3M Multi-Touch Display C4667PW
™
Interactive Digital Signage with Truly Uncompromised Touch
The interactive 46-inch
3M Multi-Touch Display C4667PW
features
3M’s high-performance projected capacitive (3M PCT) multi-touch tech-
nology and sophisticated bezel-free display design to offer users a truly
uncompromised touch experience. The C4667PW chassis display delivers
60 simultaneous touches over 1,000 square inches of interactive surface
area, at an ultra-fast 12 ms response time, to enable designers to create
multi-user experiences that are more natural, intuitive and responsive
when compared to infrared- and optical-based systems. Versatile enough
for interactive digital signage, interactive tables and kiosk solutions, the
C4667PW provides system architects with a high-performance, easy-to-
integrate commercial display for innovative multi-touch solutions.
™
Precision Large-format Multi-Touch
In addition to delivering 60 simultaneous touches at a 12ms response
time, the 3M touch electronics have an advanced built-in palm rejection
algorithm to ensure that unintended contact with the screen is ignored
and does not interfere with the user’s intended action. The design of the
projected capacitive sensor has more than 10,000 touch sensing points in
close proximity, making it precise and extremely accurate across the entire
touchscreen. 3M PCT’s durable glass surface has unique anti-stiction
properties that greatly reduces surface friction and allows users fingers to
effortlessly glide across the display for easy gesture functions. This fast,
accurate, and easy to use multi-touch screen enables customers to create,
deliver and experience innovative and engaging multi-user applications.
Industrial Grade Designed for Multi-Touch Interaction
The C4667PW display has been designed from the ground up to meet the
unique requirements of a large format multi-touch display. Unlike televisions
or digital signs, an interactive multi-touch display draws users in close
proximity to the LCD. To maintain sharp image quality at close distances the
C4667PW display features a full 1080p HD LCD, wide viewing angles, and
a fine pixel pitch of 0.177mm x 0.530mm. An advanced thermal manage-
ment system ensures the touch surface is at a comfortable temperature for
the user, even in a horizontal table implementation, and promotes "always
on" performance of critical electronic components. To ensure the image
Recommended Multi-Touch Applications
• Interactive Digital Signage
• Transportation
• Wayfinding
• Security Monitoring Systems
• Training and Simulation
• Tele-presence
• Retail Product Selectors
• Ticketing/Vending
• Point of Information
• Pro Audio/Visual
• Geospatial
• Broadcast
quality is not compromised in strong ambient lighting environments, this
display features an anti-glare coating.
Every element of the C4667PW is designed to enable integrators to
configure the display in any orientation while meeting the demanding needs
of public environments. The LED backlight system allows integrators to
implement in landscape, portrait or horizontal orientations without concern
of non-uniformity that CCFL systems can exhibit. At just 2.7” deep the
C4667PW can be a sleek wall mounted interactive digital sign or a slim
interactive table or kiosk. The all glass bezel free industrial design, inspired
by modern consumer devices, makes it an elegant addition for any
commercial or professional environment.
Feature
3M PCT Multi-Touch
Technology
Benefit
•
•
•
•
•
•
•
•
•
60 finger multi-touch input enables intuitive on-screen collaboration
Fast <12 millisecond touch response creates a natural, intuitive and responsive interface
Advanced palm rejection algorithms prevent unintended touches that commonly occur in table applications
Anti-stiction surface enhances the user experience for simple and advanced gestures
Flat front surface design built in for elegant modern aesthetics
Slim 2.7” thickness provides sleek low profile appearance while enabling easy integration on wall, table or ensclosure
All metal construction provides rugged frame for public use environments
Advanced thermal management system designed to keep display cool to the touch in tabletop and enclosure installations
Anti-Glare Coating to maintain image quality under harsh ambient lighting
Sophisticated and
Durable Design
Premium Display
for Multi-Touch
Applications
• Full HD resolution (1920x1080) with a fine pixel pitch to maintain sharp image quality while
performing up-close interactions
• Ultra-Wide viewing angle presents a brilliant image at any angle
• LED Backlights present a long lasting, bright, uniform image regardless of integrated orientation
3M Multi-Touch Display C4667PW Specifications
™
Functional Specifications
Display Details
LCD Technology
Display Colors
Pixel Pitch
SPVA (super pattern vertical align)
1.07 billion
.177 x .530mm
Physical Specifications
Product Details
Operating Environment
Storage Environment
Video Input
Audio
Cover Glass
VESA Pattern
Power Supply
Power Consumption
RoHS Compliant
Agency Approvals
Warranty
Dimensions and Weight
0 to +40 degrees C, relative humidity,
non-condensing 90%
-10 to +60 degrees C
DVI, VGA, HDMI, DP (HDCP)
Speaker: 5W + 5W @ 8Ω
Headphone: 20mW + 20mW @ 32Ω
Chemically-strenghtened
400mm x 400mm
Internal 110/220 VAC Power Supply
165 watt (maximum)
Yes
FCC-B, CE, TUV (IEC 60950), C-TICK
2 years
Brightness
700 cd/m2 (nit) typical
with touch sensor (max.)(1) 610 cd/m2 (nit) typical
Contrast Ratio (2)
Viewing Angle
Video Response Time (3)
Refresh Rate
Control Type
Native Resolution
4000:1 typical
Horizontal/Vertical: 178 degrees typical
13 ms typical
60Hz
OSD
1920 x 1080
™
(1) Brightness measured on a display with 3M
Projected Capacitive sensor.
(2) Measured at a contrast ratio of 10.
(3) Gray to Gray
Touch Details
Number of Touch Points
Touch Point Speed (4)
Input Type
Touch Communication
Operating System Support
(4) up to 20 touches
60 points with palm rejection
<12 milliseconds
Finger, thin glove
USB
Windows 8 / 7/ Vista / XP, Linux, Mac
Display Area (WxH)
(viewing area)
Display Dimensions
(outer)
Packaging (WxHxD)
Display weight
Packaging/Display weight
Ordering Information
Part Number
1018.08 x 572.67mm
40.08 x 22.55 inches
1086.7 x 638.3 x 68.6 mm
42.8 x 25.1 x 2.7 inches
1240 x 880 x 250 mm
48.8 x 34.6 x 9.8 inches
26 kg / 57 lbs
31.6 kg / 70 lbs
98-0003-4107-7
Connections
Power
USB
(touch)
OSD
In
Out
RS-232
DP HDMI
DVI VGA
Out In
Audio
3M Touch Systems
Subsidiary of 3M Company
501 Griffin Brook Park Drive
Methuen, MA 01844 U.S.A.
1-888-659-1080
www.3M.com/touch
RoHS Directive compliant:
RoHS 2011/65/EU means that the product or part does not contain any of the substances in excess of the maximum concentration values (“MCVs”) in EU RoHS Directive
2011/65/EU, unless the substance is in an application that is exempt under EU RoHS. The MCVs are by weight in homogeneous materials. This information represents 3M's knowledge and belief, which
may be based in whole or in part on information provided by third party suppliers to 3M. (3/13)
IMPORTANT NOTICE TO PURCHASER:
Specifications are subject to change without notice. These 3M Touch Systems’ Products and software are warranted to meet their published specifications
from the date of shipment and for the period stated in the specification. 3M Touch Systems makes no additional warranties, express or implied, including but not limited to any implied warranties of
merchantability or fitness for a particular purpose. User is responsible for determining whether the 3M Touch Systems Products and software are fit for User’s particular purpose and suitable for its
method of production, including intellectual property liability for User’s application. If the Product, software or software media is proven not to have met 3M Touch Systems’ warranty, then 3M Touch
Systems’ sole obligation and User’s and Purchaser’s exclusive remedy, will be, at 3M Touch Systems’ option, to repair or replace that Product quantity or software mediator to refund its purchase
price. 3M Touch Systems has no obligation under 3M Touch Systems’ warranty for any Product, software or software media that has been modified or damaged through misuse, accident, neglect, or
subsequent manufacturing operations or assemblies by anyone other than 3M Touch Systems. 3M Touch Systems shall not be liable in any action against it in any way related to the Products or soft-
ware for any loss or damages, whether non-specified direct, indirect, special, incidental or consequential (including downtime, loss of profits or goodwill) regardless of the legal theory asserted. (7/02)
© 3M 2014 All Rights Reserved.
3M is a trademark of 3M Company.
C4267PW-0114
