11/2/2017
5000-12000 BTU/H Indoor Air Conditioner (DTS Series) - Hammond Mfg.
Quality Products. Service Excellence.
5000-12000 BTU/H Indoor Air Conditioner
DTS Series
Type 12, Side Mounting
Description
Designed for side mounting on any enclosure surface where high capacity system cooling
is required.
Closed loop cooling ensures clean enclosure air is recirculated
without ever mixing with contaminated ambient air.
Optimum air circulation with maximum clearance distance between warm inlet and cold
outlet for reduced hot spot locations.
Condensor with 3 mm fin spacing, highly effective protection
against strongly contaminated and aggressive ambient air
Standards
Maintains enclosure's NEMA 12 rating
IP 54
UL, cUL and CE
Features
R134a refrigerant.
Thermostat control accessible from inside enclosure.
Hot gas bypass valve prevents evaporator freeze up while
minimizing heavy inrush currents on large BTU/H units.
Built in condensate evaporator.
Continuous air circulation from high capacity fans.
EMI/RFI suppression meets CE.
Self-diagnostics on startup.
Fault indication via LED light.
Provision for door contact allowing power down when
enclosure door is opened.
Gasket, mounting kit and template for enclosure cutout and
drilling are included.
Condensate drain hose and clamp provided.
Accessories
Gasket Kits
Filter Kits
Condensate Bottle
Remote Door Switches
Water Condensate Evaporator
https://www.hammfg.com/electrical/products/climate/dts3x45
1/3
11/2/2017
5000-12000 BTU/H Indoor Air Conditioner (DTS Series) - Hammond Mfg.
Part Number
DTS3145A115LG
DTS3145A230LG
DTS3145A460LG
DTS3245A115LG
DTS3245A230LG
DTS3245A460LG
**For ANSI 61 Gray replace LG with GY
A
36.65
36.65
36.65
53.00
54.00
54.00
B
11.89
11.89
11.89
16.00
16.00
16.00
C
14.40
14.40
14.40
14.40
14.40
14.40
Electrical
Data
Rated
Voltage
Range of
Operation
DTS3145A115LG DTS3145A230LG DTS3145A460LG DTS324
115 V 60 Hz
103-127 V
230 V 50/60 Hz
198-252 V
1020 W
4.5 A
26 A
Terminal Block
460 V 50/60 Hz
360-506 V
1283 W
1.8 A
16 A
Terminal Block
115 V 6
103-127
1600 W
13 A
57 A
Termina
Power
1000 W
Consumption
Running
Amps
Starting
Current
Line Cord
8.5 A
48 A
Terminal Block
Refrigeration
Data
DTS3145A115LG
Cooling
Capacity
Type of
Refrigerant
Adjustable
Control
Range
Max. Ambient
Air Temp
6142 BTU (1800 W)
134a
+ 77…+ 131 / + 25…'+
45C Factory setting
+95/+35C
+131 F (+55 C)
DTS3145A230LG
6995 BTU (2050 W)
134a
+ 77…+ 131 / + 25…'+
45C Factory setting
+95/+35C
+131 F (+55 C)
+59 F (+15 C)
DTS3145A460LG
6995 BTU (2015 W)
134a
+ 77…+ 131 / + 25…'+
45C Factory setting
+95/+35C
+131 F (+55 C)
+59 F (+15 C)
DTS3245A115LG
11600 BTU (3400 W)
134a
+ 77…+ 131 / + 25…'+
45C Factory setting
+95/+35C
+131 F (+55 C)
+59 F (+15 C)
DTS3245A230LG
11000 BTU (3200 W)
134a
+ 77…+ 131 / + 25…'+
45C Factory setting
+95/+35C
+131 F (+55 C)
+59 F (+15 C)
DTS3245A460LG
12000 BTU (3500 W)
134a
+ 77…+ 131 / + 25…'+
45C Factory setting
+95/+35C
+131 F (+55 C)
+59 F (+15 C)
Min. Ambient
+59 F (+15 C)
Air Temp
Air Capacity Internal Circulation 341 Internal Circulation 341 Internal Circulation 341 Internal Circulation 706 Internal Circulation 706 Internal Circulation 706
(unrestricted) CFM
CFM
CFM
CFM
CFM
CFM
Condonsate
Discharge
Filter Mat
Db Noise
Level
Unit Weight
Condensate Evaporator Condensate Evaporator Condensate Evaporator Condensate Evaporator Condensate Evaporator Condensate Evaporator
Filterless
<70 dB(A)
108 lbs/49 kg
Filterless
<70 dB(A)
108 lbs/49 kg
Filterless
<70 dB(A)
108 lbs/49 kg
Filterless
<70 dB(A)
108 lbs/49 kg
Filterless
<70 dB(A)
108 lbs/49 kg
Filterless
<70 dB(A)
108 lbs/49 kg
Exterior Case Galvanized Sheet Steel Galvanized Sheet Steel Galvanized Sheet Steel Galvanized Sheet Steel Galvanized Sheet Steel Galvanized Sheet Steel
https://www.hammfg.com/electrical/products/climate/dts3x45
2/3
11/2/2017
Refrigeration
Data
DTS3145A115LG
Finish LG
Finish GY
Nema Rating
RAL7035 Light Gray
ANSI 61 Gray
Enclosures IP 54 /
Nema 12
5000-12000 BTU/H Indoor Air Conditioner (DTS Series) - Hammond Mfg.
DTS3145A230LG
RAL7035 Light Gray
ANSI 61 Gray
Enclosures IP 54 /
Nema 12
DTS3145A460LG
RAL7035 Light Gray
ANSI 61 Gray
Enclosures IP 54 /
Nema 12
DTS3245A115LG
RAL7035 Light Gray
ANSI 61 Gray
Enclosures IP 54 /
Nema 12
DTS3245A230LG
RAL7035 Light Gray
ANSI 61 Gray
Enclosures IP 54 /
Nema 12
DTS3245A460LG
RAL7035 Light Gray
ANSI 61 Gray
Enclosures IP 54 /
Nema 12
Data subject to change without notice
© 2017. Hammond Manufacturing Ltd. All rights reserved.
https://www.hammfg.com/electrical/products/climate/dts3x45
3/3
