Features
■
Formerly
■
Available in E6 series
■
Low profile of only 5.0 mm
■
Inductance as low as 1.0 µH
■
RoHS compliant*
Applications
model
■
Input/output of DC/DC converters
■
Power supplies for:
*R
oH
S
T
•
•
•
•
Portable communication equipment
Camcorders
LCD TVs
Car radios
PM3316 Series - SMD Power Inductors
Electrical Specifications
Inductance 1 kHz
General Specifications
Test
Q Frequency
Ref.
(MHz)
20
10
50
3
50
3
50
4
50
4
50
3
50
3
50
3
40
3
25
1
25
1
25
1
30
0.05
30
0.05
33
0.05
33
0.05
57
0.05
57
0.05
81
0.07
SRF
Min.
(MHz)
137
95
65
54
42
31
26
22
18
14
12
11
8
6
5
4
4
3
2
I rms
Max.
(A)
7.50
6.50
6.10
5.00
4.50
3.40
2.90
2.50
2.00
1.80
1.40
1.20
1.00
0.80
0.70
0.55
0.45
0.35
0.30
I sat
Typ.
(A)
9.00
8.00
7.00
6.40
5.40
4.50
3.70
3.00
2.50
2.00
1.60
1.40
1.20
1.00
0.80
0.60
0.50
0.40
0.35
Bourns Part No.
PM3316-1R0M-RC
PM3316-1R5M-RC
PM3316-2R2M-RC
PM3316-3R3M-RC
PM3316-4R7M-RC
PM3316-6R8M-RC
PM3316-100M-RC
PM3316-150M-RC
PM3316-220M-RC
PM3316-330M-RC
PM3316-470M-RC
PM3316-680M-RC
PM3316-101M-RC
PM3316-151M-RC
PM3316-221M-RC
PM3316-331M-RC
PM3316-471M-RC
PM3316-681M-RC
PM3316-102M-RC
(µH)
1
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
Tol. %
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
RDC
(Ω)
0.007
0.009
0.012
0.015
0.019
0.030
0.050
0.060
0.10
0.12
0.19
0.24
0.33
0.59
0.78
1.15
1.70
2.60
3.90
Test Voltage ....................................0.1 V
Reflow soldering .... 250 °C; 10 sec max.
(In compliance with JEDEC,
J-STD-020C, Table 4-2)
Operating Temperature
................................-55 °C to +125 °C
(Temperature rise included)
Storage Temperature
................................-55 °C to +125 °C
Resistance to Soldering Heat
.......................... 250 °C, 10 sec. max.
Materials
Core ....................................... Ferrite DR
Wire ............................Enameled copper
Base ................................................DAP
Terminal ........................................Cu/Sn
Rated Current
...................Ind. drop 10 % typ. at Isat
Temperature Rise ................. 15 °C max.
at rated Irms
Packaging .................... 500 pcs. per reel
Product Dimensions
101
Electrical Schematic
10.0
±
0.2
(.393
±
.008)
12.7
±
0.2
(.500
±
.008)
5.0
±
0.3
MAX.
(.197
±
.012)
7.6
±
0.3
TYP.
(.299
±
.012)
2.4
±
0.2
TYP.
(.094
±
.008)
2.5
±
0.2
TYP.
(.098
±
.008)
• = START OF WINDING
Recommended Layout
7.3
(.287)
2.8
(.110)
3.0
(.118)
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications..
DIMENSIONS:
MM
(INCHES)
PM3316 Series - SMD Power Inductors
Soldering Profile
300
<1> Max. of 10 seconds at 250 °C
<2> Max. of 30 seconds > 220 °C
250
250 °C
<1>
200
<2>
Temperature (°C)
150
120 - 150 seconds
100
Ramp-down
5 °C/second maximum
50
Ramp-up
4 °/second maximum
0
0
50
100
150
Time
(seconds)
200
250
300
Packaging Specifications
330
(12.99)
DIA.
2.0
±
0.5
(.079
±
.020)
30.4
(1.20)
THICKNESS
0.10
(.004)
MAX.
50.0
(1.969)
13.0
±
0.5
DIA.
(.512
±
.020)
EMBOSSED
CARRIER
11.5
±
0.1
(.453
±
.004)
4.0
±
0.1
(.157
±
0.04)
EMBOSSED
CAVITY
21.0
±
0.8
(.827
±
.031)
13.0
±
0.5
(.512
±
.020)
DIA.
26
(1.02)
0.4
±
0.05
(.016
±
.002)
13.2
±
0.1
(.520
±
.004)
END
1.55
±
0.05
DIA.
(.061
±
.002)
START
24.0
±
0.3
(.945
±
.012)
101
101
101
5.3
±
0.1
(.153
±
.004)
10.4
±
0.1
(.409
±
.004)
NO COMPONENT
1.5
MIN.
(.059)
4.4
±
0.1
(.173
±
.004)
COMPONENTS
16.0
±
0.1
(.630
±
.004)
DIMENSIONS:
MM
(INCHES)
NO COMPONENT
200
(7.874)
11200
(440.945)
400
(15.748)
USER DIRECTION OF FEED
QTY: 500 PCS. PER REEL
REV. 06/10
Specifications are subject to change without notice.
