DTM165-C Series

160W to 165W Medical AC-DC External Power Supplies

Features



CEC, ErP and EISA

(1)

level V Compliant Models



Wide Range AC Input



Medical Certiﬁcations



> 87% Average Efﬁciency

Key Market Segments & Applications

Speciﬁcations

Model

Input Voltage range

Inrush Current

Input Current

Power Factor

Leakage Current (264VAC 60Hz)

Hold Up Time (Typ)

Temperature Coefﬁcient

Voltage Accuracy

Adjustment Range

Minimum Load

Total Regulation

Ripple & Noise

Short Circuit Protection

Overvoltage Protection

Efﬁciency

Operating Temperature

Storage Temperature

Humidity (non condensing)

Cooling

Withstand Voltage

Vibration (non operating)

Shock

Safety Agency Certiﬁcation

Efﬁciency Level

Ofﬂoad Power Consumption

Conducted & Radiated EMI

Immunity

Weight (Typ)

Size (WxLxH)

Cable Length

AC Input Connector

Output Connector

Warranty

VAC

%/°C

°C

%RH

VAC

yrs

DTM165PWxxx-C

90 - 264VAC (47 - 63Hz)

<130A at 230VAC input, 25°C ambient cold start

2.5A at 90VAC, Full Load

Meets EN61000-3-2. >0.9 PF

<300uA

>10ms

±0.05%/°C

±1%

None

12V to 19V Models:±5%, >19V models ±3%

<160% - hiccup mode

120 - 150% of nominal (Cycle input power to reset)

>87% average efﬁciency

0 to +60°C, derate linearly 50% load from 40 to 60°C

-10 to +80°C

0 - 90%RH

Convection

Input to Ground 1.5kVAC, Input to Output 4kVAC (Reinforced)(2 x MOPPs)

(Output is isolated from Ground)

23.52m/s (10 - 55Hz: constant sweep 1 min X, Y, Z for 1 hour)

< 196.1 m/s

(20G)

UL60601-1, EN60601-1, IEC60601-1, CE Mark

CEC, ErP, EISA level V

< 0.5W

EN55011, FCC Part 18 Class B

EN55011:2007+A2:2007

790

3.35 x 6.7 x 1.73”

1050mm

IEC 320-C14 (Accepts IEC 320-C13)

Kycon KPPx-4P or equivalent

Pins 1 & 2: -Vout, Pins 3 & 4: +Vout

Two Years

(1) EISA - Energy Independence and Security Act of 2007

1-800-526-2324 • www.us.tdk-lambda.com/lp/

146

Disclaimer: us.tdk-lambda.com/lp/legal.htm
