EFM105: Description1 A, 200 V, SILICON, SIGNAL DIODE, DO-214AC; CategoryDiscrete semiconductor diode; File Size55KB，2 Pages; ManufacturerLRC; Websitehttp://www.lrc.cn

Download Datasheet Parametric Compare View All

EFM105 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	EFM105	-	-	View	Buy Now

EFM105 Overview

1 A, 200 V, SILICON, SIGNAL DIODE, DO-214AC

EFM105 Parametric

Parameter Name	Attribute value
Maker	LRC
package instruction	R-PDSO-C2
Reach Compliance Code	unknow
ECCN code	EAR99
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.25 V
JEDEC-95 code	DO-214AC
JESD-30 code	R-PDSO-C2
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-50 °C
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum repetitive peak reverse voltage	300 V
Maximum reverse recovery time	0.035 µs
surface mount	YES
Terminal form	C BEND
Terminal location	DUAL

Preview

Download Datasheet

View All

LESHAN RADIO COMPANY, LTD.

EFM101 – EFM106

1A FAST RECOVERY SMA DIODES

Marking

RRM

(V)

Package

Dimensions

TYPE

(A)

(V)

RMI

(µA)

P8M

(A)

(ns)

EFM101

EFM102

EFM103

EFM104

EFM105

EFM106

EF1

EF2

EF3

EF4

EF5

EF6

100

150

200

300

400

1.0

0.95

1.25

5.0

DO – 214AC

Trr

=1A, I

= 0.5A, I

= 0.25A

Trr Test Conditions: I

= 1A, I

= 0.5A, I

= 0.25A

.110(2.8)

.086(2.2)

.067(1.7)

.051(1.3)

.008 MAX

(.2)

.091(2.3)

.067(1.7)

.051(1.3)

.008(0.2)

.059(1.5)

.035(0.9)

.209(5.3)

.185(4.7)

.059(1.5)

.035(0.9)

DO – 214AC

50A–1/2
