Product data sheet
Characteristics
XUK9ANBNM12
photo-electric sensor - XUK - polarised - Sn 5m
- 12..24VDC - M12
Product availability: Stock - Normally stocked in distribution facility
Main
Commercial Status
Range of product
Series name
Electronic sensor type
Sensor name
Sensor design
Detection system
Material
Type of output signal
Supply circuit type
Wiring technique
Discrete output type
Discrete output function
Electrical connection
Product specific
application
Emission
[Sn] nominal sensing
distance
Commercialised
OsiSense XU
General purpose single mode
Photo-electric sensor
XUK
Compact 50 x 50
Polarised reflex
Discrete
DC
3-wire
NPN
1 NC
1 male connector M12, 4 pins
-
Red polarised reflex
16.4 ft (5 m) polarised reflex need reflector XUZC50
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
Plastic
Complementary
Enclosure material
Lens material
Maximum sensing distance
Output type
Status LED
[Us] rated supply voltage
Switching capacity in mA
Switching frequency
Voltage drop
Current consumption
Delay first up
Delay response
Delay recovery
Setting-up
Depth
Height
Width
Product weight
PBT
PMMA
26.25 ft (8 m) polarised reflex
Solid state
1 LED (yellow) for output state
12...24 V DC
<= 100 mA (overload and short-circuit protection)
<= 250 Hz
<= 1.5 V (closed state)
<= 35 mA (no-load)
< 15 ms
< 2 ms
< 2 ms
Without sensitivity adjustment
1.97 in (50 mm)
1.97 in (50 mm)
0.71 in (18 mm)
0.15 lb(US) (0.07 kg)
Feb 28, 2016
1
Environment
Product certifications
CE
CSA
UL
-13...131 °F (-25...55 °C)
-40...158 °F (-40...70 °C)
7 gn, amplitude = +/- 1.5 mm (f = 10...55 Hz) conforming to IEC 60068-2-6
30 gn (duration = 11 ms) conforming to IEC 60068-2-27
IP65 double insulation conforming to IEC 60529
Ambient air temperature for operation
Ambient air temperature for storage
Vibration resistance
Shock resistance
IP degree of protection
Ordering and shipping details
Category
Discount Schedule
GTIN
Nbr. of units in pkg.
Package weight(Lbs)
Product availability
Returnability
Country of origin
21571 - SENSORS, ELECTRONIC BASIC XU & XS
DS2
00785901501206
1
0.13
Stock - Normally stocked in distribution facility
Y
ID
Offer Sustainability
Sustainable offer status
RoHS
REACh
Product environmental profile
Product end of life instructions
Green Premium product
Compliant - since 0841 -
Available
Available
Schneider Electric declaration of conformity
Reference not containing SVHC above the threshold
Download Product Environmental
Download End Of Life Manual
Contractual warranty
Period
18 months
2
