THESE DRAWINGS ARE THE PROPERTY OF QUALTEK
ELECTRONICS AND NOT TO BE REPRODUCED FOR
OR COMMUNICATED TO A THIRD PARTY WITHOUT
THE EXPRESS WRITTEN PERMISSION OF AN OFFICER
OF QUALTEK ELECTRONICS.
REVISION
REV.
B
DESCRIPTION
RoHS Compliancy
DATE
06-01-06
APPROVED
DP
16 ±
0.5
0
24
24 ±
31
0.5
0
12 ±
1
0.5
15 ±
0.5
0
3.15
6.3
2 ±
0.2
0
19.7
27.5
PANEL CUTOUT
27.2
30
20
CONTROLLED
3
2
1
Contact PIN Bronze Strip t=2mm Tin-Plated
Contact PIN Bronze Strip t=2mm Tin-Plated
Body Insulator PC 940R Black Color
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
Drawn / Date
B.ZHANG
04-09-02
2
1
1
Qualtek Electronics Corp.
Part Number:
Description:
NOTES:
RATING:
UL, CSA: 15A 250V AC
VDE: 10A 250V AC
APPROVALS: UL,CSA, VDE
PANEL THICKNESS: 2.0mm
RoHS COMPLIANT
PPC DIVISION
701W-20/57
AC RECEPTACLE
UNIT: mm
Checked / Date
04-09-02
REV. B
Approved / Date
JJH / 04-09-02
