Type 12 Wiring Trough (1486 Series) - Hammond Mfg.
Quality Products. Service Excellence.
Type 12 Wiring Trough
1486 Series
Application
Designed to enclose and protect multiple wiring junctions from dirt, dust, oil and water.
Standards
UL 870 Type 1
CSA Type 1
Complies with
NEMA Type 12
JIC EGP-1-1967
JIC EMP-1-1967
IEC 60529, IP54
Construction
Formed 14 gauge steel.
Smooth continuously welded seams.
Butt hinged cover is secured with easily operated screw clamps.
Oil resistant gaskets are permanently secured.
12 gauge external mounting feet are welded to the back.
Finish
Troughs and covers are finished in ANSI 61 gray powder coating.
Overall Dimensions
Part No.
1486B12
1486B18
A
2.50
2.50
B
2.50
2.50
C
12.00
18.00
Cover Size
D
12.31
18.31
E
2.84
2.84
F
2.00
2.00
G
2.00
2.00
H
3.19
3.19
J
6.00
12.00
https://www.hammfg.com/electrical/products/wireway/1486
1/2
11/19/2017
Type 12 Wiring Trough (1486 Series) - Hammond Mfg.
Overall Dimensions
Part No.
1486B24
1486B30
1486B36
1486B48
1486B60
1486B72
1486C12
1486C18
1486C24
1486C30
1486C36
1486C48
1486C60
1486C72
1486D12
1486D18
1486D24
1486D30
1486D36
1486D48
1486D60
1486D72
A
2.50
2.50
2.50
2.50
2.50
2.50
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
B
2.50
2.50
2.50
2.50
2.50
2.50
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
C
24.00
30.00
36.00
48.00
60.00
72.00
12.00
18.00
24.00
30.00
36.00
48.00
60.00
72.00
12.00
18.00
24.00
30.00
36.00
48.00
60.00
72.00
Cover Size
D
24.31
30.31
36.31
48.31
60.31
72.31
12.31
18.31
24.31
30.31
36.31
48.31
60.31
72.31
12.31
18.31
24.31
30.31
36.31
48.31
60.31
72.31
E
2.84
2.84
2.84
2.84
2.84
2.84
4.34
4.34
4.34
4.34
4.34
4.34
4.34
4.34
6.34
6.34
6.34
6.34
6.34
6.34
6.34
6.34
F
2.00
3.00
3.00
3.00
3.00
3.00
2.00
2.00
2.00
3.00
3.00
3.00
3.00
3.00
2.00
2.00
2.00
3.00
3.00
3.00
3.00
3.00
G
3.00
3.00
3.00
3.00
4.00
4.00
2.00
2.00
3.00
3.00
3.00
3.00
4.00
4.00
2.00
2.00
3.00
3.00
3.00
3.00
4.00
4.00
H
3.19
3.19
3.19
3.19
3.19
3.19
4.69
4.69
4.69
4.69
4.69
4.69
4.69
4.69
6.69
6.69
6.69
6.69
6.69
6.69
6.69
6.69
J
9.00
12.00
15.00
21.00
18.00
22.00
6.00
12.00
9.00
12.00
15.00
21.00
18.00
22.00
6.00
12.00
9.00
12.00
15.00
21.00
18.00
22.00
Data subject to change without notice
© 2017. Hammond Manufacturing Ltd. All rights reserved.
