Multi-layers Chip Inductors--
TF2012 (0805) series--Ceramic
A.
Electrical specifications:
Part
No.
TF201209-1N5S
TF201209-1N8S
TF201209-2N2S
TF201209-2N7S
TF201209-3N3
TF201209-3N9
TF201209-4N7
TF201209-5N6
TF201209-6N8
TF201209-8N2
TF201209-10N
TF201209-12N
TF201209-15N
TF201209-18N
TF201209-22N
TF201209-27N
TF201209-33N
TF201209-39N
TF201209-47N
TF201209-56N
TF201209-68N
TF201209-82N
TF201209-R10
TF201212-R12
TF201212-R15
TF201212-R18
TF201212-R22
TF201212-R27
TF201212-R33
TF201212-R39
TF201212-R47
L (nH)
@100MHz
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100
120
150
180
220
270
330
390
470
Tolerance
S
S
S
S
S, K
S, K
S, K
S, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
Q min.
@100MHz
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
Q Typical
@100MHz
@800MHz
13
13
13
12
13
15
15
15
15
15
16
16
17
17
17
18
18
18
18
19
19
20
18
19
20
20
20
20
20
20
19
40
45
48
36
56
54
50
53
51
53
45
48
48
43
47
38
35
40
33
31
28
9
-
-
-
-
-
-
-
-
-
SRF min.
(MHz)
6000
6000
6000
6000
6000
5400
4500
4000
3650
3000
2500
2450
2000
1750
1700
1550
1350
1300
1200
1150
1000
850
730
650
550
500
450
400
380
330
300
DCR
(Max)
Ω
0.10
0.10
0.10
0.10
0.13
0.15
0.20
0.23
0.25
0.28
0.30
0.35
0.40
0.45
0.50
0.55
0.60
0.65
0.70
0.75
0.85
0.90
1.0
1.3
1.5
1.8
2.0
2.5
3.0
3.5
4.0
I rms.
(mA)
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
250
250
250
200
200
150
150
100
B.
Dimensions: [Unit: mm /(inch)]
P/N & Package Size
TF201209 (0805)
TF201212 (0805)
A
2.0 ± 0.2 (0.079 ± 0.008)
2.0 ± 0.2 (0.079 ± 0.008)
B
1.2 ± 0.2 (0.047 ± 0.008)
1.2 ± 0.2 (0.047 ± 0.008)
C
0.9 ± 0.2 (0.035 ± 0.008)
1.2 ± 0.2 (0.047 ± 0.008)
D
0.5 ± 0.3 (0.020 ± 0.012)
0.5 ± 0.3 (0.020 ± 0.012)
C.
Part Number Key & Mechanical drawing:
D.
1.
2.
3.
4.
5.
Features:
Tolerance: K: ± 10%, J: ± 5%, D: ± 0.5nH, S: ±0.3nH.
The product’s material:
Ceramic.
No cross coupling between inductors due to magnetic shield. Ideal for high-density installation.
Superior Q characteristics guaranteed over the wide frequency and allow high frequency application.
The completely monolithic structure gives high reliability and allows high SRF.
6.
7.
8.
Operating temperature range: -25ºC to +85ºC, both flow and IR re-flow application is possible.
Inductance Range:
*TF2012 (0805) Series: Multi-layer Ceramic Chip Inductor, from 1.5 nH (300 mA) to 470.0 nH (100 mA)
RoHS
compliant.
Rev. A
Jan. 01, 2006. Page: 1 of 1
