600 W PS/2 Type ATX Power Supply
w w w.ieiworld.com
ACE-4860AP
600W
90 ~ 264 VAC Full Range
47 ~ 63 Hz
12 A (RMS)@115 VAC, 6 A (RMS)@230VAC
60 A max for 115 VAC, 150 A max for 230 VAC
Min. load
0A
1A
1A
0.5 A
0A
0A
0A
0A
Max. load
30 A
12 A
12 A
18 A
18 A
1A
24 A
3A
Ripple & Noise
50 mV P-P
120 mV P-P
120 mV P-P
120 mV P-P
120 mV P-P
120 mV P-P
50 mV P-P
50 mV P-P
Specifications
Voltage
Input
Frequency
Input Current
Inrush Current
Voltage
+5 V
+12 V1
+12 V2
+12 V3
+12 V4
PFC
CB
Output
Features
1. 600 W for high power consumption RAID / multi-core system
2. High efficiency
3. ATX 2.0 standard with new 20+4-pin ATX power and SATA connector design
4. Overvoltage and overcurrent protection
5. 100% Hi-pot tested
6. Multiple safety and EMC certifications
7. Total +12 V output up to 40 A
-12 V
+3.3 V
+5 Vsb
Over Voltage
Protection
Short Circuit
Protection
Watt
PFC
+12 V: 14.6 V ±10%
+5 V: 6.2 V ±10%
+3.3 V: 4 V ±10%
+3.3 V, +5 V, +12 V shut down and latch off
600 W
Active
16 ms Min.
70%
100,000 hours
Operating: 0 ~ 50°C (40 ~ 50°C derating curve)
Storage: -40 ~ 70°C
140 x 150 x 86 (mm), 5.51 x 5.91 x 3.39 (inch)
1 x 20+4-pin ATX, 1 x 4-pin 12 V CPU, 9 x HDD/
CDROM, 1 x FDD, 2 x SATA
■
Power Connector +12 V
+12V1
CPU
Hold-up Time
Efficiency
General
Specifications
MTBF
+12V2
CPU
Temperature
Dimensions
Power Supply
+12V3
Motherborad
Output Connector
Ordering Information
+12V4
I/O
Part No.
ACE-4860AP-R11-RS
Description
600 W AC-DC PS/2 ATX power supply, with PFC
ACE-4840APM
400 W PS/2 Medical Type ATX Power Supply
400W
Medical
New Version 20+4
Pins Power Supply
Specifications
Input Voltage
Input Frequency
Input Current
Inrush Current
Output Voltage
90 ~ 265 VAC Full Range
47 ~ 63 Hz
8 A (RMS) for 115 VAC, 4 A (RMS) for 230 VAC
60 A MAX. for 115 VAC, 100A MAX. for 230 VAC
Voltage
+3.3 V
+5 V
+12 V1
+12 V2
-5 V
-12 V
+5 V sb
Min. load
0.5 A min
0.3 A min
1 A min
1 A min
Max. load
30 A
30 A
17 A
17 A
0.3 A
0.8 A
2A
Ripple & Noise
50 mV
50 mV
120 mV
120 mV
100 mV
120 mV
50 mV
PFC
PICMG1.0 Form Factor Backplane
Features
1. Internal 8 cm fan
2. Meets medical safety standards
3. Line input fuse protection
4. Output overvoltage protection
5. Short circuit protection on all outputs
6. Total +12 V output up to 34 A
20+4-pin ATX
power connector
PICMG1.3 Form Factor
Backplane PE-10S/6S
Overvoltage Protection
Hold Up Time
+3.3 V &+5 V total output not exceed 180 W
+3.3 V & +5 V & +12 V total output not exceed 380 W
+5 V
5.7 V ~ 6.5 V
+3.3 V
3.7 V ~ 4.5 V
+12 V
13.3 V ~ 15.6 V
20 ms min.
100,000 hours
0°C ~ 50°C
-20°C ~ 80°C
68%
140 mm x 150 mm x 86 mm
1 x 20+4-pin ATX, 1 x 4-pin 12V CPU, 5 x HDD/CDROM,
2 x FDD, 2 x SATA, 1 x Extra +5V (P10)
■
Power Connector +12 V
Power Supply
MTBF
Operating Temperature
Storage Temperature
Efficiency
Dimensions
Outline Connector
Ordering Information
+12V1
+12V2
Part No.
I/O
Description
400 W AC-DC PS/2 ATX Power Supply, meets Medical standard,
with PFC
CPU
Motherborad
ACE-4840APM-RS
ACE-4860AP-2013-V10
