100.80
[3.969 in]
For 100mm wide PCB
1.75
[.069 in]
DETAIL A
1.50
[.059 in]
60.00
[2.362 in]
47.00
[1.850 in]
Extrusion
2.00
[.079 in]
B
97.30
[3.831 in]
2.00
[.079 in]
4.50
[.18]
4.20
[.165 in]
8.00
[.315 in]
Bezel
2.70
[.106 in]
52.60
[2.071 in]
A
4.50
[.177 in]
4.20
[.165 in]
7.10
[.280 in]
7.20
[.283 in]
105.00
[4.134 in]
DETAIL B
4.50
[.177 in]
165.00
[6.496 in]
2.00
[.079 in]
5.70
[.224 in]
3.30
[.130 in]
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc.)
Contact Factory
mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES.
(Part number and text placement/orientation on our products are subject to change,
we do not recommend using them as a locating reference for modification purposes)
23.50
2.50
[.925 in] [.098 in]
End Plate
2.0
[.079 in]
Screw #4x1/2 Pan Head
3.40
3.50
[.13]
BEZEL
C
8.00
[.315 in]
END PLATE
[.14]
NOTE
Purchased assembly includes Extrusion, 2 End Plate, 2 Bezels and 8 screws
Recommended Cover screw torque -- 2.5-3.5 lbf-in (30-40 cN-m)
64.50
[2.539 in]
D
52.55
[2.069 in]
97.30
[3.831 in]
46.50
[1.831 in]
97.30
[3.831 in]
52.55
[2.069 in]
D
59.50
[2.343 in]
PART NUMBERS
SINK BOX
Extrusion Aluminum Alloy / Black Anodized
Extrusion Aluminum Alloy / Clear Anodized
ACCESSORIES
431621
531621
031624
131624
2.00
[.079 in]
97.30
[3.831 in]
C
SECTION C-C
1.15
[.05]
104.50
[4.114 in]
End Plate Aluminum Alloy / Black Anodized
End Plate Aluminum Alloy /Clear Anodized
SECTION D-D
3.00
[.118 in]
Dimensions:
mm
[inches]
SINK BOX
31621
