1. PHYSICAL DIMENSIONS
65.0 ± 0.5
63.5 ± 0.5
REVISION
REV.
B
C
DESCRIPTION
RoHS Compliancy
Updated Dim & Fuse Changed to 5x20mm Size Only
DATE
06-01-06
09-13-16
APPROVED
DP
LY
ELECTRICAL CHARACTERISTICS:
1-1.
VOLTAGE RATING...................................115/250VAC
60.2 ±
0.5
0
1-2.
CURRENT RATING
A. @ 115 VAC..........................................6 A RMS MAX
B. @ 250 VAC.........................................6 A RMS MAX
OPERATING FREQUENCY......................50/60Hz
LEAKAGE CURRENT: EACH LINE TO GROUND
A. @ 115 VAC 60Hz............................0.25 mA MAX
B. @ 250 VAC 50Hz.............................0.45 mA MAX
HIPOT RATING (FOR ONE MINUTE)
A. LINE TO GROUND...........................2250 VDC
B. LINE TO LINE.....................................1450 VDC
MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM)
.01
/
/
.05
10
2
.10
15
5
.15
20
8
.50
30
20
1.0
35
30
5.0
45
30
10
40
40
30
30
40
50.0 ± 0.5
40.0 ± 0.5
28.4 ± 0.5
40.0 ± 0.1
29.0 ±
0.5
0
1-3.
1-4.
M3(2X) PANEL CUTOUT R2.5MAX (4X)
1-5.
1-6.
FREQ. MHz
COM. MODE dB
DIF. MODE dB
88.0 ± 1.0
82.5 ± 0.8
1-7.
OPERATING TEMPERATURE.................-25° TO +100° C
(DERATING ABOVE 40˚C)
SAFETY:
FUSE SIZE 5x20mm (FUSES NOT INCLUDED)
RoHS COMPLIANT
1-8.
1-9.
1-10.
Dim
range
(mm)
0-1
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
CONTROLLED
Qualtek Electronics Corp.
PPC DIVISION
864-06/005
EMI FILTER
UNIT: mm
REV. C
Approved / Date
JJH / 01-13-03
59.9 ± 0.3
2. ELECTRICAL SCHEMATIC
6.3x0.8(5X)
28.2 ± 0.8
Part Number:
Description:
L:
C1:
C2:
R:
2.5mH
0.22uF
3300pF
1MΩ
1-6
6-18
18-50
50-120
120-250
250-500
Drawn / Date
B.ZHANG
01-13-03
Checked / Date
01-13-03
