Liquid Tight Cordgrips
Heyco -Tite
EMC-2 Brass Liquid Tight Cordgrips
Straight-Thru, Metric Hubs
EMC Nickel-Plated Brass with Contact Sleeve
The Ultimate in Liquid Tight Strain Relief Protection
•
Ideal for applications where
Electromagnetic Interference (EMI)
protection or Electromagnetic
Compatibility (EMC) is needed.
•
Innovative contact spring,
due to
strong clamping, virtually guarantees
a secure shielded tap connection.
•
Contact spring can be precisely
positioned due to its clearly defined
limit stop, making installation simple.
•
Clamping technique ensures the cable
can be rotated, pushed and easily
dismantled during mounting.
•
Excellent 360° shield contact with
contact sleeve due to braided
shield which runs into the gland.
•
Combination of the sealing insert and
the contact socket guarantees a
constant contact quality with minimal
transfer impedance.
•
For use in clearance or threaded holes.
•
EMC Locknuts available see page 3-40.
•
DFARS Compliant
CABLE DIA. RANGE
Minimum
in.
.138
.197
.236
.315
.492
.669
.138
.197
.236
.315
.492
.669
mm.
3,5
5,0
6,0
8,0
12,5
17,0
3,5
5,0
6,0
8,0
12,5
17,0
Maximum
in.
.197
.256
.413
.591
.807
1.004
.197
.256
.413
.591
.807
1.004
mm.
5,0
6,5
10,5
15,0
20,5
25,4
5,0
6,5
10,5
15,0
20,5
25,5
4594
4595
4596
4597
4598
4599
14594
14595
14596
14597
14598
14599
PART
NO.
THREAD
SIZE
or
A
Clearance
Hole Dia.
in. mm.
PART DIMENSIONS
B
C
D
Max. O.A.
Thread
Wrenching Nut
Length
Length
Flat Size
in. mm.
in. mm.
in.
mm.
®
Standard Thread
M12 x 1,5
M16 x 1,5
M20 x 1,5
M25 x 1,5
M32 x 1,5
.472 12,0
.643
.747
.984
1.260
16,0
20,0
25,0
32,0
1.26
1.38
1.46
1.73
1.81
32,0
35,0
37,0
44,0
46,0
.39
.39
.39
.43
.51
10,0
10,0
10,0
11,0
13,0
.59
.71
.94
1.18
1.42
15,0
18,0
24,0
30,0
36,0
Short Thread —
ALL NEW PRODUCTS!
M12 x 1,5
M16 x 1,5
M20 x 1,5
M25 x 1,5
M32 x 1,5
.472 12,0
.630
.787
.984
1.260
16,0
20,0
25,0
32,0
1.06
1.18
1.30
1.57
1.61
27,0
30,0
33,0
40,0
41,0
.20
.20
.24
.28
.31
5,0
5,0
6,0
7,0
8,0
.59
.71
.94
1.18
1.42
15,0
18,0
24,0
30,0
36,0
B
C
A
D
3-39
Quick
Specs
Material
Certifications
Temperature Range
IP Rating
Nickel-Plated Brass W/TPE Sealing Gland
Recognized under the Component Program of Underwriters’ Laboratories
File E51579 to both Canadian and U.S. requirements
-40°F (-40°C) to 212°F (100°C)
IP 68, IP 69K
