440-069
EMI/RFI Banding and Shrink Boot Adapter
Self-Locking Rotatable Coupling - Standard Profile
TANDAR
O-Ring
.075 (1.9) Ref.
STYLE 2
(STRAIGHT
See Note 1)
1.00 (25.4)
Max
E Typ.
(Table I)
K*
L*
M*
* (Table IV)
.060 (1.5)
Anti-Rotation
Device (Typ.)
F
(Table III)
.380 (9.7)
H
(Table III)
G (Table III)
H
STYLE 2
(45° & 90°
See Note 1)
Termination Area
Free of Cadmium.
Knurl or Ridges
Mfr's Option
Band Option
(K Option Shown -
See Note 6)
Polysulfide Stripes
P Option
© 2011 Glenair, Inc.
Dimensions in inches (millimeters) and are subject to change without notice.
CAGE Code 06324
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
www.glenair.com
H-16
S
Adapters
CONNECTOR DESIGNATOR:
A
F
H
L
MIL-DTL-5015, -26482, Series II
and -83723 Series I and III
MIL-DTL-38999 Series I, II
MIL-DTL-38999 Series III and IV
LN29729
Angle and Profile
H
= 45°
J
= 90°
S
= Straight
Finish
B
= Cadmium Plate, Olive Drab
C
= Anodize, Black
G
= Hard Coat, Anodic
M
= Electroless Nickel
NF
= Cadmium Plate, Olive Drab
over Electroless Nickel
(See Page H-3)
Band
B
= Band
K=
Pre-Coiled Band
Shrink Boot
See Table IV
(Omit for None)
ROTATABLE COUPLING
SELF-LOCKING
440
Product
Series
F
S
069 M 20 12
-
8
-
B
Basic
Part Number
Shell
Size
See
Table
III
Cable
Entry
See
Table
IV
Length: S
ONLY
1/2-inch
increments
(e.g. 4 = 2
inches)
P
T
Connector
Designator
Polysulfide
(Omit for None)
Length ± .060 (1.52)
Min. Order Length 2.5 inch
Length **
A Thread
(Table I)
OT
D
BO
KI
T
.135 (3.4)
T
Add "T" to Part Number
for Standard Boot
J (Table III)
Printed in U.S.A.
E-Mail: sales@glenair.com
Self-Locking Rotatable Coupling - Standard Profile
See Pages H-2 and H-3 for unabridged Tables I and II, and Pages H-4 and H-5 for MIL-DTL-5015
TABLE III: Connector Designators and Dimensions
Shell Size - Conn. Desig.
A-F-L
H
08
10
12
14
16
18
20
22
24
28
32
36
40
09
11
13
15
17
19
21
23
25
F
Max
.806
.832
.856
.882
.908
.927
.953
.979
1.004
1.197
1.280
1.294
1.320
(20.5)
(21.1)
(21.7)
(22.4)
(23.1)
(23.5)
(24.2)
(24.9)
(25.5)
(30.4)
(32.5)
(32.9)
(33.5)
G
Max
1.038
1.064
1.088
1.114
1.150
1.190
1.250
1.320
1.380
1.500
1.620
1.750
1.870
(26.4)
(27.0)
(27.6)
(28.3)
(29.2)
(30.2)
(31.8)
(33.5)
(35.1)
(38.1)
(41.1)
(44.5)
(47.5)
H
Max
.906
.966
1.026
1.076
1.136
1.176
1.236
1.296
1.356
1.422
1.545
1.652
1.960
(23.0)
(24.5)
(26.1)
(27.3)
(28.9)
(29.9)
(31.4)
(32.9)
(34.4)
(36.1)
(39.2)
(42.0)
(49.8)
J
Max
1.146
1.210
1.268
1.330
1.392
1.438
1.500
1.562
1.625
1.654
1.777
1.844
2.070
(29.1)
(30.7)
(32.2)
(33.8)
(35.4)
(36.5)
(38.1)
(39.7)
(41.3)
(42.0)
(45.1)
(46.8)
(52.6)
TABLE IV: Cable Entry, Dimensions and Shrink Boot
Dash
No.
01
31
02
32
03
33
04
34
05
35
06
36
07
37
08
38
09
10
11
12
13
14
15
16
K
.125
.188
.250
.312
.375
.438
.500
.562
.625
.688
.750
.812
.875
.938
1.000
1.062
1.125
1.250
1.375
1.500
1.625
1.750
1.875
(3.2)
(4.8)
(6.4)
(7.9)
(9.5)
(11.1)
(12.7)
(14.3)
(15.9)
(17.5)
(19.1)
(20.6)
(22.2)
(23.8)
(25.4)
(27.0)
(28.6)
(31.8)
(34.9)
(38.1)
(41.3)
(44.5)
(47.6)
L
.250
.312
.375
.438
.500
.562
.625
.688
.750
.812
.875
.938
1.000
1.062
1.125
1.188
1.250
1.375
1.500
1.625
1.750
1.875
2.000
(6.4)
(7.9)
(9.5)
(11.1)
(12.7)
(14.3)
(15.9)
(17.5)
(19.1)
(20.6)
(22.2)
(23.8)
(25.4)
(27.0)
(28.6)
(30.2)
(31.8)
(34.9)
(38.1)
(41.3)
(44.5)
(47.6)
(50.8)
M
.312
.374
.437
.500
.562
.624
.687
.750
.812
.874
.937
1.000
1.062
1.124
1.187
1.250
1.312
1.437
1.562
1.687
1.812
1.937
2.062
(7.9)
(9.5)
(11.1)
(12.7)
(14.3)
(15.8)
(17.4)
(19.1)
(20.6)
(22.2)
(23.8)
(25.4)
(27.0)
(28.5)
(30.1)
(31.8)
(33.3)
(36.5)
(39.7)
(42.8)
(46.0)
(49.2)
(52.4)
Shrink Boot
Part Number
770-003S111
770-003S111
770-003S112
770-003S112
770-003S112
770-001S104
770-001S104
770-001S104
770-001S104
770-001S104
770-001S105
770-001S105
770-001S105
770-001S105
770-001S106
770-001S106
770-001S107
770-001S107
770-001S107
770-001S107
770-001S108
770-001S108
770-001S109
770-001S109
APPLICATION NOTES
1. Cable Entry is defined as the accomodation range
for the wire bundle or cable. Dimensions shown are
not intended for inspection criteria.
2. See Backshell Interface Dimensions and Standards
on Pages H-4 and H-5.
3. Metric dimensions (mm) noted in parentheses are
for reference only.
4. When maximum entry is exceeded, Style 2 will be
supplied and dimensions F, G, H and J will not apply.
Please consult factory.
5. Interface O-Ring not supplied with Connector
Designator A.
6. Backshells supplied with 600-052 Band. See Glenair
Series 600 Tool Catalog for installation details.
2.000 (50.8)
2.125 (54.0)
2.187 (55.5)
© 2011 Glenair, Inc.
www.glenair.com
Dimensions in inches (millimeters) and are subject to change without notice.
CAGE Code 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
H-17
Adapters
440-069
