The REC7.5-xxxxSRW/DRW-series offer single and dual regulated outputs in a DIP24 package
with 1kV, 2kV or 3kV options and are suitable for higher power industrial or medical
applications. Remote on/off control is possible with the /CTRL option and SMD pinning is
offered with the /SMD option. The converters can deliver 140% rated power for short periods
of time to cope with applications with large capacitive loads or high start up currents.
7.5 Watt
DIP24
&
SMD
Single
&
Dual
Output
Selection Guide
Part
Number
REC7.5-xx3.3SRW/H*/A/M
REC7.5-xx05SRW/H*/A/M
REC7.5-xx09SRW/H*/A/M
REC7.5-xx12SRW/H*/A/M
REC7.5-xx15SRW/H*/A/M
REC7.5-xx05DRW/H*/A/M
REC7.5-xx09DRW/H*/A/M
REC7.5-xx12DRW/H*/A/M
REC7.5-xx15DRW/H*/A/M
Input
Voltage
(VDC)
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
Output
Voltage
(VDC)
3.3
5
9
12
15
±5
±9
±12
±15
Output
Current
(mA)
1800
1500
833
625
500
±750
±417
±312
±250
Efficiency
(%)
78
79-82
81-84
82-85
83-86
79-82
81-84
82-85
83-86
Max
Capacitive
Load
(1)
6800µF
6800µF
6800µF
6800µF
6800µF
±2200µF
±2200µF
±2200µF
±2200µF
2011/65/EU
6/6
RoHS
E-358085
EN-60950-1 Certified
EN-60601-1 Certified
UL-60950-1 Certified
* add suffix /H1 for 1kVDC Isolation, /H2 for 2kVDC isolation or /H3
for 3kVDC Isolation (not available in H3/A/M/SMD combination)
* add suffix “/SMD” for SMD package, e.g. REC7.5-2405DRW/H1/A/M/SMD
* add suffix “/CTRL” for Remote Pin option
* add suffix „-R“ for Tape and Reel Packaging (only for SMD type available)
e.g. REC7.5-2405DRW/H1/A/M/SMD/CTRL-R
no plastic case is available for REC7.5
2:1
xx = 9-18Vin = 12,
xx = 18-36Vin = 24,
xx = 36-72Vin = 48
REC 7.5
Derating-Graph
(Ambient Temperature)
100
80
Output Power (%)
Specifications
(
measured at TA = 25°C, nominal input voltage, full load and after warm-up)
Single
Efficiency / Load
100
80
60
40
Dual
Efficiency / Load
100
80
60
60
40
30
20
0
Safe Operating Area
2412
4805
2409D
4815D
-40
0
50
85 100
71
150
483.3
Efficiency %
4812
40
20
0
2405D
2412D
Operating Temperature °C
Efficiency %
20
0
0% 20%
40%
60%
Total Output current (%)
80%
100%
0% 20%
40%
60%
Total Output current (%)
80%
100%
**Any data referred to in this datasheet are of indicative nature
and based on our practical experience only. For further details,
please refer to our Application Notes.
Refer to Application Notes
www.recom-power.com
REV: 0/2015
E-157
ECONOLINE
DC/DC-Converter
Input Voltage Range
Output Voltage Accuracy
Line Voltage Regulation
Load Voltage Regulation (25% to 100% full load )
Minimum Load
Output Ripple and Noise (at 20MHz BW)
Operating Frequency (Full Load)
Input Filter
Efficiency at Full Load
No Load Power Consumption
Isolation Voltage
H1-Suffix
H2-Suffix
H3-Suffix
Isolation Capacitance
Isolation Resistance
REC7.5-S_DRW/H*/A/M
Series
2:1
±2% max.
0.4% max.
0.8% max.
3.3V output type
5, 9, 12 and 15V output types
10%
(2)
100mVp-p max.
50mVp-p max.
150kHz min. / 240kHz max.
PI Network
see Selection Guide
(tested for 1 second)
(rated for 1 minute**)
(tested for 1 second)
(rated for 1 minute**)
(tested for 1 second)
(rated for 1 minute**)
300mW max.
1000VDC
500VAC / 60Hz
2000VDC
1000VAC / 60Hz
3000VDC
1500VAC / 60Hz
50pFtyp.
1 GΩ min.
Continuous, Auto Restart
-40°C to +71°C (see Graph)
-55°C to +125°C
95% RH
Natural convection
Nickel Plated Metal with Non-Conductive Base
12°C/W
16g
15 pcs per Tube
Specifications
(
measured at TA = 25°C, nominal input voltage, full load and after warm-up)
Short Circuit Protection (Max temp. = 50°C during short circuit conditions)
Operating Temperature Range (free air convection)
Storage Temperature Range
Relative Humidity
Case Material
Thermal Impedance
Package Weight
Packing Quantity
REC 7.5
MTBF (+25°C)
(+71°C)
}
Detailed Information see
Application Notes chapter "MTBF"
using MIL-HDBK 217F
using MIL-HDBK 217F
800 x 10
3
hours
>200 x 10
3
hours
UL 60950-1 1st Ed.
C22.2 No. 60950-1-03
EN60950-1:2006 +A12:2011
Certifications
UL General Safety
EN General Safety
EN Medical Safety
Notes
Note 1:
Note 2:
Report: E358085
Report: SPCLVD1212007
Report: MDD1205098-3 + RM1205098-3
IEC/EN 60601-1 3rd Edition; Medical Report + ISO14971 Risk Assessment
Maximum capacitive load is defined as the capacitive load that will allow start up in under 1 second without damage to the converter.
The REC 7.5 series requires a minimum of 10% load on the output to maintain specified regulation. Operating under no-load conditions
will not damage these devices; however, they may not meet all listed specifications.
Typical Characteristics
Overload Response
100
Vout (% nominal)
75
50
25
0
0
50
100
120
140
160
180
200
% of Rated Load
E-158
REV: 0/2015
www.recom-power.com
ECONOLINE
DC/DC-Converter
Package Style and Pinning (mm)
REC7.5-S_DRW/H*/A/M
Series
20.30
10.50
3.8
+0.5 /-0.25
24 PIN DIP Package
32.00
Pin Connections DIP24
Pin #
1
2
15.24
3
9
11
14
16
22
23
2.54
Top View
Single
–Vin
–Vin
NC
NC
+Vout
– Vout
+Vin
+Vin
Dual
–Vin
–Vin
Com
–Vout
+Vout
Com
+Vin
+Vin
CTRL/No Pin CTRL/No Pin
4.60
0.51
Recommended Footprint Details
1.00 ø+0.15/0
(1) 2 3
Bottom View
23 22
16
14
9
11
XX.X ± 0.5 mm
XX.XX ± 0.25 mm
2.54
24 PIN SMD Package
32.00
31.40
11.20
/H3/A/M/SMD combination is not allowed
19.90
10.90
3.81
6.35
20.30
25.40
Pin Connections DIP24 SMD
Pin #
Single
CTRL/NC
–Vin
–Vin
NC
NC
+Vout
– Vout
+Vin
+Vin
Dual
CTRL/NC
–Vin
–Vin
Com
–Vout
+Vout
Com
+Vin
+Vin
NC
NC
2.54
1
2
3
9
11
14
2.03
16
22
23
REC 7.5
Recommended Footprint Details
Pin area
0.1 x 0.50
1 2 3 4 5
0.50
9 10 11 12
2.54
1.54
23.40
Bottom View
24 23 22 21 20
16 15 14 13
26.67
24.64
1
Top View
1,4,5,10,12
13,15,20,21,24
NC = No Connection
XX.X ± 0.5 mm
XX.XX ± 0.25 mm
11 x 2.54
27.94
CTRL Option
Vin+
Fuse
22,23
2,3
ON = Open or 0V< Vctrl <1.2V
OFF = 2.2V< Vctrl <12V
0V
RECx-xxxx/CTRL
CTRL
1
1kW
1N4148
TTL Input
Off
On
The product information and specifications are subject to change without prior notice. RECOM products are not authorized for use in safety-critical applications (such as life support) without RECOM’s explicit
written consent. A safety-critical application is defined as an application where a failure of a RECOM product may reasonably be expected to endanger or cause loss of life, inflict bodily harm or damage property. The buyer
shall indemnify and hold harmless RECOM, its affiliated companies and its representatives against any damage claims in connection with the unauthorized use of RECOM products in such safety-critical applications.
www.recom-power.com
REV: 0/2015
E-159
