MBR1635, MBR1645, MBRB1645, NRVBB1645
PACKAGE DIMENSIONS
TO−220
CASE 221B−04
ISSUE E
C
Q
B
F
T
S
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI
Y14.5M, 1982.
2. CONTROLLING DIMENSION: INCH.
DIM
A
B
C
D
F
G
H
J
K
L
Q
R
S
T
U
INCHES
MIN
MAX
0.595
0.620
0.380
0.405
0.160
0.190
0.025
0.035
0.142
0.161
0.190
0.210
0.110
0.130
0.014
0.025
0.500
0.562
0.045
0.060
0.100
0.120
0.080
0.110
0.045
0.055
0.235
0.255
0.000
0.050
MILLIMETERS
MIN
MAX
15.11
15.75
9.65
10.29
4.06
4.82
0.64
0.89
3.61
4.09
4.83
5.33
2.79
3.30
0.36
0.64
12.70
14.27
1.14
1.52
2.54
3.04
2.04
2.79
1.14
1.39
5.97
6.48
0.000
1.27
4
A
1
3
U
H
K
L
G
D
J
R
