Terminal Blocks
158-P02142RPU-E, 158-P03142RPU-E, 158-P04142RPU-E, 158-P05142RPU-E,
158-P06142RPU-E, 158-P07142RPU-E, 158-P08142RPU-E, 158-P09142RPU-E,
158-P10142RPU-E, 158-P11142RPU-E, 158-P12142RPU-E
Terminal Blocks
5.08xP+2.54 (.2xP+.1)
2.54 (.1)
2
(.079)
5.08x(P-1) [.2x(P-1)]
5.62
(.221)
1.75
(.069)
ø1.1~1.2
7.62
(.3)
13.88
(.546)
158-P02142RPU-E, 158-P03142RPU-E, 158-P04142RPU-E, 158-P05142RPU-E, 158-P06142RPU-E, 158-P07142RPU-E,
158-P08142RPU-E, 158-P09142RPU-E, 158-P10142RPU-E, 158-P11142RPU-E, 158-P12142RPU
-E
5.08
(.2)
P.C.B. LAYOUT
13.88 (.546)
2
4
3
1
5
13
(.512)
10.30
(.406)
3.50±.3
(.138±.012)
0.50±.05
(.02±.002)
5.08x(P-1) [.2x(P-1)]
5.08±.08
(.2±.003)
1±.1
(.039±.004)
7.62
(0.3)
1.75
(.069)
Dimensions: mm (In.)
ELECTRICAL SPECIFICATIONS
Rating:
Pitch:
300V 10A
5.08 mm
MATERIAL SPECIFICATIONS
End Cover (5):
Lever (4):
Clamping (3):
Solder Pin (2):
Housing (1):
PA66, Green
PA66, Orange
Stainless Steel
Copper, Tin Plated
PA66, Green
RoHS Compliant
Insulation withstands voltage:
AC 1500V/Min
Insulation resistance:
Temperature range:
Electric wire:
500MΩ or more at DC500V
-40°C~ +105°C
22~14 AWG
Date Last Revised: 7-17-06
Available from Mouser Electronics
1-800-346-6873
www.mouser.com
KC-
301019
Specifications are subject to change without notice. No liability or warranty implied by this information. Environmental compliance based on producer documentation.
