1/10
Magnetic Switch
Reference Only
MRSS29DR
Data Sheet
Sensor Products Division
1. Scope
This data sheet is applied to the magnetic switch MRSS29DR
2. Part number
2-1 Part Description
Magnetic Switch
2-2 Murata Part Number MRSS29DR
3. Dimensions and Schematics
3-1 Dimensions
「 」8
5
1.1~1.4
Coplanarity : less than 0.1mm(includiong under reflow condition)
Dimension
Ⅰ.
Ⅰ.
Ⅰ.
(E.g.)
「」8
5
↓ ↓ ↓
ⅠⅠⅠ
Control code...One alphabetic character
Manufactured year...The last digit of the year
Manufactured month..
Jan to Sep : 1 to 9
Oct to Dec : X, Y, Z
Murata Manufacturing Co., LTD.
2/10
Marking Example
0.8
1.0
0.95
1.9
0.95
(Unit：㎜)
Reference mount pad
3-2 Block wiring diagram
Voltage
regulator
R1
R2
Op-Amp
Drive½
R3
R4
ＧＮＤ
R1½R4：MR Elements
3-3 Direction of applied magnetic field
Gnd
Gnd
Out
A direction
Vcc
Out
B direction
2.4
Ｖ½½
ＯＵＴ
Vcc
Murata Manufacturing Co., LTD.
3/10
3-5
Electric Characteristics/ Absolute Maximum Rating (Ta=+25
o
C Vcc=12V)
Parameter
Supply voltage
Absolute max. supply voltage
Current consumption
Symbol
V
cc
－
I
cc
H
on
H
off
f
RL
V
OH
V
OL
8
9
Operating temp. range
Storage temp. range
－
－
Conditions
－
－
－
+25℃
+25℃
+25℃
－
Vcc=12V
R
L
=10kΩ
Vcc=12V
R
L
=10kΩ
－
－
-40
-40
－
－
+85
+125
o
o
Min.
3.5
－
－
－
1.2
5
10
11.4
－
Typ.
12
－
－
－
－
－
－
－
－
Max.
30
40.0
1.5
3.2
－
－
－
－
Unit
V
V
mA
mT
kHz
kΩ
V
1
2
3
Operating magnetic field
4
（B
direction 2mT）
5
6
7
Frequency response
Load Resistance
Output Voltage
0.3
V
C
C
NOTE1)
NOTE2)
Each specification is defined by testing above items individually.
Sensitivity selection of this product is performed at Vcc=12V. Operating magnetic field can possibly
change when applying the supply voltage other than 12V. Please consult with us for technical assistance
when you consider the supply voltage other than 12V, as a special attention needs to be given in the
design.
3-6 Packing information
Form of packing
Reel dimension
Tape & reel
φ180
Pcs per reel
3000pcs
Murata Manufacturing Co., LTD.
4/10
3-7 Taping specifications
3-7-1 Taping dimensions
½
δ
δ
Ｊ
Ｈ
Ａ
Ｄ
θθ
Ｋ
0
Ｋ
1
Ｋ
Ｇ
Ｆ
Ｅ
Ｂ
Unit:mm
Parameter
Length
Width
Pocket
Depth
Pitch
Diameter
Feed hole
Pitch
Position
Overall thickness
Symbol
A
B
K
0
F
J
H
E
K
Size/
Angle
3.35±0.1
3.2±0.1
1.4±0.1
4.0±0.1
+0.1
φ1.5
-0.05
4.0±0.1
1.75±0.1
0.98±0.1
Parameter
Dist. Between
center lines
Cover tape
Carrier tape
L direction
W direction
Width
Width
Thickness
Depth
Tilt
Symbol
G
D
W
C
T
K
1
θ
Size/
Angle
2.0±0.05
3.5±0.05
+0.3
5.5
-0
8.0±0.1
0.2±0.05
1.5±0.1
30°MAX
Device
3-7-2
Reel dimensions...EIAJ PRV08B compliant
θ
1
Ｗ
Ｃ
θ
2
Unit: mm
Item
Diameter
Ｃ
Ｂ
Ａ
Symbol
A
W
B
Dim/Angle
φ178±2
9±0.5
φ60±1
Dis. between flanges
Diameter
Hub slit position
Spindle hole diam.
Key slit position
Marking
θ1
90°
C
φ13±0.5
θ2
120°
Labeled on one side of
flange
Ｗ
Murata Manufacturing Co., LTD.
5/10
3-7-3
Start/End of taping
Reel label A (example)
Trailer 160mm or more
Product containing part
Leader
Product containing part
Empty part:
100mm or more
Leader:
Cover tape
400mm or more
Reel label B (example)
3-7-4 Other notes
Continuously missing device shall not exceed 2 pcs.
Peeling strength of the cover tape: 0.1 to 0.7N.
Murata Manufacturing Co., LTD.
