39.50
`
0.37 mm
[1.555
`
0.015 in]
35.60 mm
[1.402 in]
0.30 mm
[0.012 in]
23.00 mm
[0.906 in]
2.05 mm
[0.081 in]
42.43 mm
[1.670 in]
2 X
n
0.165 in THRU
w n
0.230 in X 82.0°
D
20.00
`
0.42 mm
[0.787
`
0.017 in]
1.20 mm
[0.047 in]
22.93 mm
[0.903 in]
C
1.46 mm TYP 1.80 mm TYP
[0.057 in]
[0.071 in]
2.00 mm
[0.079 in]
35.60 mm
[1.402 in]
1.63 mm
[0.064 in]
C
EXTRUSION PROFILE
33.10 mm
[1.303 in]
ENDPLATE
EXPLODED ASSEMBLY VIEW
**DESIGNED FOR 39MM WIDE PC BOARD**
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc. )
Contact Factory
mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES.
44.62 mm
[1.757 in]
B
A
36.68 mm
[1.444 in]
25.12 mm
[0.989 in]
20.18 mm
[0.794 in]
3.00 mm
[0.118 in]
NOTE
Purchased assembly includes box, plastic bezels, End Panels,
Custom #6 Taptight screws and self adhesive rubber feet
Box made from Extruded Aluminum 6063-T5
Bezels made with polycarbonate.
End Plates made from 5052-H32 Aluminum
B
60.00
`
0.50 mm
[2.362
`
0.020 in]
1455D601
PART NUMBERS
Clear Anodized
Black Anodized
Blue Anodized
Red Anodized
1455D601
1455D601BK
1455D601BU
1455D601RD
A
35.60 mm
[1.402 in]
A
42.50 mm
[1.673 in]
6.00 mm
[0.236 in]
ACCESSORIES
See website for accessories.
OPEN BEZEL
SECTION A-A
A
1455D601
6
5
4
3
2
1
8
7
