A41
1.30
.09
for #4
self tapping
screw
3.72
Insert Area
NOTES:
1) When machine or I-plates modifications are required,
use the center of the enclosure to dimension.
.52
for
non-skid
feet
3.02
6.77
.30
typ.
6.62
Insert
Area
5.00
5.50
Top
Internal
Insert
Area
5.70
5.92
.32
1.00
6.62
Insert
Area
7.11
.12
typ.
.25
.42
.10
3.27
Top Internal
Insert Area
4.30
4.38
1.30
15°
3.72
Insert Area
5.00
4.63
.93 1.05
4.25
45°
PART
NO.
2018
2019
2020
6006
DESCRIPTION
A41 TOP
A41 BOTTOM
A41 END PANEL
SCREW 4x3/4” PHILFLAT (4)
PART NO.
51
2020IR
2020CL
2020DB9
2020DB25
ACCSESSORIES
DESCRIPTION
NON SKID FEET
A41 INFRARED PANEL
A41 CLEAR PANEL
DB9 CUT OUT PANEL
DB25 CUT OUT PANEL
.06
4.30
Insert plate
4.75
.09
.11
ALL DIMENSIONS ARE ± .010"
5/22/13
2009 Wright Ave., La Verne, CA 91750
Ph. (626) 331-0517 Fx. (626) 331-8584 www.serpac.com
