3800 Series
Flat Coil SM Power Inductors
SELECTION GUIDE
Order Code
38L361C
38L801C
38L142C
38L222C
38L322C
38L432C
38L572C
38L722C
38L882C
38S221C
38S451C
38S801C
38S132C
38S182C
38S252C
38S322C
38S402C
38S502C
38H151C
38H301C
38H501C
38H801C
38H122C
38H152C
38H202C
38H252C
38H302C
Inductance
(100kHz, 0.1V
AC
)
±20%
μH
0.36 ±30%
0.80
1.40
2.20
3.20
4.30
5.70
7.20
8.80
0.22 ±30%
0.45
0.80
1.30
1.80
2.50
3.20
4.00
5.00
0.15 ±30%
0.30 ±30%
0.50
0.80
1.20
1.50
2.00
2.50
3.00
DC
Current
1
Max.
A
18
16
12.0
9.6
7.8
6.8
5.8
5.3
4.8
18
16
12.5
10.5
9.0
7.2
6.5
5.5
4.9
18
16
12.5
10.5
9
7.2
6.5
5.5
4.9
Saturation
Current
2
Typ.
A
27
20
15
12
10
8.8
7.3
6.6
5.9
35
27
20
17
14
12
10
9.1
8.1
38
32
24
20
17
14
12
11
9.4
DC
Resistance
Max.
mΩ
1.8
2.5
3.7
5
6.8
9.7
11.9
15.5
19.6
2.2
2.6
3.7
5
6.8
9.7
11.9
15.1
20.3
1.9
2.2
3.7
5
6.8
9.5
11.8
15.1
19.4
FEATURES
RoHS compliant
High current, low DCR
Surface mount
UL94 V-0 package materials
Pick & place compatible
J-STD-020D reflow
Backward compatible with Sn/Pb
soldering systems
DESCRIPTION
The 3800 series is a range of surface mount, flat
coil wound power inductors that is designed for
use where high current and low loss is essential,
such as in laptop computers and plasma screens.
ABSOLUTE MAXIMUM RATINGS
Operating temperature range
Storage temperature range
-40°C to +130°C
-40°C to +150°C
SOLDERING INFORMATION
3
Peak reflow temperature
Pin finish
Moisture sensitivity level
245°C
Matte tin
1
PACKAGING INFORMATION
Tape & Reel
All specifications typical at T
A
=25°C
1 The maximum DC Current is the value at which the inductance falls to 65% (tolerance ±30%) or 75%
(tolerance: ±20%) of its zero current value or until its temperature rise reaches 40°C, whichever is sooner.
2 The saturation current is the continuous current at 20°C ambient at which the inductance falls to 65% (tolerance:
±30%) or 75% (tolerance: ±20%) of its zero current value.
3 For further information, please visit www.murata-ps.com/rohs
4 Terminal 3 is open-circuit and for mounting stability only.
650 per reel
For full details go to
www.murata-ps.com/rohs
www.murata-ps.com/support
KMP_3800C_A04
Page 1 of 4
3800 Series
Flat Coil SM Power Inductors
INDUCTANCE Vs CURRENT (LOW DCR TYPES)
10
8.8μH
4.3μH
Inductance, L (μH)
1.4μH
1
0.36μH
0.1
0.1
1
10
100
Current, I
DC
(A)
INDUCTANCE Vs CURRENT (STANDARD TYPES)
10
5.0μH
2.5μH
Inductance, L (μH)
1
0.8μH
0.22μH
0.1
0.1
1
10
100
Current, I
DC
(A)
INDUCTANCE Vs CURRENT (HIGH POWER TYPES)
10
3.0μH
Inductance, L (μH)
1.5μH
1
0.5μH
0.15μH
0.1
0.1
1
10
100
Current, I
DC
(A)
www.murata-ps.com/support
KMP_3800C_A04
Page 2 of 4
3800 Series
Flat Coil SM Power Inductors
TEMPERATURE Vs CURRENT (LOW DCR TYPES)
50
8.8μH
4.3μH
1.4μH
Temperature rise above ambient, t (ºC)
0.36μH
40
30
20
10
0
0
5
10
15
20
25
Current, I
DC
(A)
TEMPERATURE Vs CURRENT (STANDARD TYPES)
50
Temperature rise above ambient, t (ºC)
5.0μH
40
2.5μH
0.22μH
0.8μH
30
20
10
0
0
5
10
15
20
25
Current, I
DC
(A)
TEMPERATURE Vs CURRENT (HIGH POWER TYPES)
50
3.0μH
1.5μH
Temperature rise above ambient, t (ºC)
0.5μH
0.15μH
40
30
20
10
0
0
5
10
15
20
25
Current, I
DC
(A)
www.murata-ps.com/support
KMP_3800C_A04
Page 3 of 4
3800 Series
Flat Coil SM Power Inductors
1
PACKAGE SPECIFICATIONS
MECHANICAL DIMENSIONS
4
10.4 (0.409)
Max.
5.6 (0.220)
Max.
1.4±0.2
(0.055±0.008)
RECOMMENDED FOOTPRINT DETAILS
1.9
(0.075)
2.4
(0.094)
38LXXXC
XYYWW
3
10.4
(0.409)
Max.
6.70±0.3
(0.264±0.012)
2.0
(0.079)
8.6
(0.339)
2
1
2.6±0.2
(0.102±0.008)
5.5±0.3
(0.217±0.012)
3.6
(0.142)
2.7
(0.106)
2.8
(0.11)
All dimensions in mm (inches).
Package weight: 1.7g Typ.
11 (0.433)
All dimensions in mm (inches).
TAPE & REEL SPECIFICATIONS
TAPE OUTLINE DIMENSIONS
1.75 (0.069)
(0
.0
59
)
2 (0.079)
4 (0.157)
1.
5
16.0 (0.630)
0.5 (0.020)
5.75 (0.226)
24.0 (0.945)
11.5
(0.453)
1.
5
(0
.0
59
)
10.5
(0.413)
Direction of unreeling
All dimensions in mm (inches).
Murata Power Solutions, Inc.
11 Cabot Boulevard, Mansfield, MA 02048-1151 U.S.A.
ISO 9001 and 14001 REGISTERED
Murata Power Solutions, Inc. makes no representation that the use of its products in the circuits described herein, or the use of other
technical information contained herein, will not infringe upon existing or future patent rights. The descriptions contained herein do not imply
the granting of licenses to make, use, or sell equipment constructed in accordance therewith. Specifications are subject to change without
notice.
© 2016 Murata Power Solutions, Inc.
www.murata-ps.com/support
KMP_3800C_A04
Page 4 of 4
10.7
(0.421)
38LXXXC
XYYWW
38LXXXC
XYYWW
