SERIES
4554R & 4564R
4554 & 4564
ct
du
In
DA
SH
NU
E
MB
s
or
Radial Lead Inductors
R*
Actual Size (Max.)
Physical Parameters
Series 4554
Inches
A
0.34 Max.
B
0.433 Max.
C
0.200 Nom.
D
0.200 Nom.
E
0.024 Nom.
Series 4564
Inches
A
0.315 Max.
B
0.440 Max.
C
0.200 Nom.
D
0.200 Nom.
E
0.028 Nom.
Operating Temperature Range
Series 4554 –40°C to +85°C
Series 4564 –20°C to +80°C
Storage Temperature Rangee
Series 4554 –40°C to +85°C
Series 4564 –40°C to +80°C
Millimeters
8.64 Max.
11 Max.
5.0 Nom.
5.0 Nom.
0.61 Nom.
Millimeters
8.0 Max.
11.2 Max.
5.0 Nom.
5.0 Nom.
0.71 Nom.
-1R0M
-1R5M
-2R2M
-3R3M
-4R7M
-6R8M
-100K
-120K
-150K
-180K
-220K
-270K
-330K
-390K
-470K
-560K
-680K
-820K
-101K
-121K
-151K
-181K
-221K
-271K
-331K
-391K
-471K
-561K
-681K
-821K
-102K
1.0 µH
1.5 µH
2.2 µH
3.3 µH
4.7 µH
6.8 µH
10 µH
12 µH
15 µH
18 µH
22 µH
27 µH
33 µH
39 µH
47 µH
56 µH
68 µH
82 µH
100 µH**
120 µH**
150 µH**
180 µH**
220 µH**
270 µH**
330 µH**
390 µH**
470 µH**
560 µH**
680 µH**
820 µH**
1000 µH**
SERIES 4554 FERRITE CORE
±20%
20
7.96
150.0
±20%
20
7.96
130.0
±20%
20
7.96
100.0
±20%
20
7.96
79.0
±20%
20
7.96
51.0
±20%
20
7.96
29.0
±10%
50
2.52
14.0
±10%
50
2.52
13.0
±10%
50
2.52
12.0
±10%
40
2.52
11.0
±10%
40
2.52
9.2
±10%
40
2.52
8.5
±10%
30
2.52
7.8
±10%
30
2.52
6.9
±10%
30
2.52
6.5
±10%
30
2.52
5.4
±10%
30
2.52
4.9
±10%
30
2.52
4.1
±10%
20
0.796
3.7
±10%
20
0.796
3.4
±10%
20
0.796
3.2
±10%
20
0.796
2.8
±10%
20
0.796
2.7
±10%
20
0.796
2.4
±10%
20
0.796
2.3
±10%
20
0.796
2.1
±10%
20
0.796
1.9
±10%
20
0.796
1.8
±10%
20
0.796
1.6
±10%
20
0.796
1.5
±10%
50
0.252
1.3
0.013
0.016
0.021
0.025
0.030
0.035
0.055
0.060
0.065
0.085
0.095
0.120
0.140
0.160
0.200
0.210
0.210
0.230
0.290
0.320
0.450
0.580
0.650
0.800
0.900
1.0
1.1
1.4
1.6
1.8
2.9
10.0
8.5
6.5
5.5
4.3
3.7
3.0
2.6
2.2
2.0
1.7
1.6
1.5
1.4
1.3
1.2
1.2
1.1
0.91
0.84
0.75
0.69
0.64
0.57
0.54
0.48
0.46
0.41
0.38
0.35
0.29
The Rated DC Current
The amperage where the
inductance value decreases 10%.
**Note: Series 4554 Inductance Tolerance
Available in
J = 5% in values
≥
100µH only
Packaging
Bulk
Series 4564 Optional Tolerances: J = 5%
*Complete part # must include series # PLUS the dash #
For surface finish information,
refer to www.delevanfinishes.com
-101K
-121K
-151K
-181K
-221K
-271K
-331K
-391K
-471K
-561K
-681K
-821K
-102K
-122K
-152K
-182K
-222K
-272K
-332K
-392K
-472K
-562K
-682K
-822K
-103K
-123K
-153K
-183K
-223K
-273K
-333K
0.10 mH
0.12 mH
0.15 mH
0.18 mH
0.22 mH
0.27 mH
0.33 mH
0.39 mH
0.47 mH
0.56 mH
0.68 mH
0.82 mH
1.00 mH
1.20 mH
1.50 mH
1.80 mH
2.20 mH
2.70 mH
3.30 mH
3.90 mH
4.70 mH
5.60 mH
6.80 mH
8.20 mH
10.0 mH
12.0 mH
15.0 mH
18.0 mH
22.0 mH
27.0 mH
33.0 mH
SERIES 4564 FERRITE CORE
±10%
80
0.796
5.3
±10%
80
0.796
4.5
±10%
80
0.796
3.8
±10%
80
0.796
3.3
±10%
80
0.796
2.9
±10%
80
0.796
2.6
±10%
80
0.796
2.3
±10%
80
0.796
2.1
±10%
80
0.796
1.9
±10%
80
0.796
1.7
±10%
80
0.796
1.6
±10%
80
0.796
1.4
±10%
90
0.252
1.3
±10%
90
0.252
1.2
±10%
90
0.252
1.1
±10%
90
0.252
1.0
±10%
90
0.252
0.9
±10%
90
0.252
0.8
±10%
90
0.252
0.7
±10%
90
0.252
0.7
±10%
90
0.252
0.6
±10%
90
0.252
0.6
±10%
90
0.252
0.5
±10%
90
0.252
0.5
±10% 100
0.0796
0.4
±10% 100
0.0796
0.4
±10% 100
0.0796
0.4
±10% 100
0.0796
0.3
±10% 100
0.0796
0.3
±10% 100
0.0796
0.2
±10% 100
0.0796
0.2
2.0
2.0
2.0
3.0
3.0
3.0
4.0
4.0
4.0
4.0
4.0
6.0
6.0
9.0
9.0
9.0
13.0
13.0
13.0
13.0
18.0
18.0
26.0
26.0
40.0
40.0
60.0
60.0
80.0
80.0
80.0
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.15
0.15
0.15
0.10
0.10
0.10
0.10
0.05
0.05
0.05
0.05
0.05
0.04
0.04
0.04
0.03
0.03
0.03
0.03
