SIPAT Co.,Ltd
Specifications
Parameter
Center Frequency
Insertion Loss
1 dB Bandwidth
3 dB Bandwidth
40 dB Bandwidth
50 dB Bandwidth
Passband Variation
Absolute Delay
Ultimate Rejection
Subatrate Material
Ambient Temperature
Package Size
°C
DIP3512
www.sipatsaw.com
China Electronics Technology Group Corporation No.26 Research Institute
LBN06005 SAW Filter Electrical Characteristic
Unit
MHz
dB
MHz
MHz
MHz
MHz
dB
usec
dB
Minimum
59.9
-
18.9
19.2
-
-
-
-
50
Typical
60
23.3
18.96
19.23
20.11
20.19
0.8
3.23
53
128 LiNbO3
25
(35.0x12.7x5.2mm
3
)
Maximum
60.1
25
-
-
20.25
20.35
1.0
3.5
-
Typical Performance
-23.3145
-33.3145
-43.3145
Magnitude(dB)
-53.3145
-63.3145
-73.3145
-83.3145
-93.3145
-103.3145
40
45
50
55
60
65
Frequency(MHz)
70
75
80
Package Outline
Matching Configuration
L1=162nH
L2=180nH
C1=51pF
Source/Load Impedance=50 ohm
Notes - Component values may change depending
on board layout.
P.O. Box 2513 Chongqing, China 400060 Tel:+86-23-62920684 Fax:62805284 E-mail: sawmkt@sipat.com
