142 RHS
www.vishay.com
Vishay BCcomponents
Aluminum Electrolytic Capacitors
Radial High Temperature Standard
FEATURES
• Useful life: 2500 h at 105 °C
• Miniaturized, high CV-product per unit volume
• Charge and discharge proof
• Polarized aluminum electrolytic capacitors, non-solid
electrolyte
• Radial leads, cylindrical aluminum case, insulated with a
blue sleeve
• Pressure relief for case Ø D
6.3 mm
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Longer life
038 RSU
105 °C
Lower Z
150 RMI
142 RHS
125 °C
Higher temperature
140 RTM
Lower Z
APPLICATIONS
• Industrial, telecom and domestic appliances
• Decoupling, smoothing, filtering, buffering in SMPS
146 RTI
• Portable and mobile equipment (small size, low mass)
Fig. 1
MARKING
QUICK REFERENCE DATA
DESCRIPTION
Nominal case sizes (Ø D x L in mm)
Rated capacitance range, C
R
Tolerance on C
R
Rated voltage range, U
R
Category temperature range
Endurance test at 105 °C
Useful life at 105 °C
Useful life at 40 °C, 1.6 x I
R
applied
Shelf life at 0 V, 105 °C
Based on sectional specification
Climatic category IEC 60068
VALUE
5 x 11 to 18 x 40
1 μF to 22 000 μF
± 20 %
10 V to 450 V
-40 °C to +105 °C
2000 h
2500 h
140 000 h
1000 h
IEC 60384-4 / EN130300
40 / 105 / 56
The capacitors are marked (where possible) with the
following information:
• Rated capacitance (in μF)
• Tolerance on rated capacitance, code letter in accordance
with IEC 60062 (M for ± 20 %)
• Rated voltage (in V)
• Date code, in accordance with IEC 60062
• Code indicating factory of origin
• Name or logo of manufacturer
• Negative terminal identification
• Series number (142)
Revision: 19-Sep-16
Document Number: 28402
1
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
142 RHS
www.vishay.com
Vishay BCcomponents
SELECTION CHART FOR C
R,
U
R
, AND RELEVANT NOMINAL CASE SIZES
(Ø D x L in mm)
C
R
(μF)
1.0
2.2
4.7
10
22
33
47
100
220
330
470
1000
2200
3300
4700
6800
10 000
22 000
U
R
(V)
10
6.3 x 11
8 x 12
10 x 12
10 x 20
12.5 x 25
16 x 25
16 x 31
18 x 40
16
5 x 11
6.3 x 11
8 x 12
10 x 12
10 x 16
12.5 x 20
12.5 x 25
16 x 25
16 x 31
18 x 31
-
25
5 x 11
6.3 x 11
8 x 12
10 x 12
10 x 20
12.5 x 25
16 x 25
16 x 31
18 x 35
-
-
35
5 x 11
6.3 x 11
8 x 12
10 x 12
10 x 16
12.5 x 20
16 x 25
16 x 31
18 x 35
-
-
-
50
5 x 11
6.3 x 11
8 x 12
10 x 12
10 x 16
12.5 x 20
12.5 x 25
16 x 35
18 x 35
-
-
-
-
63
5 x 11
5 x 11
6.3 x 11
6.3 x 11
8 x 12
10 x 12
10 x 16
10 x 20
12.5 x 20
16 x 25
18 x 40
-
-
-
-
-
100
5 x 11
6.3 x 11
8 x 12
8 x 12
10 x 12
10 x 16
10 x 20
12.5 x 25
16 x 25
16 x 31
18 x 40
-
-
-
-
-
-
SELECTION CHART FOR C
R,
U
R
, AND RELEVANT NOMINAL CASE SIZES
(Ø D x L in mm)
C
R
(μF)
1.0
2.2
4.7
10
22
33
47
100
220
U
R
(V)
200
5 x 11
6.3 x 11
8 x 12
10 x 12
10 x 16
12.5 x 20
16 x 25
18 x 35
250
5 x 11
6.3 x 11
8 x 12
10 x 12
10 x 20
12.5 x 20
12.5 x 25
16 x 31
-
350
6.3 x 11
8 x 12
10 x 12
10 x 16
12.5 x 20
16 x 25
18 x 35
-
400
6.3 x 11
8 x 12
10 x 12
10 x 20
12.5 x 25
16 x 31
18 x 40
-
450
8 x 12
10 x 12
10 x 16
12.5 x 20
16 x 20
16 x 25
16 x 35
-
-
Revision: 19-Sep-16
Document Number: 28402
2
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
142 RHS
www.vishay.com
DIMENSIONS
in millimeters
AND AVAILABLE FORMS
ØD
ØD
Vishay BCcomponents
L
F
15
min.
5
min.
4 +1
0
+
-
Ød
Ød
F
Fig. 2 -
Form CA
Long leads
Fig. 3 -
Form CB
Cut leads
Dimensions of lead space F see Table 2
Case Ø D = 5 mm to 8 mm;
Lead space F is 5 mm
Fig. 4 -
Form TNA, Form TFA
Taped in box (ammopack), straight leads
Fig. 5 -
Form TFA
Taped in box (ammopack), formed leads
Table 1
DIMENSIONS
in millimeters,
MASS AND PACKAGING QUANTITIES
NOMINAL
CASE SIZE
ØDxL
5 x 11
6.3 x 11
8 x 12
10 x 12
10 x 16
10 x 20
12.5 x 20
12.5 x 25
16 x 20
16 x 25
16 x 31
16 x 35
18 x 31
18 x 35
18 x 40
CASE
CODE
11
12
13
14
15
16
17
18
19a
19
20
21
1831
22
23
Ød
0.5
0.5
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
Ø D
max.
5.5
6.8
8.5
10.5
10.5
10.5
13.0
13.0
16.5
16.5
16.5
16.5
18.5
18.5
18.5
L
max.
12.5
12.5
13.0
13.5
17.5
22.0
22.0
27.0
22.0
27.0
33.5
37.5
33.5
37.5
42.0
F
2.0 ± 0.5
2.5 ± 0.5
3.5 ± 0.5
5.0 ± 0.5
5.0 ± 0.5
5.0 ± 0.5
5.0 ± 0.5
5.0 ± 0.5
7.5 ± 0.5
7.5 ± 0.5
7.5 ± 0.5
7.5 ± 0.5
7.5 ± 0.5
7.5 ± 0.5
7.5 ± 0.5
MASS
(g)
0.4
0.6
1.1
1.6
1.9
2.2
4.0
5.0
6.0
8.0
9.0
11.0
12.5
14.5
16.0
PACKAGING QUANTITIES
FORM
CA
5000
5000
5000
3000
2500
2000
1500
1000
1000
750
600
500
400
400
400
FORM
CB
-
-
-
1000
1000
800
400
400
200
200
200
200
150
150
150
FORM
TFA, TNA
2000
2000
1000
500
500
500
300
300
200
200
200
-
-
-
-
Note
• For detailed tape dimensions please refer to packaging information:
www.vishay.com/doc?28360
Revision: 19-Sep-16
Document Number: 28402
3
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
142 RHS
www.vishay.com
Vishay BCcomponents
ORDERING EXAMPLE
Electrolytic capacitor 142 series
470 μF / 25 V; ± 20 %
Nominal case size: Ø 10 mm x 12 mm; Form TFA
Ordering Code: MAL214236471E3
ELECTRICAL DATA
SYMBOL
C
R
I
R
I
L2
I
L5
tan
DESCRIPTION
Rated capacitance at 100 Hz, tolerance ± 20 %
Rated RMS ripple current at 100 Hz, 105 ºC
Max. leakage current after 2 min at U
R
= 10 V to 100 V
Max. leakage current after 5 min at U
R
= 200 V to 450 V
Max. dissipation factor at 100 Hz
Note
• Unless otherwise specified, all electrical values in Table 2 apply
at T
amb
= 20 °C, P = 86 kPa to 106 kPa, RH = 45 % to 75 %.
Table 2
ELECTRICAL DATA AND ORDERING INFORMATION
ORDERING CODE MAL2142...
U
R
(V)
I
R
NOMINAL
I
L2
C
R
CASE SIZE 100 Hz
tan
FREQ.
100 Hz
2 min
105 ºC
ØDxL
100 Hz CODE
(1)
(μF)
(μA)
(mA)
(mm)
330
470
1000
10
2200
4700
6800
10 000
22 000
100
220
330
470
16
1000
2200
3300
4700
6800
10 000
47
100
220
470
25
1000
2200
3300
4700
6800
6.3 x 11
8 x 12
10 x 12
10 x 20
12.5 x 25
16 x 25
16 x 31
18 x 40
5 x 11
6.3 x 11
8 x 12
10 x 12
10 x 16
12.5 x 20
12.5 x 25
16 x 25
16 x 31
18 x 31
5 x 11
6.3 x 11
8 x 12
10 x 12
10 x 20
12.5 x 25
16 x 25
16 x 31
18 x 35
200
290
460
760
1260
1690
2120
3100
110
190
270
370
560
920
1170
1480
1930
2330
97
142
236
380
680
1110
1440
1710
2160
33
47
100
220
470
680
1000
2200
16
35
53
75
160
352
528
752
1088
1600
12
25
55
118
250
550
825
1175
1700
0.20
0.20
0.20
0.22
0.26
0.28
0.30
0.32
0.16
0.16
0.16
0.16
0.16
0.18
0.20
0.22
0.24
0.26
0.14
0.14
0.14
0.14
0.14
0.16
0.18
0.20
0.22
MF2
MF2
MF2
MF3
MF3
MF3
MF3
MF3
MF2
MF2
MF2
MF2
MF2
MF3
MF3
MF3
MF3
MF3
MF1
MF2
MF2
MF2
MF2
MF3
MF3
MF3
MF3
BULK PACKAGING
LONG LEADS
FORM
CA
54331E3
54471E3
54102E3
54222E3
54472E3
54682E3
54103E3
54223E3
55101E3
55221E3
55331E3
55471E3
55102E3
55222E3
55332E3
55472E3
55682E3
55103E3
56479E3
56101E3
56221E3
56471E3
56102E3
56222E3
56332E3
56472E3
56682E3
F
(mm)
2.5
3.5
5.0
5.0
5.0
7.5
7.5
7.5
2.0
2.5
3.5
5.0
5.0
5.0
5.0
7.5
7.5
7.5
2.0
2.5
3.5
5.0
5.0
5.0
7.5
7.5
7.5
CUT LEADS
FORM
CB
-
-
64102E3
64222E3
64472E3
64682E3
64103E3
64223E3
-
-
-
65471E3
65102E3
65222E3
65332E3
65472E3
65682E3
65103E3
-
-
-
66471E3
66102E3
66222E3
66332E3
66472E3
66682E3
F
(mm)
-
-
5.0
5.0
5.0
7.5
7.5
7.5
-
-
-
5.0
5.0
5.0
5.0
7.5
7.5
7.5
-
-
-
5.0
5.0
5.0
7.5
7.5
7.5
TAPED AMMOPACK
FORM
TNA
74331E3
74471E3
-
-
-
-
-
-
75101E3
75221E3
75331E3
-
-
-
-
-
-
-
76479E3
76101E3
76221E3
-
-
-
-
-
-
F
(mm)
2.5
3.5
-
-
-
-
-
-
2.5
2.5
3.5
-
-
-
-
-
-
-
2.5
2.5
3.5
-
-
-
-
-
-
FORM
TFA
34331E3
34471E3
34102E3
34222E3
34472E3
34682E3
34103E3
-
35101E3
35221E3
35331E3
35471E3
35102E3
35222E3
35332E3
35472E3
35682E3
-
36479E3
36101E3
36221E3
36471E3
36102E3
36222E3
36332E3
36472E3
-
F
(mm)
5.0
5.0
5.0
5.0
5.0
7.5
7.5
-
5.0
5.0
5.0
5.0
5.0
5.0
5.0
7.5
7.5
-
5.0
5.0
5.0
5.0
5.0
5.0
7.5
7.5
-
Revision: 19-Sep-16
Document Number: 28402
4
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
142 RHS
www.vishay.com
Vishay BCcomponents
ORDERING CODE MAL2142...
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
I
R
NOMINAL
I
L2
C
R
CASE SIZE 100 Hz
tan
FREQ.
100 Hz
2 min
105 ºC
ØDxL
100 Hz CODE
(1)
(μF)
(μA)
(mA)
(mm)
47
100
220
330
35
470
1000
2200
3300
4700
22
47
100
220
50
330
470
1000
2200
3300
4.7
10
22
33
47
63
100
220
330
470
1000
2200
2.2
4.7
10
22
33
100
47
100
220
330
470
1000
5 x 11
6.3 x 11
8 x 12
10 x 12
10 x 16
12.5 x 20
16 x 25
16 x 31
18 x 35
5 x 11
6.3 x 11
8 x 12
10 x 12
10 x 16
12.5 x 20
12.5 x 25
16 x 35
18 x 35
5 x 11
5 x 11
6.3 x 11
6.3 x 11
8 x 12
10 x 12
10 x 16
10 x 20
12.5 x 20
16 x 25
18 x 40
5 x 11
6.3 x 11
8 x 12
8 x 12
10 x 12
10 x 16
10 x 20
12.5 x 25
16 x 25
16 x 31
18 x 40
90
150
270
350
460
810
1260
1420
1900
78
120
188
240
410
530
950
1470
1770
36
54
86
100
141
235
335
510
640
930
2340
30
40
66
99
148
180
265
440
540
715
985
16
35
77
116
165
350
770
1155
1645
11
24
50
110
165
235
500
1100
1650
3
6
14
21
30
63
139
208
296
630
1380
3
5
10
22
33
47
100
220
330
470
1000
0.12
0.12
0.12
0.12
0.12
0.12
0.14
0.16
0.18
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.12
0.14
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.09
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
MF1
MF2
MF2
MF2
MF2
MF2
MF3
MF3
MF3
MF1
MF1
MF2
MF2
MF2
MF2
MF2
MF3
MF3
MF1
MF1
MF1
MF1
MF1
MF2
MF2
MF2
MF2
MF2
MF3
MF1
MF1
MF1
MF1
MF1
MF1
MF2
MF2
MF2
MF2
MF2
BULK PACKAGING
LONG LEADS
FORM
CA
50479E3
50101E3
50221E3
50331E3
50471E3
50102E3
50222E3
50332E3
50472E3
51229E3
51479E3
51101E3
51221E3
51331E3
51471E3
51102E3
51222E3
51332E3
58478E3
58109E3
58229E3
58339E3
58479E3
58101E3
58221E3
58331E3
58471E3
58102E3
58222E3
59228E3
59478E3
59109E3
59229E3
59339E3
59479E3
59101E3
59221E3
59331E3
59471E3
59102E3
F
(mm)
2.0
2.5
3.5
5.0
5.0
5.0
7.5
7.5
7.5
2.0
2.5
3.5
5.0
5.0
5.0
5.0
7.5
7.5
2.0
2.0
2.5
2.5
3.5
5.0
5.0
5.0
5.0
7.5
7.5
2.0
2.5
3.5
3.5
5.0
5.0
5.0
5.0
7.5
7.5
7.5
CUT LEADS
FORM
CB
-
-
-
60331E3
60471E3
60102E3
60222E3
60332E3
60472E3
-
-
-
61221E3
61331E3
61471E3
61102E3
61222E3
61332E3
-
-
-
-
-
68101E3
68221E3
68331E3
68471E3
68102E3
68222E3
-
-
-
-
69339E3
69479E3
69101E3
69221E3
69331E3
69471E3
69102E3
F
(mm)
-
-
-
5.0
5.0
5.0
7.5
7.5
7.5
-
-
-
5.0
5.0
5.0
5.0
7.5
7.5
-
-
-
-
-
5.0
5.0
5.0
5.0
7.5
7.5
-
-
-
-
5.0
5.0
5.0
5.0
7.5
7.5
7.5
TAPED AMMOPACK
FORM
TNA
70479E3
70101E3
70221E3
-
-
-
-
-
-
71229E3
71479E3
71101E3
-
-
-
-
-
-
78478E3
78109E3
78229E3
78339E3
78479E3
-
-
-
-
-
-
79228E3
79478E3
79109E3
79229E3
-
-
-
-
-
-
-
F
(mm)
2.5
2.5
3.5
-
-
-
-
-
-
2.5
2.5
3.5
-
-
-
-
-
-
2.5
2.5
2.5
2.5
3.5
-
-
-
-
-
-
2.5
2.5
3.5
3.5
-
-
-
-
-
-
-
FORM
TFA
30479E3
30101E3
30221E3
30331E3
30471E3
30102E3
30222E3
30332E3
-
31229E3
31479E3
31101E3
31221E3
31331E3
31471E3
31102E3
-
-
38478E3
38109E3
38229E3
38339E3
38479E3
38101E3
38221E3
38331E3
38471E3
38102E3
-
39228E3
39478E3
39109E3
39229E3
39339E3
39479E3
39101E3
39221E3
39331E3
39471E3
-
F
(mm)
5.0
5.0
5.0
5.0
5.0
5.0
7.5
7.5
-
5.0
5.0
5.0
5.0
5.0
5.0
5.0
-
-
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
7.5
-
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
7.5
7.5
-
Revision: 19-Sep-16
Document Number: 28402
5
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
京公网安备 11010802033920号
EEWORLD
