VP
ALUMINUM ELECTROLYTIC CAPACITORS
Bi-Polarized
series
Standard bi-polarized series for entertainment electronics.
Compliant to the RoHS directive (2011/65/EU).
EP
Wide
Temperature
VP
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
Performance Characteristics
–40 to +85°C
6.3 to 100V
0.47 to 6800µF
± 20% at 120Hz, 20°C
After 5 minutes' application of rated voltage at 20°C, leakage current is not more than 0.03CV or 3 (µA), whichever is greater.
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF.
Measurement frequency : 120Hz at 20°C
Rated voltage (V)
10
16
25
35
50
63
100
6.3
tan
δ
(MAX.)
0.24
0.22
0.20
0.16
0.14
0.12
0.10
0.26
Measurement frequency : 120Hz
Rated voltage (V)
Z– 25°C / Z+20°C
Impedance ratio
ZT / Z20 (
MAX.
)
Z– 40°C / Z+20°C
Stability at Low Temperature
6.3
4
10
10
3
8
16
2
6
25
2
5
35
2
4
50
2
4
63
2
3
100
2
3
Endurance
The specifications listed at right shall be met when
the capacitors are restored to 20°C after the rated
voltage is applied for 2000 hours at 85°C with the
polarity inverted every 250 hours.
Capacitance change
tan
δ
Leakage current
Within ± 20% of the initial capacitance value
200% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Marking
After storing the capacitors under no load at 85°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
Printed with white color letter on black sleeve.
Radial Lead Type
Sleeve (P.E.T.) (P.E.T.)
Sleeve
Type numbering system (Example : 10V 47
µ
F)
φ
d
φ
d
1
2
31
4
2
5
3
6
4
7
5
86
9 10 11 10 11
7 8 9
UV P 1 A 4 7 0 M DD DD
UV P 1 A 4 7 0 M
P
±0.5
P
±0.5
φD
+
0.5
MAX
φD
+
0.5
MAX
Configuration
Configuration
Capacitance tolerance ( ±20%) ( ±20%)
Capacitance tolerance
Rated capacitance (47µF) (47µF)
Rated capacitance
Rated voltage (10V) (10V)
Rated voltage
Pressure
relief vent
(φ6.3up) (φ6.3up)
Pressure
relief vent
L
+
MAX
L
+
MAX
15
MIN
4
MIN
15
MIN
4
MIN
Series name name
Series
Type
(mm)
(mm)
Type
(L < 20) 1.5< 20) 1.5
φD
(L
(L > 20) 2.0> 20) 2.0
P
(L =
=
φd
86.3 10 8 12.5 16
5
φD
6.35
10 12.5 18
16
2.0P 2.5
2.0 3.5
2.5 5.0
3.5 5.0
5.0 7.5
5.0 7.5
7.5
0.5
φd
0.5
0.5 0.6
0.5 0.6
0.6 0.6
0.6 0.8
0.6 0.8
0.8
18
7.5
0.8
Configuration
Configuration
φ
D
Pb-free leadwire
φ
D
Pb-free PET sleeve sleeve
Pb-free PET
Pb-free leadwire
•
Please refer to page 20 about the end seal configuration.
5
5
6.3
6.3
8 · 10 8 · 10
12.5 to 1812.5 to 18
DD
ED
PD
HD
DD
ED
PD
HD
Please refer to page 20, 21, 22 about the formed or taped product spec.
Please refer to page 4 for the minimum order quantity.
Dimension table in next page.
