SUPER BRIGHT T-1 3/4 (5 mm)
LED LAMP - Water Clear
PACKAGE DIMENSIONS
0.200 (5.08)
0.180 (4.57)
5°
SUPER GREEN
MV8410 MV8411
MV8412
MV841X
0.350 (8.89)
0.330 (8.38)
0.040 (1.02)
FEATURES
• Popular T-1 3/4 package
1.00 (25.4)
MIN
• Super high brightness suitable for outdoor
applications
• Solid state reliability
0.023 (0.58)
0.017 (0.43)
SQ. (2X)
0.100 (2.54)
NOM
• Water clear optics
0.050 (1.27)
NOM
• Standard 100 mil. lead spacing
FLAT DENOTES
CATHODE
Ø0.230 (5.84)
NOTES:
1. Dimensions for all drawings are in inches (mm).
2. Lead spacing is measured where the leads emerge from
the package.
3. Protruded resin under the flange is 1.5 mm (0.059") max.
DESCRIPTION
This T-1 3/4 super bright LED has a narrow viewing angle of 12°
for concentrated light output. The MV841X series is made with a
GaP LED that emits green light at 565 nm. It is encapsulated in a
water clear epoxy lens package.
ABSOLUTE MAXIMUM RATINGS
Parameter
Operating Temperature
Storage Temperature
Lead Soldering Time
Continuous Forward Current
Peak Forward Current
(f = 1.0 KHz, Duty Factor = 1/10)
Reverse Voltage
Power Dissipation
(T
A
= 25°C unless otherwise specified)
Symbol
T
OPR
T
STG
T
SOL
I
F
I
F
V
R
P
D
Rating
-40 to +85
-40 to +100
260 for 5 sec
30
160
5
85
Unit
°C
°C
°C
mA
mA
V
mW
1 of 3
2/17/00
300036A
SUPER BRIGHT T-1 3/4 (5 mm)
LED LAMP - Water Clear
SUPER GREEN
MV8410 MV8411
MV8412
ELECTRICAL / OPTICAL CHARACTERISTICS
Part Number
Luminous Intensity (mcd)
Minimum
Typical
Forward Voltage (V)
Maximum
Typical
Peak Wavelength (nm)
Spectral Line Half Width (nm)
Viewing Angle (°)
2.8
2.1
565
30
12
2.8
2.1
565
30
12
2.8
2.1
565
30
12
I
F
= 20mA
I
F
= 20mA
I
F
= 20mA
160
240
250
370
400
600
I
F
= 20mA
MV8410
(T
A
=25°C)
MV8411
MV8412
Condition
I
F
= 20mA
MV841X
TYPICAL PERFORMANCE CURVES
90
2.5
RELATIVE LUMNOUS INTENSITY
(NORMALIZED AT 20 mA)
1.0
2.0
3.0
4.0
5.0
80
I
F
- FORWARD CURRENT (mA)
70
60
50
40
30
20
10
0
2.0
1.5
1.0
0.5
0.0
0
5
10
15
20
25
30
V
F
- FORWARD VOLTAGE (V)
I
F
- DC FORWARD CURRENT (mA)
Fig. 1 Forward Current vs. Forward Voltage
Fig. 2 Relative Luminous Intensity vs.
DC Forward Current
2 of 3
2/17/00
300036A
SUPER BRIGHT T-1 3/4 (5 mm)
LED LAMP - Water Clear
SUPER GREEN
MV8410 MV8411
MV8412
1.0
MV841X
RELATIVE INTENSITY
-20˚
0.5
-40˚
-50˚
-60˚
-70˚
-80˚
0
500
550
600
650
700
750
-90˚
100
80
60
40
-30˚
-10˚
0˚
10˚
20˚
30˚
40˚
50˚
60˚
70˚
80˚
20
0
20
40
60
80
90˚
100
WAVELENGTH (nm)
REL. LUMINOUS INTENSITY (%)
Fig. 3 Relative Intensity vs. Peak Wavelength
Fig. 4 Radiation Diagram
50
I
F
- FORWARD CURRENT (mA)
40
30
20
10
0
0
20
40
60
85
100
T
A
- AMBIENT TEMPERATURE (˚C)
3 of 3
2/17/00
300036A
