MIL-DTL-83513
Micro-D
500-011
EMI/RFI Micro-D Backshell
with shield sock
sTYLE T - ToP ENTRY
L
sTYLE s - sIDE ENTRY
sTYLE E - 45° ENTRY
Shield Sock:
Single Layer
K
D
E
F
G
M
H
Jackscrew
Fillister
Head
Option B
J Thread
Connector
Shown for
Reference
.175 (4.4)
Retaining
LENGTH
Jackscrew Hex
B
Metric dimensions (mm) are
indicated in parentheses.
C
HoW To oRDER
Cable
Entry
style
T
– Top
s
– Side
E
– 45°
Basic
Part
Number
011
shell*
Plating
C
– Black Anodize
E
– Chem. Film
J
– Gold Iridite Over
Cadmium Over
Electroless Nickel
M
– Electroless Nickel
NF
– Cadmium, Olive
Drab Over
Electroless Nickel
z 2
– Gold
M
shell
size
(Table I)
9
15
21
25
31
37
51
100
Hardware options *
B
– (2) Male Fillister
Head Jackscrews
H
– (2) Male Hex Socket
F
– (2) Female Jackpost
FB
– (1) Female Jackpost
And (1) Male
Jackpost
FH
– (1) Female Jackpost
and (1) Male Hex
Socket
B
Cable
Entry
(Table II)
04
05
06
07
08
09
10
11
12
shield
sock
Length
Length
in 1 inch
increments
(e.g. 6 = 6
inches)
series
500
Sample Part Number:
T
011
500
© 2011 Glenair, Inc.
21
CAGE Code 06324
06
—
6
* sEE PAGE C-4 FoR CoMPLETE INFoRMATIoN
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
C-18
500-011
EMI/RFI Micro-D Backshell
with shield sock
TABLE I: DIMENsIoNs
shell
size
09
15
21
25
31
37
51
100
shell
size
09
15
21
25
31
37
51
100
A
.775 (19.7)
.925 (23.5)
1.075 (27.3)
1.175 (29.8)
1.325 (33.7)
1.475 (37.5)
1.425 (36.2)
2.160 (54.9)
G
.650 (16.5)
.700 (17.8)
.735 (18.7)
.800 (20.3)
.860 (21.8)
.925 (23.5)
.975 (24.8)
1.050 (26.7)
B
C
.565 (14.4)
.715 (18.2)
.865 (22.0)
.965 (24.5)
1.115 (28.3)
1.265 (32.1)
1.215 (30.9)
1.800 (45.7)
J Thread
2-56 UNC-2
2-56 UNC-2
2-56 UNC-2
2-56 UNC-2
2-56 UNC-2
2-56 UNC-2
2-56 UNC-2
4-40 UNC-2
D
E
.435 (11.0)
.440 (11.2)
.458 (11.6)
.483 (12.3)
.476 (12.1)
.478 (12.2)
.548 (13.9)
.687 (17.4)
M
Max
1.00 (25.4)
1.03 (26.2)
1.05 (26.7)
1.09 (27.7)
1.13 (28.7)
1.16 (29.5)
1.19 (30.2)
1.25 (31.8)
F
.607 (15.4)
.643 (16.3)
.677 (17.2)
.718 (18.2)
.726 (18.4)
.744 (18.9)
.829 (21.1)
.984 (25.0)
Max Entry Table
II
08
08
08
08
09
09
10
12
.36
.36
.36
.36
.36
.36
.40
.45
(9.1)
(9.1)
(9.1)
(9.1)
(9.1)
(9.1)
(10.2)
(11.4)
.32
.44
.56
.62
.68
.72
.75
.81
±.03
.75
.88
1.00
1.06
1.12
1.16
1.19
1.25
(8.1)
(11.2)
(14.2)
(15.7)
(17.3)
(18.3)
(19.1)
(20.6)
(0.8)
(19.1)
(22.4)
(25.4)
(26.9)
(28.4)
(29.5)
(30.2)
(31.8)
H
REF
.154 (3.9)
.154 (3.9)
.154 (3.9)
.154 (3.9)
.154 (3.9)
.154 (3.9)
.154 (3.9)
.184 (4.7)
k
TABLE II: CABLE ENTRY
Dash No.
04
05
06
07
08
09
10
11
12
L Entry
.125 (3.2)
.156 (4.0)
.188 (4.8)
.219 (5.6)
.250 (6.4)
.281 (7.1)
.312 (7.9)
.344 (8.7)
.375 (9.5)
Metric dimensions (mm) are indicated in parentheses.
