This document was generated on 10/23/2017
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0877610008
Active
Milli-Grid™ Connector System
Milli-Grid Header, Dual Row Dual Body, Through Hole, Vertical, 12 Circuits, 0.38µm
Gold (Au) Selective Plating, 8.18mm Stacking Height, Pocket Tray Packaging, Lead-
Free
Documents:
Drawing (PDF)
Product Specification PS-87761-100 (PDF)
Agency Certification
UL
General
Product Family
Series
Application
Overview
Product Name
UPC
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
First Mate / Last Break
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Mated Height
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PCB Locator
PCB Retention
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Polarized to Mating Part
Polarized to PCB
Shrouded
Stackable
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Voltage - Maximum
RoHS Certificate of Compliance (PDF)
Series image - Reference only
E29179
PCB Headers
87761
Board-to-Board, Signal
Milli-Grid™ Connector System
Dual Body, Milli-Grid
756054582220
Yes
12
12
Black
No
94V-0
No
No
None
None
5.46mm
Copper Alloy
Gold
Nickel
Nylon
665.780/mg
2
Vertical
No
None
Tray
2.00mm
2.00mm
0.381µm
No
No
No
No
-55°C to +105°C
Through Hole
2.0A
125V
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Not Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Search Parts in this Series
87761 Series
Mates With
79109 Board-to-Board Top/Bottom Entry
SMT Receptacle
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
010
WAVE
003
260
PS-87761-100
SD-87761-007, SD-87761-018
