INFRARED DETECTOR
Infrared detector module with preamp
Non-cooled Type
Easy-to-use detector module with built-in preamp
These Infrared detector modules with preamp are designed to operate at room temperatures by just connecting to a DC power supply. The
detector element is selectable from among InGaAs, PbSe and Ge. B7506-01 detector is especially suited for CO
2
laser detection. We welcome
requests for custom devices that suit your application.
Features
Applications
l
Compact size
l
Infrared detection
l
Easy-to-use
l
CO
2
laser detection
Operates just by connecting to DC power supply
l
Circuit design optimized for detector element characteristics
Accessories (Optional)
l
Power supply for non-cooled type (±15 V)
Accessories (Supplied)
C3871
l
4-conductor cable for non-cooled type (for connection to DC
power supply): 2 m (connector installed on one end) A4372-02
l
Instruction manual
s
Specifications / Absolute maximum ratings
Type No.
Detector
element
Active area
External
input voltage
Current
consumption
(mm)
(V)
(mA)
G6121
InGaAs
±15
φ5
-
P4245
PbSe
3×3
±15
±15
B7506-01
Photon drag
+30, -10
1
φ4.6
* Light level at which photon drag detector temperature does not exceed 60 °C
Absolute maximum ratings
Incident light level *
Operating
Storage
temperature temperature
Pulse light
CW light
Topr
Tstg
2
(MW)
(J/cm )
(°C)
(°C)
-
1
0 to +40
-20 to +50
s
Electrical and optical characteristics (Typ.)
Type No.
Measurement
Peak
condition
sensitivity
Element
wavelength
temperature
λp
T
(°C)
(µm)
1.55
25
4.0
10.6
Cut-off
wavelength
λc
(µm)
1.7
4.8
-
sensitivity
S
λ=λp
(V/W)
1 × 10
6
5 × 10
4
0.013
NEP
(W/Hz
1/2
)
5 × 10
-13
2 × 10
-10
3 × 10
-2
Frequency
response
-3 dB
(Hz)
DC to 8 k
0.2 to 10 k
50 to 500 k
Output
impedance
(Ω)
50
Output
voltage
R
L
=1 kΩ
(V)
+10
±10
±10
G6121
P4245
B7506-01
Infrared detector module with preamp
s
Spectral response
10
13
Non-cooled type
(Typ. T=25 ˚C)
10
12
G6121
D* (cm · Hz
2
/W)
λ
10
11
1
10
10
10
9
P4245
10
8
1
2
3
4
5
6
WAVELENGTH (µm)
KIRDB0187EA
s
Dimensional outlines (unit: mm)
G6121, P4245
PHOTOSENSITIVE
SURFACE
Dimensional outline (B7506-01, unit: mm)
7 20 ± 0.2
B7506-01
(4 ×) M3 THREADED HOLE, DEPTH: 2
(WITH HELICAL INSERT)
FOR HEATSINK INSTALLATION
48 ± 1.5
(4
×)
2.8 CS5
(FOR M2.6 FLAT
HEAD SCREW)
ACTIVE AREA
(4
×)
M2.6 DEPTH 5
(MOUNTING THREADED HOLE)
4-PIN CONNECTOR
(VOLTAGE INPUT)
10.2
23.2
33.5
20 ± 0.2
WINDOW
4.6 ± 0.2
107.5
32
18.2
26
35
20
36.5
13.2 ± 0.5
PHOTOSENSITIVE
SURFACE
3.1 ± 0.5
(5 ×) M3 THREADED HOLE, DEPTH 5
(MOUNTING THREADED HOLE)
4-PIN CONNECTOR
(±15 V)
26
35
0.9 MAX.
41
BNC CONNECTOR
2
(SIGNAL OUTPUT)
KIRDA0008ED
24 ± 0.2
15
25
60
s
Output waveform example (B7506-01)
Input beam
Peak power
Repetition rate
Pulse width
CO
2
laser
45 W
100 Hz
200 µs
KIRDA0136EA
Information furnished by HAMAMATSU is believed to be reliable. However, no responsibility is assumed for possible inaccuracies or omissions.
Specifications are subject to change without notice. No patent rights are granted to any of the circuits described herein. ©2001 Hamamatsu Photonics K.K.
HAMAMATSU PHOTONICS K.K., Solid State Division
1126-1 Ichino-cho, Hamamatsu City, 435-8558 Japan, Telephone: (81) 053-434-3311, Fax: (81) 053-434-5184, http://www.hamamatsu.com
U.S.A.: Hamamatsu Corporation: 360 Foothill Road, P.O.Box 6910, Bridgewater, N.J. 08807-0910, U.S.A., Telephone: (1) 908-231-0960, Fax: (1) 908-231-1218
Germany: Hamamatsu Photonics Deutschland GmbH: Arzbergerstr. 10, D-82211 Herrsching am Ammersee, Germany, Telephone: (49) 08152-3750, Fax: (49) 08152-2658
France: Hamamatsu Photonics France S.A.R.L.: 8, Rue du Saule Trapu, Parc du Moulin de Massy, 91882 Massy Cedex, France, Telephone: 33-(1) 69 53 71 00, Fax: 33-(1) 69 53 71 10
United Kingdom: Hamamatsu Photonics UK Limited: 2 Howard Court, 10 Tewin Road, Welwyn Garden City, Hertfordshire AL7 1BW, United Kingdom, Telephone: (44) 1707-294888, Fax: (44) 1707-325777
North Europe: Hamamatsu Photonics Norden AB: Smidesvägen 12, SE-171 41 Solna, Sweden, Telephone: (46) 8-509-031-00, Fax: (46) 8-509-031-01
Italy: Hamamatsu Photonics Italia S.R.L.: Strada della Moia, 1/E, 20020 Arese, (Milano), Italy, Telephone: (39) 02-935-81-733, Fax: (39) 02-935-81-741
Cat. No. KIRD1035E02
May 2001 DN
