DPP120-960 Series
120W, 240W, 480W & 960W 3 Phase DIN Rail Mount Power Supplies
Features
Low Cost
12V, 24V or 48V Outputs
Wide Range 340 to 575VAC Input
Parallel Function Switch (240 & 480W)
Current Share (960W)
-40
(3)
to +71°C Operation
Key Market Segments & Applications
Specifications
Model
AC Input Voltage range
(1)
Input Frequency
DC Input Voltage range
Inrush Current (380-480VAC)
Power Factor
(2)
Input Current (400VAC) (typ)
Output Voltage Accuracy
Line Regulation
Load Regulation
Ripple and Noise (20MHz BW)
Overcurrent Protection (Typ)
Overvoltage Protection
Overtemperature Protection
Hold Up Time (380-480VAC)
Parallel operation (up to 90% load)
LED Indicators
DC Good Relay (24V models only)
Operating Temperature
Storage Temperature
Operating Humidity (non condensing)
Cooling
Withstand Voltage
Isolation Resistance
Vibration
Shock
Vibration (Operating)
Shock (Operating)
Safety Agency Approvals
Conducted & Radiated EMI
Immunity
Weight (Typ)
Size (WxHxD)
Switching Frequency
MTBF (Bellcore Issue 6 @40°C, GB)
Case material
Warranty
VAC
Hz
VDC
A
-
A
%
%
%
mV
-
V
-
ms
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
g
in
kHz
Hours
-
yrs
DPP240-xx-3
DPP480-xx-3
DPP960-xx-3
340 - 575VAC, three phase
47 - 63Hz
480 - 820VDC*
10A
20A
20A
30A
0.55
0.55
0.65
0.8
0.36A
0.65A
1.1A
1.72A
-0, +1% of Nominal
±1%
±1%
±1% (±5% when set in parallel mode)
100mV
100mV
100mV
80mV
115 - 135%
120 - 140%
110 - 135%
110 - 130%
See model selector
Yes, auto recovery
> 20ms
> 20ms
> 20ms
> 15ms
-
Set in parallel (droop) mode - up to 2 units
Green LED = On, Red LED = DC Output Low
0.3A rated normally open relay contacts, closes when output is above 17.6 - 19.4V
-40
(3)
to +71°C(Derate linearly 2.5%/°C from 61 to 71°C, 3.5%/°C for DPP960)”
-40 to +85°C
20 - 95% RH
Convection. Recommend 1” clearance on all sides
Input to Output 3kVAC, Input to Ground 1.5kVAC for 1 min.
>100M at 25°C & 70%RH, Output to Ground 500VDC
IEC 60068-2-6. 10- 500Hz, 2G on X, Y & Z axes
IEC 60068-2-27. Half sinewave, 4G, 22ms, 3 times each face
IEC 60068-2-6 (Mounting by rail: Random wave, 10-500 Hz, 2G, ea. along X, Y Z axes 10 min/cycle, 60 min)
,
IEC 60068-2-27 (Half sine wave, 4G, 22ms, 3 axes, 6 Faces, 3 times for each face)
UL508 Listed, UL60950-1, EN60950-1, CE
EN55022 class B
IEC 61000-4-2, -3, 4, -5, -6. -8, -11
800g
1100g
1720g
3400g
2.92 x 4.88 x 4.68”
3.5 x 4.88 x 4.68” 5.91 x 4.88 x 4.68” 10.86 x 4.97 x 4.68”
70kHz
25kHz
80kHz
52kHz
527,000
488,000
411,000
352,000
Metal
Three years
*Safety certified for AC input only
DPP120-xx-3
(1) Bi-phase input is permissible, but output load must be derated to 75% load
(2) Passive, meets EN61000-3-2
(3) DPP480 -30°C
1-800-526-2324 • www.us.tdk-lambda.com/lp/
