PIN BODY
SEE TABLE
SPRING
9
PLATING ZONES
ZONE 3
ZONE 1
ZONE 2
1.5
5.8
C
21.8
11.7MIN
0.32
C
3 REF
3.7 REF
2.8 REF
1.6 MIN
LOOSE PIECE LENGTH = 29.4 MAX
NOTES
1
1.27 MICRON MIN NICKEL PLATE OVER ZONE 3.
0.76 MICRON MIN PRECIOUS METAL PLATE OVER ZONE 1.
1 MICRON MIN TIN PLATE OVER ZONE 2.
CONFORMS TO THE REQUIREMENTS OF TE CONNECTIVITY PRODUCT SPEC 108-10042
BASED ON EIA/ECA-364-1000.01A (CONTROLLED ENVIRONMENT APPLICATIONS)
1.27 MICRONS MIN NICKEL PLATE OVER ZONE 3.
0.76 MICRON MIN PRECIOUS METAL ELECTROPLATE OVER ZONE 1.
0.076 MICRON MIN GOLD FLASH PLATE OVER THE REMAINDER OF ZONE 3.
CONFORMS TO THE REQUIREMENTS OF TE CONNECTIVITY PRODUCT SPEC 108-10042
BASED ON EIA/ECA-364-1000.01A (CONTROLLED ENVIRONMENT APPLICATIONS)
1.54 - 2.54 MICRON SILVER PLATE OVER ZONE 3.
1.27 MICRON MIN NICKEL PLATE OVER ZONE 3.
0.76 MICRON MIN GOLD PLATE OVER ZONE 1.
0.076 MICRON MIN GOLDFLASH PLATE OVER THE REMAINDER OF
1.27 MICRON MIN NICKEL PLATE OVER ZONE 3.
0.76 MICRON MIN GOLD PLATE OVER ZONE 1.
1 MICRON MIN TIN PLATE OVER ZONE 2.
HOT-DIPPED PRETIN
1.27 MICRONS MIN NICKEL PLATE OVER ZONE 3.
1 - 3 MICRON ELECTRO-TIN PLATE OVER ZONE 3
0.76 MICRON MIN NICKEL PLATE OVER ZONE 3 PER QQ-N-290
1.5 - 2.54 MICRON SILVER PLATE OVER ZONE 3,
SERRATIONS CAN BE MULTI LOCK OR TWO SLOTS.
WIRE RANGE: 0.75 - 1.50 mm² (18-16 AWG)
INSULATION RANGE: 2.0 - 2.5 mm (.080-.100) DIA
REELING
DIRECTION
SECTION
LOOSE PIECE COLOR CODE: BLUE
A-A
SECTION
B-B
A
A
B
A
A
B
2
3
3
6
6
1
1
2
7
2
STAINLESS STEEL
STAINLESS STEEL
STAINLESS STEEL
STAINLESS STEEL
STAINLESS STEEL
STAINLESS STEEL
STAINLESS STEEL
STAINLESS STEEL
STAINLESS STEEL
STAINLESS STEEL
PHBR
PHBR
PHBR
BRASS
BRASS
BRASS
BRASS
BRASS
BRASS
BRASS
PIN BODY
3.0 REF
164164-8
164164-7
1-164161-5
1-164161-3
1-164161-2
2
B
164164-6
164164-5
164164-4
1-164161-1
164161-9
164161-7
164161-6
3
4
5
6
7
8
9
ZONE 3.
A
B
A
A
B
164164-2
164164-1
164161-4
164161-3
164161-2
A
10.
11.
REELING
FINISH
SPRING MATERIAL
AS DIRECTION
DWN
'A' BUT
01JUN2012
THIS DRAWING IS A CONTROLLED DOCUMENT.
BARRELS DOWN
J. BRIGHT
DIMENSIONS:
TOLERANCES UNLESS
OTHERWISE SPECIFIED:
C
LOOSE PIECE PART NUMBER
12. OMISSION OF 6 CONTACTS MAX PER REEL OF 5000PCS
A
mm
WIRE BARRELS
FACE UP.
1471-9 (3/11)
B
MATERIAL
0 PLC
1 PLC
2 PLC
3 PLC
4 PLC
ANGLES
FINISH
0.5
0.25
0.15
0.15
2°
01JUN2012
J.AMBROSE
APVD
NAME
01JUN2012
M GREENER
TYPE
CHK
PRODUCT SPEC
APPLICATION SPEC
TE Connectivity
A
108-10042
SEE TABLE
SEE TABLE
CUSTOMER DRAWING
114-19000
WEIGHT
-
A2
00779
SIZE
III+, SIZE 16, PIN ASS'Y
LONG SERIES,
18-16 AWG, 2.0-2.5mm DIA INSULATION
CAGE CODE DRAWING NO
RESTRICTED TO
164161
SCALE
NTS
SHEET
1
OF
1
REV
-
M2
