LPP-150-48 Overview

Switching Power Supplies 76.8W 24V 3.2A

LPP-150-48 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	MEAN WELL
package instruction	,
Reach Compliance Code	compliant
Other features	ALSO OPERATE WITH INPUT FROM 120-370VDC
Analog Integrated Circuits - Other Types	AC-DC POWER FACTOR CORRECTION MODULE
Maximum input voltage	264 V
Minimum input voltage	85 V
Nominal input voltage	115 V
JESD-30 code	R-XXMA-X16
Number of functions	1
Output times	1
Number of terminals	16
Maximum output voltage	52.8 V
Minimum output voltage	45.6 V
Nominal output voltage	48 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
surface mount	NO
technology	HYBRID
Terminal form	UNSPECIFIED
Terminal location	UNSPECIFIED
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	153.6 W
Fine-tuning/adjustable output	YES

Preview

Download Datasheet

View All

150W Single Output with PFC Function

Features :

LPP-150

series

Universal AC input / Full range

Built-in active PFC function, PF>0.96

Protections:Short circuit/Over load/Over voltage

Protections:Over temperature(option)

Cooling by free air convection

100% full load burn-in test

Fixed switching frequency at PFC:67KHz PWM:134KHz

3 years warranty

SPECIFICATION

MODEL

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

OUTPUT

VOLTAGE ADJ. RANGE

VOLTAGE TOLERANCE

Note.3

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

HOLD TIME (Typ.)

VOLTAGE RANGE

FREQUENCY RANGE

POWER FACTOR

INPUT

EFFICIENCY(Typ.)

AC CURRENT (Typ.)

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

OVER LOAD

PROTECTION

OVER VOLTAGE

WORKING TEMP.

WORKING HUMIDITY

ENVIRONMENT STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

SAFETY STANDARDS

WITHSTAND VOLTAGE

SAFETY & ISOLATION RESISTANCE

EMC

(Note 4)

LPP-150-3.3 LPP-150-5

3.3V

30A

0 ~ 30A

99W

30A

0 ~ 30A

150W

100mVp-p

LPP-150-7.5 LPP-150-12 LPP-150-13.5 LPP-150-15 LPP-150-24 LPP-150-27 LPP-150-48

7.5V

20A

0 ~ 20A

150W

100mVp-p

12V

12.5A

0 ~ 12.5A

150W

100mVp-p

13.5V

11.2A

0 ~ 11.2A

151.2W

100mVp-p

15V

10A

0 ~ 10A

150W

100mVp-p

24V

6.3A

0 ~ 6.3A

150W

150mVp-p

27V

5.6A

0 ~ 5.6A

151.2W

150mVp-p

48V

3.2A

0 ~ 3.2A

153.6W

250mVp-p

RIPPLE & NOISE (max.)

Note.2

100mVp-p

3.14 ~ 3.63V 4.75 ~ 5.5V

2.0%

0.5%

1.0%

0.5%

1.0%

7.13 ~ 8.25V 11.4 ~ 13.2V 12.8 ~ 14.9V 14.3 ~ 16.5V 22.8 ~ 26.4V 25.7 ~ 29.7V 45.6 ~ 52.8V

2.0%

1.0%

0.5%

1.0%

0.5%

1.0%

0.5%

1.0%

0.5%

1.0%

0.5%

600ms, 30ms at full load

30ms at full load

85 ~ 264VAC

47 ~ 63Hz

PF 0.96/230VAC

66%

2.5A/115VAC

72%

PF 0.98/115VAC at full load

76%

79%

80%

83%

1.2A/230VAC

120 ~ 370VDC

COLD START 40A/230VAC

<3.5mA / 240VAC

105 ~ 150%

rated output power

Protection type : Constant current limiting, recovers automatically after fault condition is removed

3.63 ~ 4.45V 5.5 ~ 6.75V 8.25 ~ 10.1V 13.2 ~ 16.2V 14.85 ~ 18.2V 16.5~ 20.25V 26.4 ~ 32.4V 29.7 ~ 36.5V 52.8 ~ 64.8V

Protection type : Shut down o/p voltage, re-power on to recover

-10 ~ +60 with cooling FAN(Refer to output load derating curve)

20 ~ 90% RH non-condensing

-20 ~ +85

, 10 ~ 95% RH

0.05%/ (0 ~ 50

10 ~ 500Hz, 2G 10min./1cycle, Period for 60min.each along X, Y, Z axes

UL60950-1, TUV EN60950-1 Approved

I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC

EMI CONDUCTION & RADIATION

Compliance to EN55022 (CISPR22) Class B

HARMONIC CURRENT

Compliance to EN61000-3-2,-3

EMS IMMUNITY

MTBF

Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, Light industry level, criteria A

191.8Khrs min. MIL-HDBK-217F (25

222*75*41mm (L*W*H)

0.62Kg; 24pcs/16.6Kg/1.39CUFT

)

OTHERS

NOTE

DIMENSION

PACKING

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

File Name:LPP-150-SPEC 2005-09-13
