This document was generated on 10/06/2017
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0752354159
Active
GbX® Backplane Connector System
4-Pair GbX Backplane Connector System, Right Guide Header, 80 Circuits, Gold (Au)
1.27µm, Pin Length 5.55mm
Documents:
Drawing (PDF)
Product Specification PS-75221-999-001 (PDF)
Agency Certification
UL
General
Product Family
Series
Application
Application Tooling Documents
Comments
Component Type
Overview
Product Name
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Durability (mating cycles max)
First Mate / Last Break
Flammability
Guide to Mating Part
Keying to Mating Part
Material - Plating Mating
Net Weight
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to PCB
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Electrical
Current - Maximum per Contact
Data Rate
Real Signals (per 25mm)
Shield Type
Shielded
Voltage - Maximum
Packaging Specification PK-70873-563 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
E29179
Backplane Connectors
75235
Backplane
TM-622022099
Right Guide Header, Keying Position E
PCB Header
GbX® Backplane Connector System
GbX
822350179850
80
80
200
No
94V-0
Yes
Yes
Gold
4.537/g
10
4
8
Vertical
2.20mm
No
Yes
1.60mm
Tray
1.85mm
1.85mm
No
Yes
Yes
105°C
1.0A
8.0 Gbps
108
Ground Plane Shield
Yes
120V AC (RMS)/DC
EU ELV
Not Relevant
EU RoHS
China RoHS
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Not Reviewed
Not Relevant
Not Reviewed
Search Parts in this Series
75235 Series
Mates With
75220 GbX Daughtercard
Solder Process Data
Lead-freeProcess Capability
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
N/A
PK-70873-563
PS-75221-999-001
SD-75235-410
