TABLE OF PART NUMBERS
28.5
[1.122]
E
12.50
[.492]
19.80
[.780]
PART No.
RJX8FA5H
RJX8FB5H
FRONT SHELL MATERIAL
PLASTIC BLACK A TYPE
METAL NICKEL PLATED B TYPE
C
E
U
E
3.5
[.138]
2 x
n
1.55
19.80
[.780]
D
12.70
[.500]
3.81
[.150]
10.16
[.400]
[.061]
n
22.0
23.0
[.906]
MIN
D
13.34
[.525]
[.866]
MIN
19.80
[.780]
PANEL CUT OUT
1:1
[.047]
7
5
3
1
8
6
4
2
n
1.20
2
X
n
2.7
[.106]
14.61
[.575]
C
2.54
[.100]
(TYP)
6.60
[.260]
8 x
n
0.8
[.031]
1.27
[.050]
4.44
[.175]
MIN MOUNTING PITCH
1:1
2.54
[.100]
(CONNECTOR FRONT VIEW)
RJ45 CONTACTS
RJ45 SHELL GROUND CONTACT
CONNECTOR LOCATION PINS
C
B
PCB LAYOUT
2:1
(CONNECTOR TOP VIEW)
PSE PINOUT ALTERNATIVES
CONDUCTOR
1
2
3
4
5
6
7
8
Alternative-A
(MDI-X)
Negative V
PSE
Negative V
PSE
Positive V
PSE
Alternative-A
(MDI)
Positive V
PSE
Positive V
PSE
Negative V
PSE
Alternative-A
(AII)
SPECIFICATIONS:
1. MATERIALS:
- PLASTIC INSERT & HOUSING: HIGH TEMPERATURE THERMOPLASTIC FLAMMABILITY RATING UL94V-0
DSM STANYL, 30%
BLACK
- FRONT SHELL: METAL: ZINC ALLOY ZAMAK 3, NICKEL PLATE (B TYPE) OR PLACTIC (A TYPE).
- CONTACTS: PHOSPHORE BRONZE, 1.27 um GOLD PLATE ON MATING SURFACES, 1.27 um NICKEL MIN
UNDERPLATE. 3.81 um MIN MATTE TIN ON CONTACT TAILS.
- LATCH LOCK AND SPRING: SPRING STEEL, NICKEL PLATE.
2. ELECTRICAL CHARACTERISTICS:
- RATED VOLTAGE: 125 VAC
- TYPICAL CONTACT RESISTANCE: 20 mOhm
- INSULATION RESISTANCE: >500 MOhm
- DIELECTRIC STRENGTH: 1000 VAC, 60 SECONDS
- TRANSMISSION SPECIFICATION/CLASS: COMPLIES WITH CAT5e 1000 BASE-T PER EIA-568-C.2
- PoE+ COMPLIES WITH 802.3at Type 2 ( SEE PSE PINOUT ALTERNATIVE TABLE)
B
3D VIEW
1:1
Positive V
PSE
Negative V
PSE
Positive V
PSE
Positive V
PSE
Negative V
PSE
Negative V
PSE
UNLESS OTHERWISE SPECIFIED
TOLERANCE TO BE
A
LINEAR
ANGULAR
X
±
0.5
X
~
±
1
X.X ±
0.1
X.X' ±
30'
X.X ±
0.05
X.X'X " ± 15'
BREAK ALL SHARP EDGES
AND REMOVE ALL BURRS
THIS DOCUMENT IS THE PROPERTY OF AMPHENOL AUSTRALIA PTY. LTD.
. NO PART THEREOF MAY BE REPRODUCED AND USED
WITHOUT THE PRIOR WRITTEN CONSENT OF THE OWNER
.
Amphenol
TITLE:
Amphenol Australia Pty.Ltd,
20 Industry Blvd, Carrum Downs
VIC 3201 Australia
PART No:
MATERIAL:
REFER SPECIFICATION
DRN:
CKD:
APP'D:
T.N
P.M
P.M
DATE:
08/10/12
DATE:
08/10/12
DATE:
08/10/12
SIZE:
DO NOT SCALE
FINISH:
XLRnet CONNECTOR
RJ45 RECP CAT5e
NON-LED & EMI SHIELD
REFER TO TABLE OF
PART NUMBERS
REV
1
SHEET
A
DRAWING No.
6
5
4
DIMENSIONS IN MILIMETRES
3
THIRD ANGLE
PROJECTION
SCALE:
3:2
A3
55010837-000
1
1
/
1
2
