1. PHYSICAL DIMENSIONS
#6-32X1/4
REVISION
REV.
B
RoHS Compliancy
DESCRIPTION
DATE
06-01-06
APPROVED
LY
ELECTRICAL CHARACTERISTICS:
1-1.
VOLTAGE RATING...................................115/250VAC
1-2.
CURRENT RATING
A. @ 115 VAC..........................................3 A RMS MAX
B. @ 250 VAC.........................................3 A RMS MAX
OPERATING FREQUENCY......................50/60Hz
LEAKAGE CURRENT: EACH LINE TO GROUND
A. @ 115 VAC 60Hz............................0.25 mA MAX
B. @ 250 VAC 50Hz.............................0.45 mA MAX
HIPOT RATING (FOR ONE MINUTE)
A. LINE TO GROUND...........................2250 VDC
B. LINE TO LINE.....................................1450 VDC
MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM)
.01
15
0
.05
25
6
.10
45
25
.15
50
35
.50
70
48
1.0
70
55
5.0
60
55
10
55
55
30
30
40
BROWN
G/Y
BLUE
1.575 ± 0.02
1-3.
1-4.
2.04MAX
1-5.
4.0MIN
2.55MAX
0.63
1.575 ± 0.005
0.005
0
1-6.
FREQ. MHz
COM. MODE dB
1.79MAX
DIF. MODE dB
0.91 ±
Ø0.157
1-7.
1-8.
OPERATING TEMPERATURE.................-25° TO +100° C
SAFETY:
RoHS COMPLIANT
R0.234
1.22 ± 0.005
PANEL CUTOUT
1-9.
2. ELECTRICAL SCHEMATIC
L1:
L2:
C1:
C2:
R:
6.5mH
4.5mH
0.33uF
3300pF
2.2MΩ
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
CONTROLLED
Qualtek Electronics Corp.
Part Number:
Description:
PPC DIVISION
870-03/004
EMI FILTER
UNIT: in
REV. B
Approved / Date
JJH / 09-12-01
Drawn / Date
B.Zhang
09-12-01
Checked / Date
09-12-01
