Surface Mount Polyester (PET) Film Capacitor
MDC Series Dual In-Line, 50 – 630 VDC, High Current
Overview
Dual in-line (DIL) metallized polyester (PET) film capacitor
for surface mounting. Encapsulation in self-extinguishing
material meeting the requirements of UL 94 V–0.
Applications
Typical applications include high frequency switched-mode
power supplies, DC/DC converters and input/output filtering.
Benefits
Rated voltage: 50 – 630 VDC
Rated voltage: 30 – 220 VAC
Capacitance range: 0.033 – 15 µF
Capacitance tolerance: ±5%, ±10%, other tolerances on
request
• Climatic category: 55/125/56
• RoHS Compliant and lead-free terminations
• Operating temperature range of −55˚C to +125˚C
•
•
•
•
Legacy Part Number System
MDC
Series
Dual In-Line,
Metallized
Polyester
10
Lead Spacing
(mm)
10
15
333
Capacitance Code (pF)
First two digits indicate
the two most significant
digits of the capacitance
value in picofarads. The
third digit is the number
of following zeros.
K
Capacitance
Tolerance
J = ±5
K = ±10%
Other tolerances
on request.
50
Rated Voltage
(VDC)
50
100
250
400
630
A52
Size Code
See Dimension
Table
P3
Number of Leads
per Side
P3 = 3 leads
P4 = 4 leads
P5 = 5 leads
P7 = 7 leads
P8 = 8 leads
TUBE
Packaging
See Ordering
Options Table
New KEMET Part Number System
F
Capacitor
Class
F = Film
15
Series
Dual In-Line,
Metallized
Polyester
3
3 = 3 leads
4 = 4 leads
5 = 5 leads
7 = 7 leads
8 = 8 leads
A
A = 10
B = 15
A
Size Code
A=
Standard
box size
333
Capacitance Code (pF)
First two digits indicate
the two most significant
digits of the capacitance
value in picofarads. The
third digit is the number
of following zeros.
K
Capacitance
Tolerance
J = ±5
K = ±10%
Other
tolerances on
request
050
Rated Voltage
(VDC)
050 = 50
100 = 100
250 = 250
400 = 400
630 = 630
T
Packaging
See Ordering
Options Table
Number of Lead Spacing
Leads per Side
(mm)
One world. One KEMET
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 • 864-963-6300 • www.kemet.com
F3074_MDC • 9/22/2016
1
Surface Mount Polyester (PET) Film Capacitor
MDC Series Dual In-Line, 50 – 630 VDC, High Current
Ordering Options Table
Packaging Type
Standard Packaging Options
Case Size
A53
Bulk (Tube)
Tape & Reel (Standard
Reel)
T
VV687
TUBE
TR32
KEMET
Legacy
Packaging Packaging
Code
Code
Dimensions – Millimeters
L
LL
Center line
B
H1
L3
See note
W
Board
mounting
surface
H
P1
X
Y
P2
L2
P3
Z
H
+/-0.2
6.05
9.0
6.05
6.05
6.05
6.05
9.0
6.05
6.05
6.05
6.05
9.0
11.0
9.0
11.0
Legacy Leads P1
P2 P3
(1)
B
Size
per
Code
Side
+/-0.2 +/-0.2 +/-0.2 +/-0.2
A52
A53
A54
A55
B53
B55
A53
A54
A55
B55
A55
A57
A58
A57
A58
3
3
3
3
3
3
4
4
4
4
5
7
7
8
8
10.0
10.0
10.0
10.0
15.0
15.0
10.0
10.0
10.0
15.0
10.0
10.0
10.0
10.0
10.0
2.54
2.54
2.54
2.54
2.54
2.54
2.54
2.54
2.54
2.54
2.54
2.54
2.54
2.54
2.54
5.08
5.08
5.08
5.08
5.08
5.08
7.62
7.62
7.62
7.62
10.16
15.24
15.24
17.78
17.78
12.2
12.7
12.2
12.2
16.5
16.5
12.7
12.2
12.2
16.5
12.2
12.7
12.7
12.7
12.7
L
+/-0.2
11.0
14.0
13.5
16.5
11.0
12.2
14.0
13.5
16.5
12.2
16.5
23.0
23.0
23.0
23.0
H1
+/-0.4
7.75
10.5
7.75
7.75
7.75
7.75
10.5
7.75
7.75
7.75
7.75
10.7
12.5
10.7
12.5
L2
L3
(2)
W
X
Y
Z
LL
+/-0.2
Maximum
+/-0.05 +/-0.05
2.96
4.46
4.21
5.71
2.96
3.56
3.19
2.94
4.44
2.29
3.17
3.88
3.88
2.61
2.61
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
+/-0.2
Nominal
+/-0.2
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
0.25
0
0.25
0.25
0.6
0.6
0
0.25
0.25
0.6
0.25
0
0
0
0
1.7
1.5
1.7
1.7
1.7
1.7
1.5
1.7
1.7
1.7
1.7
1.7
1.5
1.7
1.5
Drawing shows MDC with three leads per side. Similar dimensional requirements apply to the 4, 5, 7, and 8 leads per side configurations.
(1) P3 represents the cumulative tolerance of all leads.
(2) L3 represents the extent to which the center line of the leads misaligns with the center line of the body. Dimension shown is the maximum such
misalignment allowed.
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 • 864-963-6300 • www.kemet.com
F3074_MDC • 9/22/2016
2
Surface Mount Polyester (PET) Film Capacitor
MDC Series Dual In-Line, 50 – 630 VDC, High Current
Performance Characteristics
Rated Voltage (VDC)
Rated Voltage (VAC)
Capacitance Range (µF)
Capacitance Tolerance
Category Temperature Range
Rated Temperature
Voltage Derating
Climatic Category
Test Voltage
50
30
0.033 – 15
100
63
0.033 – 10
250
160
0.033 – 1.5
400
200
0.033 – 0.47
630
220
0.033 – 0.18
±5%, ±10%, other tolerances on request
-55°C to +125°C
+85°C
The rated voltage is decreased with 1.25%/°C from +85°C
55/125/56
1.6 x V
R
, 60 seconds
Measured at +20°C According to IEC 60384–2
Minimum Value Between Terminals
Insulation Resistance
V
R
≤ 100
V
R
> 100
C ≤ 0.1 µF
Dissipation Factor
1 kHz
10 kHz
100 kHz
Self Inductance
Approximately 4 nH
0.8%
1.5%
2.5%
C ≤ 0.33 µF
15,000 MΩ
30,000 MΩ
Maximum Values at +23°C
0.1 < C < 3.3 µF
0.8%
1.5%
5.0%
C > 0.33 µF
5,000 MΩ • µF
10,000 MΩ • µF
3.3 ≤ C ≤ 10 µF
0.8%
1.5%
C > 10 µF
0.8%
2.0%
Typical Capacitance vs.
Temperature at 1 kHz
Typical Dissipation Factor vs.
Temperature at 1 kHz
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 • 864-963-6300 • www.kemet.com
F3074_MDC • 9/22/2016
3
Surface Mount Polyester (PET) Film Capacitor
MDC Series Dual In-Line, 50 – 630 VDC, High Current
Maximum RMS Voltage V
rms
(V) vs. Frequency
Value
1.0 μF
2.2 μF
3.9 μF
4.7 μF
6.8 μF
10 μF
Rated
Voltage
250 V
100 V
100 V
100 V
100 V
100 V
Case
Size
A57
A52
A52
A54
A57
A58
1 kHz
150.0
50.0
50.0
50.0
50.0
50.0
10 kHz
36.0
25.0
18.0
16.0
15.5
15.0
100 kHz
9.2
5.0
4.0
3.5
2.2
2.0
500 kHz
2.9
1.2
1.0
0.7
0.5
0.4
1 MHz
1.3
0.6
0.3
0.2
0.2
0.2
Maximum RMS Current I
rms
(A) vs. Frequency
Value
1.0 μF
2.2 μF
3.9 μF
4.7 μF
6.8 μF
10 μF
Rated
Voltage
250 V
100 V
100 V
100 V
100 V
100 V
Case
Size
A57
A52
A52
A54
A57
A58
1 kHz
1.0
1.5
2.0
2.0
3.0
4.0
10 kHz
2.2
2.3
4.0
4.5
6.0
9.0
100 kHz
5.5
6.0
10.0
10.0
11.0
13.0
500 kHz
9.0
7.5
11.0
12.5
13.0
14.0
1 MHz
10.0
10.0
11.5
12.5
13.5
14.5
Environmental Compliance
