• Rugged Construction • Established Reliability (QPL)
• Extended WVDC up to 1500 VDC
ATC, the industry leader, is announcing new improved ESR/ESL
performance for the 700 B Series RF/Microwave Capacitors. The
superior high self-resonance and zero TCC characteristic of this Series
provide excellent performance over a broad range of RF and microwave
applications requiring minimum drift, including RF power. Porcelain
and ceramic construction provide a rugged, hermetic package.
ELECTRICAL AND MECHANICAL
SPECIFICATIONS
QUALITY FACTOR (Q):
Greater than 10,000 (0.1 pF to 200 pF) @ 1 MHz.
Greater than 2000 (220 pF to 1000 pF) @ 1 MHz.
Greater than 2000 (1100 pF to 5100 pF) @ 1 KHz.
TEMPERATURE COEFFICIENT OF CAPACITANCE (TCC):
0 ±30 PPM/°C (-55°C to +125°C)
INSULATION RESISTANCE (IR):
0.1 pF to 470 pF:
10
6
Megohms min. @ +25°C at rated WVDC.
10
5
Megohms min. @ +125°C at rated WVDC.
Typical functional applications: Bypass, Coupling, Tuning and DC Blocking.
510 pF to 5100 pF:
Typical circuit applications: Filters, Oscillators, Timing and RF Power
10
5
Megohms min. @ +25°C at rated WVDC.
Amplifiers.
10
4
Megohms min. @ +125°C at rated WVDC.
WORKING VOLTAGE (WVDC):
See Capacitance Values Table, page 2.
ENVIRONMENTAL TESTS
ATC 700 B Series Capacitors are designed and manufactured to meet and
exceed the requirements of EIA-198, MIL-PRF-55681 and MIL-PRF-123.
DIELECTRIC WITHSTANDING VOLTAGE (DWV):
250% of WVDC for capacitors rated at 500 volts DC or less for 5 seconds.
150% of WVDC for capacitors rated at 1250 volts DC or less for 5 seconds.
120% of WVDC for capacitors rated above 1250 volts DC for 5 seconds.
THERMAL SHOCK:
MIL-STD-202, Method 107, Condition A.
MOISTURE RESISTANCE:
MIL-STD-202, Method 106.
RETRACE:
Less than ±(0.02% or 0.02 pF), whichever is greater.
AGING EFFECTS:
None
PIEZOELECTRIC EFFECTS:
None
(No capacitance variation with voltage or pressure).
LOW VOLTAGE HUMIDITY:
MIL-STD-202, Method 103, Condition A, with 1.5 Volts DC applied
while subjected to an environment of 85°C with 85% relative humid-
ity for 240 hours min.
CAPACITANCE DRIFT:
±(0.02% or 0.02 pF), whichever is greater.
OPERATING TEMPERATURE RANGE:
0.1 to 200 pF: from -55°C to +175°C
220 to 5100 pF: from -55°C to +125°C
LIFE TEST:
MIL-STD-202, Method 108, for 2000 hours, at 125°C.
200% WVDC applied.
Voltage Applied:
TERMINATION STYLES:
Available in various surface mount and leaded styles.
See Mechanical Configurations, page 3.
200% of WVDC for capacitors rated at 500 volts DC or less.
120% of WVDC for capacitors rated at 1250 volts DC or less.
100% of WVDC for capacitors rated above 1250 volts DC.
TERMINAL STRENGTH:
Terminations for chips and pellets withstand a pull
of 5 lbs. min., 15 lbs. typical, for 5 seconds in direction perpendicular to the
termination surface of the capacitor. Test per MIL-STD-202, method 211.
ATC # 001-814 Rev.T, 4/18
ATC 700 B Capacitance Values
RATED WVDC CAP. CAP.
CAP. CAP.
TOL.
CODE (pF)
STD.
EXT. CODE (pF)
0R1
0R2
0R3
0R4
0R5
0R6
0R7
0R8
0R9
1R0
1R1
1R2
1R3
1R4
1R5
1R6
1R7
1R8
1R9
2R0
2R1
2R2
2R4
2R7
3R0
0.1
B
0.2
0.3
B, C
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
B, C, D 500
1.4
1.5
1.6
1.7
1.8
1.9
2.0
2.1
2.2
2.4
2.7
3.0
3R3
3R6
3R9
4R3
4R7
5R1
5R6
6R2
6R8
7R5
8R2
9R1
100
110
120
130
150
160
180
200
220
240
270
300
TOL.
RATED WVDC CAP. CAP.
STD.
EXT. CODE (pF)
330
360
390
430
470
510
560
620
680
750
820
910
101
111
121
131
151
161
181
201
221
241
271
301
TOL.
RATED WVDC CAP. CAP.
STD.
EXT. CODE (pF)
331
361
391
431
471
511
561
621
681
751
821
911
102
112
122
152
182
222
272
302
332
392
472
512
VOLT
TOL.
RATED WVDC
STD.
EXT.
1500
3.3
3.6
3.9
4.3
4.7
B, C, D
5.1
5.6
6.2
6.8
7.5
B, C, J
8.2
K, M
9.1
10
500
11
12
13
15
16
F, G, J,
K, M
18
20
22
24
27
30
1500
33
36
39
43
47
51
500
56
62
68
75
82
91
F, G, J
100
110
K, M
120
130
300
150
160
180
200
220
240
200
270
300
1500
EXT
1000
EXTENDED
N/A
330
360
390
200
430
470
510
560
620
680
750
820
150
910
F, G, J
1000
1100 K, M
1200
1500
1800
2200
50
2700
3000
3300
3900
4700
5100
EXTENDED VOLTAGE
EXTENDED VOLTAGE
VOLTAGE
N/A
EXTENDED VOLTAGE
VRMS = 0.707 x WVDC
• SPECIAL VALUES, TOLERANCES, HIGHER WVDC AND MATCHING AVAILABLE. PLEASE CONSULT FACTORY.
Capacitance values in
bold
type indicate porcelain dielectric. All other capacitance values indicate ceramic dielectric.
All 700 B Capacitors are available laser marked with ATC's identification, capacitance code and tolerance.
NOTE: EXTENDED WVDC DOES NOT APPLY TO CDR PRODUCTS.
ATC PART NUMBER CODE
ATC700 B 33 1 J W 500 X
Series
Case Size
Capacitance Code:
First 2 significant digits for capacitance.
R=Decimal Point
Indicates number of zeros following digits
of capacitance in picofarads except for decimal values.
Capacitance Tolerance
EXTENDED VOLTAGE
T
Packaging
T - Tape and Reel, 1000 pc. qty.*
TV - Vertical Orientation of Product,
Tape and Reel, 1000 pc. qty.*
I - Special Packaging. Consult Factory.
*
Consult ATC for other quantities
ATC Cap-Pac® packaging (100 pc. qty. std.) is also
available. For this option, leave last field blank.
Laser Marking
D
F
±1%
G
±2%
J
K
M
CAPACITANCE TOLERANCE
Code
Tol.
B
±0.1 pF
C
±0.25 pF ±0.5 pF
±5% ±10% ±20%
WVDC
Termination Code
The above part number refers to a 700 B Series (case size B) 330 pF capacitor,
J tolerance (±5%), 500 WVDC, with W termination (Tin/Lead, Solder Plated over Nickel Barrier), laser marking and ATC Cap-Pac
®
packaging.
ATC accepts orders for our parts using designations
with
or
without
the
“ATC” prefix. Both methods of defining the part number are equivalent,
i.e., part numbers referenced with the “ATC” prefix are interchangeable to
parts referenced without the “ATC” prefix. Customers are free to use either
in specifying or procuring parts from American Technical Ceramics.
For additional information and catalogs contact your ATC
representative or call direct at (+1-631) 622-4700.
Consult factory for additional performance data.
C E R A M I C S
ATC Asia
sales@atceramics-asia.com
A M E R I C A N
2
ATC North America
sales@atceramics.com
T E C H N I C A L
ATC Europe
saleseur@atceramics.com
ww w.a tc e r a m ics .c o m
ATC 700 B Capacitors: Mechanical Configurations
ATC
SERIES
& CASE
SIZE
ATC
TERM.
CODE
OUTLINES
MIL-PRF-
55681
CASE SIZE
& TYPE
W/T IS A
TERMINATION SURFACE
Y
BODY DIMENSIONS
INCHES (mm)
LENGTH
(L)
WIDTH
(W)
THICKNESS
(T)
LEAD AND TERMINATION
DIMENSIONS AND MATERIALS
OVERLAP
(Y)
MATERIALS
700B
W
CDR14BP
B
Solder Plate
Y
W
L
T
.110
+.020 -.010 .110 ±.015
(2.79
(2.79 ±0.38)
+0.51 -0.25)
.110
+.035 -.010 .110 ±.015
(2.79
(2.79 ±0.38)
+0.89 -0.25)
.110
+.020 -.010 .110 ±.015
(2.79
(2.79 ±0.38)
+0.51 -0.25)
.110
+.020 -.010 .110 ±.015
(2.79
(2.79 ±0.38)
+0.51 -0.25)
Tin / Lead, Solder Plated over
Nickel Barrier Termination
700B
P
CDR14BP
B
Pellet
Y
L
W
T
Heavy Tin/ Lead Coated,
over Nickel Barrier
Termination
.102 (2.59) .015 (0.38)
max.
±.010 (0.25)
700B
T
N/A
B
RoHS Compliant
Tin Plated over
Nickel Barrier Termination
W
L
T
Solderable
Nickel Barrier
Y
RoHS Compliant
Gold Plated over
Nickel Barrier Termination
Length
( LL )
Width Thickness
( WL )
( TL )
700B
CA
CDR13BP
B
Gold Chip
W
L
T
700B
MS
CDR21BP
B
Microstrip
B
Axial Ribbon
.110 ±.015
(2.79 ±0.38
.135 ±.015
(3.43 ±0.38)
.120 (3.05)
max.
700B
AR
CDR22BP
.250
(6.35)
min.
.093
±.005
(2.36
±0.13)
.004
±.001
(.102
±.025)
700B
RR
CDR24BP
B
Radial Ribbon
N/A
.102 (2.59)
max.
700B
RW
CDR23BP
B
Radial Wire
.145 ±.020
(3.68 ±0.51)
.500
(12.7)
min.
#26 AWG.,
.016 (.406) dia.
nominal
700B
AW
CDR25BP
B
Axial Wire
Additional lead styles available: Narrow Microstrip (NM), Narrow Axial Ribbon (NA) and Vertical Narrow Microstrip (H). Other lead lengths are available; consult factory.
All leads are high purity silver attached with high temperature solder and are
RoHS
compliant. For a complete military catalog, request American Technical Ceramics
document ATC 001-818.
A M E R I C A N
ATC North America
sales@atceramics.com
T E C H N I C A L
ATC Europe
saleseur@atceramics.com
C E R A M I C S
ATC Asia
sales@atceramics-asia.com
3
w w w.a t c e ra m ic s .c o m
ATC 700 B Capacitors: Non-Magnetic Mechanical Configurations
ATC
SERIES
& CASE
SIZE
ATC
TERM.
CODE
OUTLINES
MIL-PRF-
55681
CASE SIZE
& TYPE
W/T IS A
TERMINATION SURFACE
Y
*
BODY DIMENSIONS
INCHES (mm)
LENGTH
(L)
WIDTH
(W)
THICKNESS
(T)
LEAD AND TERMINATION
DIMENSIONS AND MATERIALS
OVERLAP
(Y)
MATERIALS
700B
WN
Meets
Require-
ments
B
Non-Mag
Solder Plate
Y
W
L
T
.110
+.025 -.010 .110 ±.015
(2.79
(2.79 ±0.38)
+0.64 -0.25)
Tin/ Lead, Solder Plated over
Non-Magnetic Barrier
Termination
700B
PN
Meets
Require-
ments
B
Non-Mag
Pellet
Y
W
L
T
.110
Heavy Tin/ Lead Coated, over
+.035 -.010 .110 ±.015 .102 (2.59) .015 (0.38)
Non-Magnetic Barrier
(2.79
(2.79 ±0.38)
max.
±.010 (0.25)
Termination
+0.89 -0.25)
.110
+.025 -.010 .110 ±.015
(2.79
(2.79 ±0.38)
+0.64 -0.25)
700B
TN
Meets
Require-
ments
RoHS Compliant
Tin Plated over
Non-Magnetic Barrier
Termination
.120 (3.05)
max.
Length
( LL )
Width Thickness
( WL )
( TL )
B
Non-Mag
W
L
T
Solderable
Barrier
B
Non-Mag
Microstrip
B
Non-Mag
Axial Ribbon
700B
MN
Meets
Require-
ments
700B
AN
Meets
Require-
ments
.135 ±.015
(3.43 ±0.38)
.250
(6.35)
min.
.110 ±.015
(2.79 ±0.38)
.106 (2.69)
max.
N/A
.093
±.005
(2.36
±0.13)
.004
±.001
(.102
±.025)
700B
FN
Meets
Require-
ments
B
Non-Mag
Radial Ribbon
700B
RN
Meets
Require-
ments
B
Non-Mag
Radial Wire
.145 ±.020
(3.68 ±0.51)
700B
BN
Meets
Require-
ments
.500
(12.7)
min.
#26 AWG.,
.016 (.406) dia.
nominal
B
Non-Mag
Axial Wire
*Capacitors with values greater than 200 pF contain a trace magnetic element that may exhibit weak magnetic properties.
**Additional lead styles available: Narrow Microstrip (DN), Narrow Axial Ribbon (GN) and Vertical Narrow Microstrip (HN). Other lead lengths are available;
consult factory; All leads are high purity silver attached with high temperature solder and are
Will Xmega replace the mega series? I looked at the information and found that Xmega is too powerful, especially the new A1U A3U series with USB, which is super awesome. It seems that A3U is available...
I'm selling the EasyARM8962 board. I've never used it, so it's very new and has everything. Now I'm working on an STM32 project, so I don't need the board anymore, so I want to sell it at a low price....
Adopt the transparent transmission mode, use the single chip microcomputer to send instructions to the wireless module, and realize the configuration of the wireless module. A wireless module is set a...
This article details the latest developments in power circuits. It also introduces several devices that illustrate how advances in circuit architecture and packaging technology have led to smaller pow...
1.How to debug MFC program under WinCE6.0 in VS2005? Can anyone give a detailed explanation? 2.I get an error every time I deploy after clicking DEBUG. The details are as follows: 1>------ Deploy star...
Microchip's PIC18F46J50 is a low-power, high-performance 8-bit USB microcontroller (MCU) using nanoWatt XLP technology. The current in deep sleep mode can be as low as 13nA, the operating voltage i...[Details]
System design is a complex process. It is not enough to just use ICs. There are many details to consider. This article uses a high-fidelity music playback system as an example to introduce how to s...[Details]
1 Introduction
With the acceleration of the pace of urban modernization, society has higher requirements for urban road lighting and urban lighting projects. The state has clearly required tha...[Details]
Two simple circuits are implemented to drive two LEDs from a battery powered microprocessor.
This design is based on a circuit that uses three resistors and a microprocessor I/O pin as an input h...[Details]
This paper establishes a fuel cell engine test platform based on the NI integrated hardware and software environment. This platform can realize the test and control of fuel cell engines and their a...[Details]
Microcalorimetry
is used to determine energy relationships. Microcalorimetry techniques are often required when performing calorimetric experiments with small sample sizes or slow heating rat...[Details]
1. With the development of modern industry and the continuous improvement of automation, some medium and large control systems have been greatly facilitated, which not only makes control easier, bu...[Details]
I. Introduction
Since RS232 has a short communication distance (only 15 meters according to EAT/TAI-232 standard), and can only perform point-to-point communication, it cannot directly f...[Details]
This week, Microsoft held its 2012 Microsoft Worldwide Partner Conference (WPC) in Toronto, Canada. At the conference, Microsoft showed its new products and services to partners around the world. A...[Details]
The potentiometer is an adjustable electronic component. The main functions of the potentiometer in the circuit are as follows:
1. Used as a voltage divider
A potentiometer is a continuou...[Details]
Digital array radar (DAR) uses digital beam forming (DBF) in both receiving and transmitting modes to achieve flexible distribution and reception of RF signal power in the airspace, obtain excellent t...[Details]
TC9012F is a universal CMOS large-scale integrated circuit for infrared remote control signal transmission, suitable for remote control of TV, VTR, laser player and other equipment. In the market, ...[Details]
introduction
At present, measuring instruments are developing towards networking, and each individual embedded instrument will become a node on the Internet. This system realizes the network...[Details]
In the "digital pressure measurement" experimental device of applied physics, the subject technical knowledge of analog circuits, digital circuits, sensors and single-chip microcomputers is used. In o...[Details]
People who often surf the Internet until late at night, their families always complain that turning on the big lights in the living room affects their rest, but some people don't have keyboard ligh...[Details]
Microchip MCU
京公网安备 11010802033920号
EEWORLD
