M20 Connectors
Female Horizontal Surface Mount
Rear tail configuration, to allow mounting right up to the edge
of the PCB.
Supplied in Tape and Reel packaging as standard for use in
automated assembly systems.
2.54mm (.100") PITCH
SINGLE ROW
DOUBLE ROW
B
B
2.54
0.64
0.64
2.54
8.50
8.50
6.90
2.50
3.40
5.00
2.54
3.20
A
0.85
A
2 x 0.85
B
2.54
2.00
B
2.54
5.50
1.02
CALCULATION
A
B + 2.79
2.54 x (No. of contacts per row - 1)
1.00
2.00
Recommended PC Board Pattern
B
Recommended PC Board Pattern
HOW TO ORDER
M20 - 79 X XX 42 R
SERIES CODE
NO. OF ROWS
1
2
Single Row
Double Row
PACKAGING
R
Tape & Reeled
FINISH
42
Gold + Tin
NO. OF CONTACTS PER ROW
02 to 06, 08, 10
All dimensions in mm.
www.harwin.com
207
