NJU7051/52
LOW INPUT OFFSET VOLTAGE C-MOS OPERATIONAL AMPLIFIER
■
GENERAL DESCRIPTION
The NJU7051/52 are single and dual C-MOS Operational
Amplifiers operated on a single-power-supply, low voltage and
low operating current.
The input offset voltage is lower than 2mV,and the input bias
current is as low as less than 1pA,consequently the very small
signal around the ground level can be amplified.
The minimum operating voltage is 1V and the output stage
permits output signal to swing between both of the supply rails.
Furthermore, the operating current is also as low as 15µA
( typ ) per circuit, therefore it can be applied especially to battery
operated items.
■PACKAGE
OUTLINE
NJU7051M
NJU7052M
NJU7051V
■
FEATURES
■
PIN CONFIGURATION
●
Single-Power-Supply
●
Low Input Offset Voltage
( V
IO
=2mV max )
●
Wide Operating Voltage
( V
DD
=1~16V )
●
Wide Output Swing Range
( V
OM
=2.94V typ. @ V
DD
=3V )
●
Low Operating Current
( 15µA/circuit )
●
Low Bias Current
( I
IB
=1pA typ. )
●
Internal Compensation Capacitor
●
External Offset Null Adjustment ( Only NJU7051 )
NJU7051M
●
Package Outline
DMP/SSOP8 ( NJU7051 )
NJU7051V
DMP8 ( NJU7052 )
●
C-MOS Technology
■
EQUIVALENT CIRCUIT
NJU7052M
٭
IN1,IN2 are only for NJU7051 ( NJU7052 don’t have these terminals ).
Ver.2013-12-03
-1-
NJU7051/52
■
ABSOLUTE MAXIMUM RATINGS
( Ta=25˚C )
PARAMETER
Supply Voltage
Differential Input Voltage
Common Mode Input Voltage
Power Dissipation
Operating Temperature Range
Storage Temperature Range
SYMBOL
V
DD
V
ID
V
IC
P
D
T
opr
T
stg
RATINGS
18
± 18 ( note1 )
-0.3~18
( SSOP8 ) 250
( DMP8 ) 300
-40~+85
-40~+125
UNIT
V
V
V
mW
˚C
˚C
( note1 ) If the supply voltage ( V
DD
) is less than 18V, the input voltage must not over the V
DD
level though 18V is limit specified.
■
ELECTRICAL CHARACTERISTICS
( Ta=25˚C,V
DD
=3V,R
L
=∞ )
PARAMETER
Input Offset Voltage
Input Offset Current
Input Bias Current
Input Impedance
Large Signal Voltage Gain
Input Common Mode Voltage Range
Maximum Output Swing Voltage
Common Mode Rejection Ratio
Supply Voltage Rejection Ratio
Operating Current/Circuit
Slew Rate
Unity Gain Bandwidth
SYMBOL
V
IO
I
IO
I
IB
R
IN
A
V
V
ICM
V
OM
CMR
SVR
I
DD
SR
F
t
TEST CONDITION
R
S
=50Ω
MIN.
-
-
-
-
80
0~2
2.90
60
60
-
-
-
TYP.
-
1
1
1
90
-
2.94
70
70
15
0.05
0.1
MAX.
2
-
-
-
-
-
-
-
-
25
-
-
UNIT
mV
pA
pA
TΩ
dB
V
V
dB
dB
µA
V/µs
MHz
R
L
=1MΩ
A
V
=40dB,C
L
=10pF
■
OFFSET ADJUSTMENT CIRCUIT
( Only For NJU7051 )
[CAUTION]
The specifications on this databook are only
given for information , without any guarantee
as regards either mistakes or omissions. The
application circuits in this databook are
described only to show representative usages
of the product and not intended for the
guarantee or permission of any right including
the industrial rights.
-2-
Ver.2013-12-03
