maximum
70.04
25
-
-
8.02
1
-
200
-
-40
-45
-
-
-
0
-
1
+85
+105
10
DIP3512 (35.0x12.8x4.7mm3)
SIPAT Co., Ltd.
( CETC No.26 Research Institute )
#14 Nanping Huayuan Road,
Chongqing, China, 400060
Tel: +86-23-62808818
Part Number
Rev. Date
Ver.
LBN70A52
2007-12-17
1.0
Page
1/3
Fax: +86-23-62808382
www.sipatsaw.com / sawmkt@sipat.com
China Electronics Technology Group Corporation
No.26 Research Institute
70MHz SAW Filter
7MHz Bandwidth
Part Number: LBN70A52
www. sipatsaw.com
SIPAT Co., Ltd.
Matching Configuration
Source/Load Impedance=50 ohm
INPUT
50
Ω
OUTPUT
50
Ω
Notes - Component values may change depending
on board layout.
Package Dimension
35.00 0.5
Pad Configuration:
SIPAT
LBN70A52
07XX
Input
Output
1
5
12.80 0.5
4.7
4.5
Ground All Others
Marking Configuration:
1) SIPAT: Manufacturer Name
2) LBN70A52: Part Number
3) 07XX: Date Code
0.45 0.05
2.54 0.2
7.62 0.2
3
6
Package: DIP3512
SIPAT Co., Ltd.
( CETC No.26 Research Institute )
#14 Nanping Huayuan Road,
Chongqing, China, 400060
Tel: +86-23-62808818
2
1
4
5
25.40 0.2
2.54 0.2
Unit: mm
Part Number
Rev. Date
Ver.
LBN70A52
2007-12-17
1.0
Page
2/3
Fax: +86-23-62808382
www.sipatsaw.com / sawmkt@sipat.com
China Electronics Technology Group Corporation
No.26 Research Institute
70MHz SAW Filter
7MHz Bandwidth
Part Number: LBN70A52
www. sipatsaw.com
SIPAT Co., Ltd.
Typical Performance
Frequency Respond
Type Performance
-12.6279
-22.6279
-32.6279
-22.1279
-21.1279
Passband Respond
-21.6279
-42.6279
Magnitude(dB)
-52.6279
-62.6279
-72.6279
-82.6279
-24.1279
-22.6279
-23.1279
-23.6279
-92.6279
-102.6279
-112.6279
55
60
65
70
Frequency(MHz)
75
80
85
-24.6279
-25.1279
65
66
67
68
69
70
71
72
73
74
75
Horizontal: 5MHz/Div
Vertical: 10dB/Div
Horizontal: 1MHz/Div
Vertical: 0.5dB/Div
Group Delay Variation(f0±3MHz)
Type Performance
4100
15
Phase Linearity(f0±3MHz)
Type Performance
4000
10
3900
X: 70
Y: 3803
X: 73
Y: 3804
5
X: 67
Y: 2.285
X: 73
Y: 0.5084
Group Delay Time(ns)
Degree(deg)
3800
X: 67
Y: 3780
0
X: 70
Y: -1.581
-5
3700
-10
3600
-15
3500
-20
3400
64
66
68
70
Frequency(MHz)
72
74
76
64
66
68
70
Frequency(MHz)
72
74
76
Horizontal: 2MHz/Div
Vertical: 100ns/Div
Horizontal: 2MHz/Div
Vertical: 5deg/Div
Smith Chart S11
+j1.0
+j0.5
+j2.0
Smith Chart S22
+j1.0
+j0.5
+j2.0
+j0.2
+j5.0
+j0.2
+j5.0
0.2
0.5
1.0
2.0
5.0
0.2
0.5
1.0
2.0
0.0
∞
0.0
5.0
∞
-j0.2
-j5.0
-j0.2
-j5.0
-j0.5
-j1.0
-j2.0
-j0.5
-j1.0
-j2.0
SIPAT Co., Ltd.
( CETC No.26 Research Institute )
#14 Nanping Huayuan Road,
Chongqing, China, 400060
Tel: +86-23-62808818
Part Number
Rev. Date
Ver.
LBN70A52
2007-12-17
1.0
Page
3/3
Fax: +86-23-62808382
www.sipatsaw.com / sawmkt@sipat.com
