Embedded Power for
Business-Critical Continuity
BXA3 Series
Single output
Total Power:
5W
Input Voltage: 38 - 72VDC
# of Outputs: Single
Rev.03.07.07
bxa3
1 of 4
Special Features
• 3 Watts in DIL Package
• 9 models including 3.3 Vdc
output
• Wide input ranges 9 Vdc to 18
Vdc, 18 Vdc to 36 Vdc, 36 Vdc
to 75 Vdc
• EN55022 conducted emissions
level A (optional)
• Continuous short circuit
protection
• Operating temperature
range -25 °C to +105 °C
• Input voltage range to
ETS300-132-2
• UL, VDE and CSA safety
approvals
• Available RoHS compliant
• 2 year warranty
The BXA3 Series of dc-dc converters is designed to offer the
optimum cost/benefit power solution for a wide variety of
applications including public and private telecommunications,
industrial systems and process and test equipment. The series
consists of 9 models with input voltages of 9 Vdc to 18Vdc, 18 Vdc
to 36 Vdc and 36 Vdc to 75 Vdc, and offers standard output
voltages of 3.3 V, 5 V, 12 V and 15 V in single and dual output
configurations. Continuous short-circuit protection, overvoltage
protection, 60 mV output ripple and EN55022 level A conducted
noise compliance minimize design-in time, cost and eliminate the
need for external components.
Safety
VDE0805/EN60950/IEC950
File No. 10401-3336-0098
Licence No. 5856
UL1950 File No. E136005
CSA C22.2 No. 950
File No. LR41062C
Embedded Power for
Business-Critical Continuity
Specifications
All specifications are typical at nominal input, full load at 25
°
C unless otherwise stated.
Rev.03.07.07
bxa3
2 of 4
OUTPUT SPECIFICATIONS
Voltage accuracy
Line regulation
Load regulation
Ripple and noise
(5 Hz to 20 MHz)
LL to HL, all outputs
Full load to no load
+5 V output
All others
Temperature coefficient
Over voltage protection
Short circuit protection
INPUT SPECIFICATIONS
Input voltage range
12 Vdc
24 Vdc
48 Vdc
Suffix ‘-F’ (See Note 5)
(See Note 7)
Output remains within
specification
9-18 Vdc
18-36 Vdc
36-75 Vdc
Pi type
Yes
5 V/ms
Clamp diode
±1.0%
±2.5%
±2.5%
60 mV pk-pk, max.,
15 mV rms
100 mV pk-pk, max.,
15 mV rms
±0.02%/°C, max.
135% Vout
Continuous
automatic recovery
EMC CHARACTERISTICS
Conducted emissions
EN55022, FCC part 15
Suffix ‘-F’ versions
(See Notes 5 and 6)
Level A
GENERAL SPECIFICATIONS
Efficiency
Isolation voltage
Switching frequency
Approvals and
standards
Case material
Material flammability
Weight
MTBF
MIL-HDBK-217F
Input/output
Variable
See table
500 Vdc
200 kHz to1 MHz
VDE0805, EN60950, IEC950
UL1950, CSA C22.2 No. 950
Non-conductive
black plastic
UL94V-0 min.
15 g (0.53 oz)
800,000 hours
Input filter
Reverse voltage
protection
Max. input rise
and fall time
ENVIRONMENTAL SPECIFICATIONS
Thermal performance
Operating ambient
(See derating curve)
Non-operating amb
Cooling
Non-condensing
Operating
Non operating
5 Hz to 500 Hz
-25 °C to +105 °C
-40 °C to +105 °C
Free air convection
cooled
5% to 95% RH
10,000 feet max.
40,000 feet max.
2.5 G rms (approx.)
Relative humidity
Altitude
Vibration
Embedded Power for
Business-Critical Continuity
Specifications Contd.
Rev.03.07.07
bxa3
3 of 4
INPUT
VOLTAGE
9-18 Vdc
9-18 Vdc
18-36 Vdc
18-36 Vdc
18-36 Vdc
36-75 Vdc
36-75 Vdc
36-75 Vdc
36-75 Vdc
OUTPUT
VOLTAGE
3.3 V
15 V
3.3 V
5V
±5 V
3.3 V
5V
12 V
15 V
OUTPUT
CURRENT
(1)
600 mA
200 mA
600 mA
500 mA
±250 mA
600 mA
500 mA
250 mA
200 mA
INPUT
CURRENT
(2)
245 mA
335 mA
122 mA
140 mA
140 mA
61 mA
69 mA
83 mA
83 mA
TYPICAL
EFFICIENCY
68%
75%
68%
76%
76%
68%
76%
76%
76%
REGULATION
LINE
(3)
±2.5%
±2.5%
±2.5%
±2.5%
±2.5%
±2.5%
±2.5%
±2.5%
±2.5%
LOAD
(4)
±2.5%
±2.5%
±2.5%
±2.5%
±2.5%
±2.5%
±2.5%
±2.5%
±2.5%
MODEL
NUMBER
(5,8,9)
BXA3-12S3V3J
BXA3-12S15J
BXA3-24S3V3J
BXA3-24S05J
BXA3-24D05J
BXA3-48S3V3J
BXA3-48S05J
BXA3-48S12J
BXA3-48S15J
Notes
1
2
3
4
5
6
Maximum.
Maximum figure at full load (nominal).
Low line to high line.
Full load to no load.
An optional internal filter is available. When the filter is added, the BXA3
will meet VDE0871-A, VDE0878-A and EN55022-A. Add the suffix ‘-F’ to
the model number, e.g.
BXA3-12S15-FJ.
Conducted noise filtering to EN55022 level B may be accomplished by
putting the following capacitors across the input pins.
12 Vdc
5 μF ceramic X7R dielectric type
24 Vdc
3 μF ceramic X7R dielectric type
48 Vdc
1 μF ceramic X7R dielectric type
Reverse voltage protection can be implemented by putting a fast blow fuse
on the positive input rail. Rate the fuse for 250 mA at 48 Vdc input, 500 mA
at 24 Vdc input and 1000 mA at 12 Vdc input.
The ‘J’ suffix indicates that these parts are Pb-free (RoHS 6/6) compliant.
TSE RoHS 5/6 (non Pb-free) compliant versions may be available on special
request, please contact your local sales representative for details.
NOTICE: Some models do not support all options. Please contact your local
Artesyn representative or use the on-line model number search tool at
http://www.artesyn.com/powergroup/products.htm to find a suitable
alternative.
7
8
9
Embedded Power for
Business-Critical Continuity
Rev.03.07.07
bxa3
4 of 4
Americas
0.12 Typ
(3.0)
0.1
(2.5)
23
22
2
3
0.020 Dia.
(0.5)
DOT ON TOP
REFERENCES
PIN 2
5810 Van Allen Way
Carlsbad, CA 92008
USA
Telephone: +1 760 930 4600
Facsimile: +1 760 930 0698
Europe (UK)
1.25
(31.8)
0.6
(15.2)
BOTTOM VIEW
0.1
(2.5)
0.1
(2.5)
0.175
(4.5)
0.1
(2.5)
16
15
14
9
10
11
0.03
(0.762)
Waterfront Business Park
Merry Hill, Dudley
West Midlands, DY5 1LX
United Kingdom
Telephone: +44 (0) 1384 842 211
Facsimile: +44 (0) 1384 843 355
Asia (HK)
0.60
(15.2)
0.02
(0.5)
0.50
(12.7)
0.80
(20.3)
ALL DIMENSIONS IN Inches (mm)
ALL PINS ARE IN TRUE POSITION WITHIN .010 DIA. @ M.M.C.
TOLERANCE
.XX =
±
0.02
(INCHES)
.XXX =
±
0.005
16th - 17th Floors, Lu Plaza
2 Wing Yip Street, Kwun Tong
Kowloon, Hong Kong
Telephone: +852 2176 3333
Facsimile: +852 2176 3888
For global contact, visit:
www.powerconversion.com
technicalsupport@powerconversion.com
PIN CONNECTIONS
PIN NUMBER
2
3
22
23
9
10
11
14
15
16
SINGLE OUTPUT
–Vin
–Vin
+Vin
+Vin
No Pin
No Pin
No Connection
+Vout
No Pin
-Vout
DUAL OUTPUT
–Vin
–Vin
+Vin
+Vin
Common
No Pin
-Vout
+Vout
No Pin
Common
While every precaution has been taken to ensure
accuracy and completeness in this literature, Emerson
Network Power assumes no responsibility, and disclaims
all liability for damages resulting from use of this
information or for any errors or omissions.
Emerson Network Power.
The global leader in enabling
business-critical continuity.
AC Power
Connectivity
DC Power
Embedded Power
Inbound Power
Integrated Cabinet Solutions
Outside Plant
Precision Cooling
DERATING CURVE
Output Power (Watts)
2.5/3W
71°C
85°C
Site Monitoring and Services
EmersonNetworkPower. com
0W
-25°C -20°C -10°C
0°C 10°C
20°C
30°C 40°C
50°C
60°C 70°C 80°C
105°C
90°C 100°C 110°C
