MW122
M E D I C A L 1 2 0 W AT T S E R I E S
MW122 SWITCH-MODE
P O W E R S U P P LY
•
•
•
•
•
•
•
•
•
•
•
MW122
Ault Part No.
Voltage
DC
Max
Amps
Max
Watts
100-240 VAC Universal Input
Desktop Style
Single Output to 120W
Regulated Output With Low Ripple
Meets Medical Safety Agency Requirements
Complies With EMI/RFI Regulations
CE Compliant
Impact Resistant Polycarbonate Enclosure
Private Label Marking Available
3 Year Warranty
Modified and Custom Designs Also
Available
MW122RA12XXF01
MW122RA24XXF01
12V
24V
10
5
120
120
Ault Part No. Key
Ault Part No. Key
MW122 R
Product
Family
Name
Manufacturing
Location
(volume
dependent)
A
Design
Revision
Changes
12
Voltage
DC
XX
Connector
#51 - Standard
for12V model;
Connector
#3 -Standard
for 24V model.
__
Input
Configuration/
Model Type
(see pg. 2)
01
Standard (no
modifications,
special artwork
or special
packaging)
A U LT I N C O R P O R AT E D
7105 Northland Terrace
|
Minneapolis, Minnesota 55428
|
USATEL (1) 763-592-1900
FAX (1) 763-592-1911
|
E-MAIL info@aultinc.com
|
WEB www.aultinc.com
© Copyright 2004 Ault Inc.
MW122
Input
Rated Voltage
Operating Voltage
Line Frequency
Current
Protection
Power Factor Correction
Provided
90-264 VAC
47-63 Hz
M E D I C A L 1 2 0 W AT T S E R I E S
Electrical
100-240 VAC +/–10%
Efficiency
Dielectric Withstand
86% Typical
4000 VAC, 5600 VDC primary-secondary
1500 VAC, 2150 VDC primary-ground
500 VDC secondary-ground
Complies with EMC Directives
CE Compliant
Min. 100,000 Hours
2A max. at 90 VAC input
Dual internal primary current fuse
Complies with EN61000-3-2 and
EN61000-3-3
EMI
CE
MTBF
Output
Combined Line and Load
Voltage Regulation
Ripple
Transient Response
Holdup Time
Protection
Cord and Connector
±1% excluding cord
mVp-p 1% max
0.5 msec. for 50% load change typical
16 msec min. over entire input range
Overcurrent protection.
Short circuit protection.
12V:
5 ft., 4 conductor, 18AWG, #51
connector, Pinout Pins 1-4 = +V. 3,6 =
common with overmolded Ferrite core.
24V:
5 ft., 2 conductor, 18AWG, with
overmolded Ferrite core, #03 connector,
center positive.
Environmental
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
Cooling
0º to 40ºC with no derating
-30º to +85ºC
5% to 95% non-condensing
0-10,000 feet
Convectional - non vented case
Mechanical
Case and Dimensions
Case Material
Weight
9.0L x 2.9W x 2.0H (in)
229L x 74W x 51H (mm)
Black 94V0 polycarbonate
24 ounces, 684 grams (excluding cord)
Safety Approvals
Agency Listings
cURus2601, TUV/IEC EN60601-1
Connector
Input Configuration
IEC320
w/ground
C14
(F)
Pinout Code
w
Center contact: positive
Switchcraft 760 plug or equivalent
Switchcraft 712A jack or equivalent
Description
Suggested Mating
Other Connectors are available by special order
Pinout Code
Description
Suggested Mating
Molded Mini Fit Receptacle
Overmolded by Ault 6 pos, Molex 39-01-
2060 max. wire 18AWG or equivalent
Plug Molex 39-01-2060 or 3063
Other Connectors are available by special order
A U LT I N C O R P O R AT E D
7105 Northland Terrace
|
Minneapolis, Minnesota 55428
|
USATEL (1) 763-592-1900
FAX (1) 763-592-1911
|
E-MAIL info@aultinc.com
|
WEB www.aultinc.com
© Copyright 2004 Ault Inc.
