IHLP-2525CZ-5A
www.vishay.com
Vishay Dale
IHLP
®
Automotive Inductors, High Temperature (155 °C) Series
FEATURES
• High temperature, up to 155 °C
• Shielded construction
• Excellent DC/DC energy storage up to 1 MHz
to 2 Mhz. Filter inductor applications up the
SRF (see Standard Electrical Specifications
table).
• Handles high transient current spikes without
saturation
• Ultra low buzz noise, due to composite
construction
• AEC-Q200 qualified
• IHLP design. PATENT(S):
www.vishay.com/patents
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DESIGN SUPPORT TOOLS
click logo to get started
Models
Available
Design Tools
Available
STANDARD ELECTRICAL SPECIFICATIONS
L
0
INDUCTANCE
± 20 %
AT 100 kHz,
0.25 V, 0 A
(μH)
0.47
0.68
0.82
1.0
1.5
2.2
3.3
4.7
5.6
6.8
10
15
22
DCR
TYP.
25 °C
(m)
3.87
5.38
6.75
7.90
12.3
HEAT
DCR RATING SATURATION
SRF
MAX. CURRENT CURRENT
TYP.
25 °C DC TYP.
DC TYP.
(MHz)
(A)
(1)
(m)
(A)
(2)
4.14
5.76
7.22
8.45
13.2
20.0
16.5
13.8
12.0
10.6
8.1
6.8
5.6
5.3
4.4
4.0
2.9
2.8
14.0
17.0
16.8
13.0
11.6
10.8
8.3
5.6
4.8
4.4
2.9
2.8
2.2
82.4
56.1
68.6
53.2
45.9
31.2
28.6
25.5
22.8
19.6
14.0
10.4
8.3
APPLICATIONS
Engine and transmission control units
Diesel injection drivers
DC / DC converters for entertainment / navigation systems
Noise suppression for motors: windshield wipers / power
seats / power mirrors / heating and ventilation blower /
HID lighting
• LED drivers
•
•
•
•
DIMENSIONS
in inches [millimeters]
0.255 ± 0.010
[6.47 ± 0.254]
17.10 18.30
26.50 28.40
35.90 38.40
42.60 45.60
53.80 57.60
71.90 76.90
118.0 127.0
163.0 174.0
0.255 ± 0.010
[6.47 ± 0.254]
0.125 ± 0.01
[3.18 ± 0.3]
0.270 ± 0.015
[6.86 ± 0.381]
0.118 [3.0]
Max.
Notes
• All test data is referenced to 25 °C ambient
• Operating temperature range -55 °C to +155 °C
• The part temperature (ambient + temp. rise) should not exceed
155 °C under worst case operating conditions. Circuit design,
component placement, PWB trace size and thickness, airflow
and other cooling provisions all affect the part temperature. Part
temperature should be verified in the end application
• Rated operating voltage (across inductor) = 75 V
(1)
DC current (A) that will cause an approximate
T
of 40 °C
(2)
DC current (A) that will cause L to drop approximately 20 %
0
0.050 ± 0.012
[1.27 ± 0.30]
Typical Pad Layout (Min.)
0.135
[3.429]
0.135
[3.429]
0.325
[8.255]
DESCRIPTION
IHLP-2525CZ-5A
MODEL
22 μH
INDUCTANCE VALUE
± 20 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC
®
LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
H
L
P
2
5
2
SIZE
5
C
Z
E
R
2
2
INDUCTANCE
VALUE
0
M
TOL.
5
A
MODEL
PACKAGE
CODE
SERIES
PATENT(S):
www.vishay.com/patents
This Vishay product is protected by one or more United States and international patents.
Revision: 29-Sep-17
Document Number: 34335
1
For technical questions, contact:
magnetics@vishay.com
